KITCHENAID KHSD4 11380
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | KHSD4 11380 |
| Kód 12NC/I.C. kód: | 851349201000 |
| Značka: | KITCHENAID |
| Typ produktu: | Vestavné trouby a varné desky |
| Další podobné modely: | Q0961920000, 859991538650, 851349212100 |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 11192380 WHR06283 |
C00416556
482000019255 |
Bracket Gas cock | Na dotaz | Zadat poptávku | |
| 11192495 WHR06283 |
C00416549
482000019248 |
Support burner | Na dotaz | Zadat poptávku | |
| 11193030 WHR06283 |
C00416532
482000019229 |
Bracket Gas cock | Na dotaz | Zadat poptávku | |
| 11193580 WHR06283 |
C00416533
482000019230 |
Cover base | Na dotaz | Zadat poptávku | |
| 11194090 WHR06283 |
C00416534
482000019231 |
Cover terminal block | Na dotaz | Zadat poptávku | |
| 11203641 WHR06283 |
C00417863
482000021733 |
Grid for hob wok | Na dotaz | Zadat poptávku | |
| 11230380 WHR06283 |
C00417891
482000021761 |
Spring sparkplug | Na dotaz | Zadat poptávku | |
| 11280011 WHR06283 |
C00332177
481250518404 |
Thermocouple nut | Na dotaz | Zadat poptávku | |
| 11290252 WHR06283 |
C00416557
482000019256 |
Spacer | Na dotaz | Zadat poptávku | |
| 11290330 WHR06283 |
C00417892
482000021762 |
Nut sparkplug | Na dotaz | Zadat poptávku | |
| 11381310 WHR06283 |
C00417864
482000021734 |
Buffer piece | Na dotaz | Zadat poptávku | |
| 11381600 WHR06283 |
C00416535
482000019232 |
Ring ignition switch | Na dotaz | Zadat poptávku | |
| 11381830 WHR06283 |
C00417865
482000021735 |
Threaded ring button | Na dotaz | Zadat poptávku | |
| 11410140 WHR06283 |
C00332675
481253268097 |
Těsnění | Na dotaz | Zadat poptávku | |
| 11410310 WHR06283 |
C00332506
481253048294 |
Spojka kónická | Na dotaz | Zadat poptávku | |
| 11427240 WHR06283 |
C00416558
482000019257 |
Manifold | Na dotaz | Zadat poptávku | |
| 11427250 WHR06283 |
C00416559
482000019258 |
Gas pipe | Na dotaz | Zadat poptávku | |
| 11427260 WHR06283 |
C00416560
482000019259 |
Gas pipe | Na dotaz | Zadat poptávku | |
| 11428450 WHR06283 |
C00417959
482000021844 |
Gas pipe | Na dotaz | Zadat poptávku | |
| 11428460 WHR06283 |
C00417960
482000021845 |
Gas pipe | Na dotaz | Zadat poptávku | |
| 11430421 WHR06283 |
C00328765
481236078104 |
Malý hořák | Na dotaz | Zadat poptávku | |
| 11430431 WHR06283 |
C00328766
481236078105 |
Burner medium | Na dotaz | Zadat poptávku | |
| 11430441 WHR06283 |
C00328767
481236078106 |
Burner cup | Na dotaz | Zadat poptávku | |
| 11431060 WHR06283 |
C00417871
482000021741 |
Burner | Na dotaz | Zadat poptávku | |
| 11431070 WHR06283 |
C00417872
482000021742 |
Spreader,burner | Na dotaz | Zadat poptávku | |
| 11431081 WHR06283 |
C00417873
482000021743 |
Spreader,burner aux. | Na dotaz | Zadat poptávku | |
| 11431091 WHR06283 |
C00417874
482000021744 |
Spreader,burner SR | Na dotaz | Zadat poptávku | |
| 11431101 WHR06283 |
C00417875
482000021745 |
Spreader,burner rap. | Na dotaz | Zadat poptávku | |
| 11441272 WHR06283 |
C00417876
482000021746 |
Burner cap | Na dotaz | Zadat poptávku | |
| 11441342 WHR06283 |
C00417877
482000021747 |
Burner cap ext. | Na dotaz | Zadat poptávku | |
| 11441362 WHR06283 |
C00417878
482000021748 |
Burner cap SR | Na dotaz | Zadat poptávku | |
| 11441372 WHR06283 |
C00417879
482000021749 |
Burner cap | Na dotaz | Zadat poptávku | |
| 11450798 WHR06283 |
C00417912
482000021795 |
Nozzle LPG 0.85 | Na dotaz | Zadat poptávku | |
| 11450895 WHR06283 |
C00417880
482000021750 |
Nozzle NG 0.71 | Na dotaz | Zadat poptávku | |
| 11450898 WHR06283 |
C00417949
482000021834 |
Nozzle LPG 0.46 | Na dotaz | Zadat poptávku | |
| 11450950 WHR06283 |
C00417913
482000021796 |
Nozzle NG | Na dotaz | Zadat poptávku | |
| 11450951 WHR06283 |
C00417950
482000021835 |
Nozzle NG | Na dotaz | Zadat poptávku | |
| 11450952 WHR06283 |
C00417914
482000021797 |
Nozzle NG | Na dotaz | Zadat poptávku | |
| 11450954 WHR06283 |
C00417961
482000021846 |
Nozzle NG | Na dotaz | Zadat poptávku | |
| 11450955 WHR06283 |
C00417962
482000021847 |
Nozzle LPG | Na dotaz | Zadat poptávku | |
| 11542113 WHR06283 |
C00326863
481213838016 |
Thermo couple L=600mm | Na dotaz | Zadat poptávku | |
| 11542452 WHR06283 |
C00417885
482000021755 |
Thermocouple | Na dotaz | Zadat poptávku | |
| 11543212 WHR06283 |
C00416562
482000019261 |
Switch ignition | Na dotaz | Zadat poptávku | |
| 11550384 WHR06283 |
C00321840
480121100288 |
Spark plug A-SR-R | Na dotaz | Zadat poptávku | |
| 11550591 WHR06283 |
C00417963
482000021848 |
Spark plug | Na dotaz | Zadat poptávku | |
| 11703525 WHR06283 |
C00417964
482000021849 |
Grid for hob | Na dotaz | Zadat poptávku | |
| 11703535 WHR06283 |
C00417965
482000021850 |
Grid for hob | Na dotaz | Zadat poptávku | |
| 11731950 WHR06283 |
C00416543
482000019242 |
Gas cock 0.34 | Na dotaz | Zadat poptávku | |
| 11731960 WHR06283 |
C00416544
482000019243 |
Gas cock 0.43 | Na dotaz | Zadat poptávku | |
| 11731980 WHR06283 |
C00417888
482000021758 |
Gas cock 0.29/0.57 | Na dotaz | Zadat poptávku | |
| 11743120 WHR06283 |
C00417889
482000021759 |
Knob | Na dotaz | Zadat poptávku | |
| 11780153 WHR06283 |
C00417966
482000021851 |
Cabinet | Na dotaz | Zadat poptávku | |
| 12530000 WHR06283 |
C00322176
480121102442 |
Svorkovnice+upevnění kabelu 16A | 438 Kč
€ 17.50 |
||
| 4170418500 WHR06283 |
C00417967
482000021852 |
Hob | Na dotaz | Zadat poptávku | |
