WHIRLPOOL AGB 657/WP Dishwasher with square bas
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | AGB 657/WP Dishwasher with square bas |
| Kód 12NC: | 851265701000 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Profesionální domácí čištění |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| A01 WHR60278 |
C00422377
483286008923 |
Frame | Na dotaz | Zadat poptávku | |
| A02 WHR60278 |
C00517745
483286008924 |
Tank | Na dotaz | Zadat poptávku | |
| A03 WHR60278 |
C00517746
483286008925 |
Door | Na dotaz | Zadat poptávku | |
| A04 WHR60278 |
C00342109
483286008118 |
Door catch | Na dotaz | Zadat poptávku | |
| A05 WHR60278 |
C00338000
483286008119 |
Nut catch | Na dotaz | Zadat poptávku | |
| A06 WHR60278 |
C00338315
483286008861 |
Magnet ,cover | Na dotaz | Zadat poptávku | |
| A07 WHR60278 |
C00340116
483286008862 |
Handle | Na dotaz | Zadat poptávku | |
| A08 WHR60278 |
C00517747
483286008926 |
Hinge ,left | Na dotaz | Zadat poptávku | |
| A09 WHR60278 |
C00497220
483286008927 |
Hinge ,right | Na dotaz | Zadat poptávku | |
| A10 WHR60278 |
C00501119
483286008928 |
Spring | Na dotaz | Zadat poptávku | |
| A11 WHR60278 |
C00501116
483286008863 |
Foot ,rubber | Na dotaz | Zadat poptávku | |
| A12 WHR60278 |
C00517748
483286008929 |
Side panel ,right | Na dotaz | Zadat poptávku | |
| A13 WHR60278 |
C00517749
483286008931 |
Side panel ,left | Na dotaz | Zadat poptávku | |
| A14 WHR60278 |
C00517750
483286008932 |
Panel rear | Na dotaz | Zadat poptávku | |
| A15 WHR60278 |
C00517751
483286008933 |
Cover plate | Na dotaz | Zadat poptávku | |
| A16 WHR60278 |
C00517752
483286008934 |
Plinth | Na dotaz | Zadat poptávku | |
| A17 WHR60278 |
C00517753
483286008935 |
Gasket | Na dotaz | Zadat poptávku | |
| B01 WHR60278 |
C00502950
483286008936 |
Boiler | Na dotaz | Zadat poptávku | |
| B02 WHR60278 |
C00339911
483286008813 |
Heating element 6kW 230V | Na dotaz | Zadat poptávku | |
| B03 WHR60278 |
C00337971
483286008139 |
Těsnění, O kroužek topení profesionální myčky Whirlpool | 966 Kč
€ 38.10 |
||
| B04 WHR60278 |
C00335535
483286008149 |
Thermostat | Na dotaz | Zadat poptávku | |
| B05 WHR60278 |
C00338536
483286008153 |
Knob | Na dotaz | Zadat poptávku | |
| B06 WHR60278 |
C00335524
483286008871 |
Thermostat 0 - 90°C | 1 642 Kč
€ 64.80 |
||
| B07 WHR60278 |
C00335862
483286008937 |
Support ,thermostat. | Na dotaz | Zadat poptávku | |
| B08 WHR60278 |
C00335477
483286008151 |
Thermostat TANK | Na dotaz | Zadat poptávku | |
| B09 WHR60278 |
C00500400
483286008872 |
Gasket | Na dotaz | Zadat poptávku | |
| B10 WHR60278 |
C00338013
483286008873 |
Nut 1¼'' | Na dotaz | Zadat poptávku | |
| B11 WHR60278 |
C00318788
483286008816 |
Dávkovač oplachu | 2 405 Kč
€ 94.90 |
||
| B12 WHR60278 |
C00341418
483286008818 |
Pipe 4x7 | Na dotaz | Zadat poptávku | |
| B13 WHR60278 |
C00339400
483286008798 |
Hose ,pressostat | Na dotaz | Zadat poptávku | |
| B14 WHR60278 |
C00517754
483286008938 |
Grommet | Na dotaz | Zadat poptávku | |
| B15 WHR60278 |
C00337307
483286008154 |
Valve | Na dotaz | Zadat poptávku | |
| B16 WHR60278 |
C00335965
483286008156 |
Strap 13 - 20mm | Na dotaz | Zadat poptávku | |
| B17 WHR60278 |
C00339249
483286008167 |
Hose rubber | Na dotaz | Zadat poptávku | |
| B18 WHR60278 |
C00500401
483286008883 |
Capacitor | Na dotaz | Zadat poptávku | |
| B19 WHR60278 |
C00340204
483286008919 |
Grommet | Na dotaz | Zadat poptávku | |
| B20 WHR60278 |
C00384761
483286008913 |
Terminal Board | Na dotaz | Zadat poptávku | |
| B21 WHR60278 |
C00517755
483286008939 |
Bearing ,el. valve | Na dotaz | Zadat poptávku | |
| B22 WHR60278 |
C00337387
483286008163 |
Tube bend inlet | Na dotaz | Zadat poptávku | |
| B23 WHR60278 |
C00337304
483286008141 |
1-WAY SOLENOID VALVE D10 | Na dotaz | Zadat poptávku | |
| B24 WHR60278 |
C00335615
483286008817 |
T-adapter | Na dotaz | Zadat poptávku | |
| B25 WHR60278 |
C00337970
483286008137 |
O-Ring | Na dotaz | Zadat poptávku | |
| B26 WHR60278 |
C00336567
483286008138 |
Screw M8x12 | Na dotaz | Zadat poptávku | |
| C01 WHR60278 |
C00497221
483286008941 |
Heating element | Na dotaz | Zadat poptávku | |
| C02 WHR60278 |
C00500228
483286008942 |
Heating element ,protection | Na dotaz | Zadat poptávku | |
| C03 WHR60278 |
C00497222
483286008943 |
Pump | Na dotaz | Zadat poptávku | |
| C04 WHR60278 |
C00517756
483286008944 |
Tube bend | Na dotaz | Zadat poptávku | |
| C05 WHR60278 |
C00343385
483286008171 |
Clamp 38-50mmm | Na dotaz | Zadat poptávku | |
| C06 WHR60278 |
C00517757
483286008945 |
Support ,pump | Na dotaz | Zadat poptávku | |
| C07 WHR60278 |
C00501120
483286008946 |
Water collector | Na dotaz | Zadat poptávku | |
| C08 WHR60278 |
C00517758
483286008947 |
Screw | Na dotaz | Zadat poptávku | |
| C09 WHR60278 |
C00517759
483286008948 |
Gasket | Na dotaz | Zadat poptávku | |
| C10 WHR60278 |
C00335975
483286008147 |
Strap | Na dotaz | Zadat poptávku | |
| C11 WHR60278 |
C00517760
483286008949 |
Pipe ,outlet | Na dotaz | Zadat poptávku | |
| C12 WHR60278 |
C00344556
483286008796 |
Airtrap | Na dotaz | Zadat poptávku | |
| C13 WHR60278 |
C00340494
483286008794 |
Gasket ,Air trap | Na dotaz | Zadat poptávku | |
| C14 WHR60278 |
C00338341
483286008795 |
Link , Air trap | Na dotaz | Zadat poptávku | |
| C15 WHR60278 |
C00373911
483286008891 |
Nátrubek myčky | 1 108 Kč
€ 43.70 |
||
| C16 WHR60278 |
C00340175
483286008807 |
Guide | Na dotaz | Zadat poptávku | |
| C17 WHR60278 |
C00517761
483286008951 |
Spacer | Na dotaz | Zadat poptávku | |
| C18 WHR60278 |
C00341423
483286008811 |
Pipe ,fitting | Na dotaz | Zadat poptávku | |
| C19 WHR60278 |
C00517762
483286008952 |
Stopper | Na dotaz | Zadat poptávku | |
| C20 WHR60278 |
C00517733
483286008881 |
Pipe | Na dotaz | Zadat poptávku | |
| C21 WHR60278 |
C00517763
483286008953 |
Pipe ,outlet upper | Na dotaz | Zadat poptávku | |
| C22 WHR60278 |
C00517764
483286008954 |
Filter | Na dotaz | Zadat poptávku | |
| C23 WHR60278 |
C00517736
483286008887 |
Pin ,rinse | Na dotaz | Zadat poptávku | |
| C24 WHR60278 |
C00517765
483286008955 |
Screw | Na dotaz | Zadat poptávku | |
| C25 WHR60278 |
C00500314
483286008956 |
Flange | Na dotaz | Zadat poptávku | |
| C27 WHR60278 |
C00339181
483286008806 |
Hub ,washing/rinse | Na dotaz | Zadat poptávku | |
| C29 WHR60278 |
C00335614
483286008166 |
T-adapter | Na dotaz | Zadat poptávku | |
| C31 WHR60278 |
C00501121
483286008957 |
Filter | Na dotaz | Zadat poptávku | |
| C32 WHR60278 |
C00517766
483286008958 |
Over flow SPC | Na dotaz | Zadat poptávku | |
| C33 WHR60278 |
C00385107
483286008899 |
O-Ring | Na dotaz | Zadat poptávku | |
| D01 WHR60278 |
C00339184
483286008189 |
Nátrubek mycího ramene | 2 654 Kč
€ 104.80 |
||
| D02 WHR60278 |
C00337267
483286008828 |
rameno horní | 6 132 Kč
€ 242.10 |
||
| D03 WHR60278 |
C00340917
483286008179 |
naboj | 2 180 Kč
€ 86.10 |
||
| D04 WHR60278 |
C00339185
483286008192 |
Hub | Na dotaz | Zadat poptávku | |
| D05 WHR60278 |
C00336816
483286008418 |
Tryska mycího ramene poloprofesionální myčky | 825 Kč
€ 32.60 |
||
| D06 WHR60278 |
C00336575
483286008317 |
Screw M4 X 8 | Na dotaz | Zadat poptávku | |
| D07 WHR60278 |
C00337974
483286008318 |
O-RING3 | 1 192 Kč
€ 47.10 |
||
| D08 WHR60278 |
C00335606
483286008322 |
Tailpiece rinse arm | Na dotaz | Zadat poptávku | |
| D09 WHR60278 |
C00337987
483286008323 |
Šroub ramene | 1 176 Kč
€ 46.40 |
||
| D10 WHR60278 |
C00336820
483286008829 |
Rinse arm ,right | Na dotaz | Zadat poptávku | |
| D11 WHR60278 |
C00336821
483286008831 |
Rinse arm ,left | Na dotaz | Zadat poptávku | |
| D12 WHR60278 |
C00337975
483286008324 |
Těsnění | 852 Kč
€ 33.60 |
||
| D13 WHR60278 |
C00517741
483286008904 |
WASH ARM | Na dotaz | Zadat poptávku | |
| D14 WHR60278 |
C00336822
483286008833 |
Rinse arm ,cpl. | Na dotaz | Zadat poptávku | |
| D15 WHR60278 |
C00337976
483286008835 |
O-Ring | Na dotaz | Zadat poptávku | |
| D16 WHR60278 |
C00337636
483286008834 |
Plug | Na dotaz | Zadat poptávku | |
| E01 WHR60278 |
C00581963
483286008959 |
Control panel | Na dotaz | Zadat poptávku | |
| E02 WHR60278 |
C00503473
483286008906 |
Panel ,printed | Na dotaz | Zadat poptávku | |
| E03 WHR60278 |
C00335757
483286008908 |
Switch | Na dotaz | Zadat poptávku | |
| E04 WHR60278 |
C00341012
483286008922 |
pouzdro tlacitka | 1 042 Kč
€ 41.10 |
||
| E05 WHR60278 |
C00344047
483286008921 |
tlačítko | 965 Kč
€ 38.10 |
||
| E06 WHR60278 |
C00341828
483286008331 |
Lamp control | Na dotaz | Zadat poptávku | |
| E07 WHR60278 |
C00337024
483286008917 |
Spínač | 936 Kč
€ 37.00 |
||
| E08 WHR60278 |
C00341826
483286008333 |
světlo | 965 Kč
€ 38.10 |
||
| E09 WHR60278 |
C00335758
483286008918 |
SPINAC | 1 275 Kč
€ 50.30 |
||
| E10 WHR60278 |
C00342725
483286008341 |
Contact inductive | Na dotaz | Zadat poptávku | |
| E11 WHR60278 |
C00517743
483286008909 |
Sensor | Na dotaz | Zadat poptávku | |
| E12 WHR60278 |
C00517744
483286008911 |
Terminal Board | Na dotaz | Zadat poptávku | |
| E13 WHR60278 |
C00503474
483286008912 |
Terminal Board | Na dotaz | Zadat poptávku | |
| E15 WHR60278 |
C00340952
483286008841 |
Filter ,noise. | Na dotaz | Zadat poptávku | |
| E16 WHR60278 |
C00501122
483286008961 |
Relay | Na dotaz | Zadat poptávku | |
| E17 WHR60278 |
C00621168
483286008962 |
Timer | Na dotaz | Zadat poptávku | |
| E18 WHR60278 |
C00497223
483286008963 |
Switch,pushbut. | Na dotaz | Zadat poptávku | |
