WHIRLPOOL AGB 655/DP Dishwasher sq. basket break t
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | AGB 655/DP Dishwasher sq. basket break t |
| Kód 12NC: | 851265515000 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Profesionální domácí čištění |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| A01 WHR55870 |
C00422376
483286008907 |
Frame | Na dotaz | Zadat poptávku | |
| A02 WHR55870 |
C00524366
483286001384 |
Tank | Na dotaz | Zadat poptávku | |
| A03 WHR55870 |
C00517725
483286008859 |
Door | Na dotaz | Zadat poptávku | |
| A04 WHR55870 |
C00338315
483286008861 |
Magnet ,cover | Na dotaz | Zadat poptávku | |
| A05 WHR55870 |
C00342109
483286008118 |
Door catch | Na dotaz | Zadat poptávku | |
| A06 WHR55870 |
C00338000
483286008119 |
Nut catch | Na dotaz | Zadat poptávku | |
| A07 WHR55870 |
C00340116
483286008862 |
Handle | Na dotaz | Zadat poptávku | |
| A08 WHR55870 |
C00501116
483286008863 |
Foot ,rubber | Na dotaz | Zadat poptávku | |
| A09 WHR55870 |
C00341442
483286008121 |
Pin hinge | Na dotaz | Zadat poptávku | |
| A10 WHR55870 |
C00339856
483286008122 |
Hinge | Na dotaz | Zadat poptávku | |
| A11 WHR55870 |
C00517726
483286008864 |
Side panel ,right | Na dotaz | Zadat poptávku | |
| A12 WHR55870 |
C00496295
483286008865 |
Side panel ,left | Na dotaz | Zadat poptávku | |
| A13 WHR55870 |
C00524367
483286001385 |
Panel ,BACK | Na dotaz | Zadat poptávku | |
| A14 WHR55870 |
C00338037
483286008135 |
Nut | Na dotaz | Zadat poptávku | |
| A15 WHR55870 |
C00524368
483286001386 |
Cover plate | Na dotaz | Zadat poptávku | |
| A16 WHR55870 |
C00517727
483286008868 |
Plinth | Na dotaz | Zadat poptávku | |
| A17 WHR55870 |
C00335460
483286008131 |
tyč spojovací | 1 315 Kč
€ 51.90 |
||
| A18 WHR55870 |
C00337753
483286008133 |
Plate tie rod | Na dotaz | Zadat poptávku | |
| A19 WHR55870 |
C00344331
483286008134 |
Bolt | Na dotaz | Zadat poptávku | |
| B02 WHR55870 |
C00502943
483286001387 |
Boiler | Na dotaz | Zadat poptávku | |
| B03 WHR55870 |
C00501036
483286000124 |
Topení myčky AGB | 4 032 Kč
€ 159.00 |
||
| B04 WHR55870 |
C00318788
483286008816 |
Dávkovač oplachu | 2 405 Kč
€ 94.90 |
||
| B05 WHR55870 |
C00335535
483286008149 |
Thermostat | Na dotaz | Zadat poptávku | |
| B06 WHR55870 |
C00338536
483286008153 |
Knob | Na dotaz | Zadat poptávku | |
| B07 WHR55870 |
C00335524
483286008871 |
Thermostat 0 - 90°C | 1 642 Kč
€ 64.80 |
||
| B08 WHR55870 |
C00335477
483286008151 |
Thermostat TANK | Na dotaz | Zadat poptávku | |
| B09 WHR55870 |
C00500400
483286008872 |
Gasket | Na dotaz | Zadat poptávku | |
| B10 WHR55870 |
C00338013
483286008873 |
Nut 1¼'' | Na dotaz | Zadat poptávku | |
| B11 WHR55870 |
C00517729
483286008874 |
Bearing ,el. valve | Na dotaz | Zadat poptávku | |
| B12 WHR55870 |
C00503472
483286008875 |
Terminal Board | Na dotaz | Zadat poptávku | |
| B12 WHR55870 |
C00517730
483286008876 |
Power cable | Na dotaz | Zadat poptávku | |
| B13 WHR55870 |
C00337304
483286008141 |
1-WAY SOLENOID VALVE D10 | Na dotaz | Zadat poptávku | |
| B14 WHR55870 |
C00337387
483286008163 |
Tube bend inlet | Na dotaz | Zadat poptávku | |
| B15 WHR55870 |
C00524240
483286000992 |
Pipette | Na dotaz | Zadat poptávku | |
| B16 WHR55870 |
C00339249
483286008167 |
Hose rubber | Na dotaz | Zadat poptávku | |
| B17 WHR55870 |
C00335965
483286008156 |
Strap 13 - 20mm | Na dotaz | Zadat poptávku | |
| B18 WHR55870 |
C00335975
483286008147 |
Strap | Na dotaz | Zadat poptávku | |
| B19 WHR55870 |
C00502942
483286000991 |
Funnel ,rinse pump | Na dotaz | Zadat poptávku | |
| B20 WHR55870 |
C00501057
483286000485 |
Inlet ,ELBOW | Na dotaz | Zadat poptávku | |
| B21 WHR55870 |
C00373915
483286000989 |
Pump | Na dotaz | Zadat poptávku | |
| B22 WHR55870 |
C00340204
483286008919 |
Grommet | Na dotaz | Zadat poptávku | |
| B23 WHR55870 |
C00339400
483286008798 |
Hose ,pressostat | Na dotaz | Zadat poptávku | |
| B24 WHR55870 |
C00341418
483286008818 |
Pipe 4x7 | Na dotaz | Zadat poptávku | |
| B25 WHR55870 |
C00336567
483286008138 |
Screw M8x12 | Na dotaz | Zadat poptávku | |
| B26 WHR55870 |
C00337970
483286008137 |
O-Ring | Na dotaz | Zadat poptávku | |
| B27 WHR55870 |
C00335862
483286008937 |
Support ,thermostat. | Na dotaz | Zadat poptávku | |
| B28 WHR55870 |
C00379059
483286001388 |
Fitting | Na dotaz | Zadat poptávku | |
| B29 WHR55870 |
C00502646
483286001389 |
Nut | Na dotaz | Zadat poptávku | |
| B30 WHR55870 |
C00581676
483286000127 |
Pump | Na dotaz | Zadat poptávku | |
| B31 WHR55870 |
C00339368
483286000128 |
Hose draining d19 90° 2000 PS + CURVA | Na dotaz | Zadat poptávku | |
| B32 WHR55870 |
C00503428
483286000131 |
Inlet ,ELBOW | Na dotaz | Zadat poptávku | |
| B33 WHR55870 |
C00341421
483286000502 |
tryska - nátrubek | 1 854 Kč
€ 73.10 |
||
| B34 WHR55870 |
C00421486
483286003391 |
Filter, weight DET./BRILL. | Na dotaz | Zadat poptávku | |
| B35 WHR55870 |
C00497100
483286000996 |
Pipe | Na dotaz | Zadat poptávku | |
| B36 WHR55870 |
C00339444
483286008155 |
TRANSPARENT HOSE 4X7 | Na dotaz | Zadat poptávku | |
| B37 WHR55870 |
C00497214
483286000995 |
Čerpadlo detergentu profi myčka Whirlpool | 5 320 Kč
€ 209.80 |
||
| C01 WHR55870 |
C00495326
483286001391 |
Heating element 2000 W | Na dotaz | Zadat poptávku | |
| C02 WHR55870 |
C00373912
483286008878 |
Čerpadlo | 7 916 Kč
€ 312.20 |
||
| C03 WHR55870 |
C00517713
483286000142 |
Outlet elbow | Na dotaz | Zadat poptávku | |
| C05 WHR55870 |
C00338006
483286008374 |
Nut 3/8 inch | Na dotaz | Zadat poptávku | |
| C06 WHR55870 |
C00517733
483286008881 |
Pipe | Na dotaz | Zadat poptávku | |
| C07 WHR55870 |
C00517734
483286008882 |
Inlet | Na dotaz | Zadat poptávku | |
| C08 WHR55870 |
C00343385
483286008171 |
Clamp 38-50mmm | Na dotaz | Zadat poptávku | |
| C09 WHR55870 |
C00340540
483286008162 |
Gasket | Na dotaz | Zadat poptávku | |
| C10 WHR55870 |
C00344555
483286008161 |
Airtrap-náhrada 482000020120 | Na dotaz | Zadat poptávku | |
| C13 WHR55870 |
C00335614
483286008166 |
T-adapter | Na dotaz | Zadat poptávku | |
| C14 WHR55870 |
C00501118
483286008884 |
Stopper | Na dotaz | Zadat poptávku | |
| C15 WHR55870 |
C00517735
483286008885 |
Reductor | Na dotaz | Zadat poptávku | |
| C16 WHR55870 |
C00341423
483286008811 |
Pipe ,fitting | Na dotaz | Zadat poptávku | |
| C17 WHR55870 |
C00500555
483286008886 |
Pipe ,outlet upper | Na dotaz | Zadat poptávku | |
| C18 WHR55870 |
C00373914
483286001208 |
Hub ,UPPER | Na dotaz | Zadat poptávku | |
| C19 WHR55870 |
C00517736
483286008887 |
Pin ,rinse | Na dotaz | Zadat poptávku | |
| C20 WHR55870 |
C00517737
483286008888 |
Tube bend 1¼'' | Na dotaz | Zadat poptávku | |
| C21 WHR55870 |
C00337973
483286008173 |
O-Ring | Na dotaz | Zadat poptávku | |
| C22 WHR55870 |
C00338016
483286008172 |
Nut 1" | Na dotaz | Zadat poptávku | |
| C23 WHR55870 |
C00500402
483286008889 |
Spacer | Na dotaz | Zadat poptávku | |
| C24 WHR55870 |
C00373916
483286000143 |
Filter | Na dotaz | Zadat poptávku | |
| C25 WHR55870 |
C00339181
483286008806 |
Hub ,washing/rinse | Na dotaz | Zadat poptávku | |
| C26 WHR55870 |
C00340175
483286008807 |
Guide | Na dotaz | Zadat poptávku | |
| C27 WHR55870 |
C00500314
483286008956 |
Flange | Na dotaz | Zadat poptávku | |
| C28 WHR55870 |
C00517738
483286008892 |
Screw M6x10 | Na dotaz | Zadat poptávku | |
| C29 WHR55870 |
C00517739
483286008893 |
Nut 1"3/4 | Na dotaz | Zadat poptávku | |
| C30 WHR55870 |
C00343384
483286008783 |
Clamp 44-56mm | Na dotaz | Zadat poptávku | |
| C31 WHR55870 |
C00337242
483286008809 |
Washer | Na dotaz | Zadat poptávku | |
| C32 WHR55870 |
C00500404
483286008895 |
Cover ,Tube bend | Na dotaz | Zadat poptávku | |
| C33 WHR55870 |
C00337986
483286008176 |
Nut ring | Na dotaz | Zadat poptávku | |
| C34 WHR55870 |
C00500403
483286008894 |
Tube bend | Na dotaz | Zadat poptávku | |
| C35 WHR55870 |
C00500305
483286008897 |
Gasket | Na dotaz | Zadat poptávku | |
| C36 WHR55870 |
C00336682
483286008974 |
Screw | Na dotaz | Zadat poptávku | |
| C37 WHR55870 |
C00337237
483286008757 |
Washer | Na dotaz | Zadat poptávku | |
| C38 WHR55870 |
C00340539
483286008902 |
Gasket | Na dotaz | Zadat poptávku | |
| C39 WHR55870 |
C00337991
483286008903 |
Nut M10 | Na dotaz | Zadat poptávku | |
| D01 WHR55870 |
C00339184
483286008189 |
Nátrubek mycího ramene | 2 654 Kč
€ 104.70 |
||
| D02 WHR55870 |
C00337267
483286008828 |
rameno horní | 6 132 Kč
€ 241.80 |
||
| D03 WHR55870 |
C00340917
483286008179 |
naboj | 2 180 Kč
€ 86.00 |
||
| D04 WHR55870 |
C00339185
483286008192 |
Hub | Na dotaz | Zadat poptávku | |
| D05 WHR55870 |
C00336816
483286008418 |
Tryska mycího ramene poloprofesionální myčky | 825 Kč
€ 32.50 |
||
| D06 WHR55870 |
C00336575
483286008317 |
Screw M4 X 8 | Na dotaz | Zadat poptávku | |
| D07 WHR55870 |
C00337974
483286008318 |
O-RING3 | 1 192 Kč
€ 47.00 |
||
| D08 WHR55870 |
C00335606
483286008322 |
Tailpiece rinse arm | Na dotaz | Zadat poptávku | |
| D09 WHR55870 |
C00337987
483286008323 |
Šroub ramene | 1 176 Kč
€ 46.40 |
||
| D10 WHR55870 |
C00336820
483286008829 |
Rinse arm ,right | Na dotaz | Zadat poptávku | |
| D11 WHR55870 |
C00336821
483286008831 |
Rinse arm ,left | Na dotaz | Zadat poptávku | |
| D12 WHR55870 |
C00337975
483286008324 |
Těsnění | 852 Kč
€ 33.60 |
||
| D13 WHR55870 |
C00517741
483286008904 |
WASH ARM | Na dotaz | Zadat poptávku | |
| D14 WHR55870 |
C00336822
483286008833 |
Rinse arm ,cpl. | Na dotaz | Zadat poptávku | |
| D15 WHR55870 |
C00337636
483286008834 |
Plug | Na dotaz | Zadat poptávku | |
| D16 WHR55870 |
C00337976
483286008835 |
O-Ring | Na dotaz | Zadat poptávku | |
| E01 WHR55870 |
C00503447
483286001405 |
Tank ,BREAK | Na dotaz | Zadat poptávku | |
| E02 WHR55870 |
C00524369
483286001392 |
Cover | Na dotaz | Zadat poptávku | |
| E04 WHR55870 |
C00497108
483286001393 |
Gasket | Na dotaz | Zadat poptávku | |
| E05 WHR55870 |
C00502944
483286001394 |
Pipe ,fitting | Na dotaz | Zadat poptávku | |
| E06 WHR55870 |
C00581792
483286001395 |
Cover | Na dotaz | Zadat poptávku | |
| E10 WHR55870 |
C00524370
483286001396 |
Fitting | Na dotaz | Zadat poptávku | |
| E13 WHR55870 |
C00524374
483286001403 |
Guard ,spray | Na dotaz | Zadat poptávku | |
| E15 WHR55870 |
C00524375
483286001404 |
Funnel | Na dotaz | Zadat poptávku | |
| E17 WHR55870 |
C00524371
483286001397 |
Spring | Na dotaz | Zadat poptávku | |
| F01 WHR55870 |
C00502945
483286001398 |
Plate | Na dotaz | Zadat poptávku | |
| F02 WHR55870 |
C00503436
483286000471 |
Panel PRINTED | Na dotaz | Zadat poptávku | |
| F03 WHR55870 |
C00341828
483286008331 |
Lamp control | Na dotaz | Zadat poptávku | |
| F04 WHR55870 |
C00341826
483286008333 |
světlo | 965 Kč
€ 38.10 |
||
| F05 WHR55870 |
C00344047
483286008921 |
tlačítko | 965 Kč
€ 38.10 |
||
| F06 WHR55870 |
C00341012
483286008922 |
pouzdro tlacitka | 1 042 Kč
€ 41.10 |
||
| F07 WHR55870 |
C00335757
483286008908 |
Switch | Na dotaz | Zadat poptávku | |
| F08 WHR55870 |
C00497109
483286001399 |
Sensor | Na dotaz | Zadat poptávku | |
| F09 WHR55870 |
C00517743
483286008909 |
Sensor | Na dotaz | Zadat poptávku | |
| F10 WHR55870 |
C00337564
483286008334 |
Pressostat | Na dotaz | Zadat poptávku | |
| F11 WHR55870 |
C00524372
483286001401 |
Terminal Board | Na dotaz | Zadat poptávku | |
| F12 WHR55870 |
C00524373
483286001402 |
Terminal Board | Na dotaz | Zadat poptávku | |
| F13 WHR55870 |
C00384761
483286008913 |
Terminal Board | Na dotaz | Zadat poptávku | |
| F14 WHR55870 |
C00502949
483286008914 |
Filter ,noise | Na dotaz | Zadat poptávku | |
| F15 WHR55870 |
C00336888
483286008915 |
Relay | Na dotaz | Zadat poptávku | |
| F16 WHR55870 |
C00335433
483286008916 |
Timer ,cycle | Na dotaz | Zadat poptávku | |
| F17 WHR55870 |
C00337024
483286008917 |
Spínač | 936 Kč
€ 36.90 |
||
| F18 WHR55870 |
C00335758
483286008918 |
SPINAC | 1 275 Kč
€ 50.30 |
||
| F20 WHR55870 |
C00373913
483286003664 |
Timer electronic | Na dotaz | Zadat poptávku | |
