WHIRLPOOL AGB 666/WP
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | AGB 666/WP |
| Kód 12NC: | 851266601000 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Profesionální domácí čištění |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| A01 WHR43218 |
C00422375
483286008847 |
Frame | Na dotaz | Zadat poptávku | |
| A02 WHR43218 |
C00340796
483286008744 |
Foot rubber | Na dotaz | Zadat poptávku | |
| A03 WHR43218 |
C00524290
483286001172 |
Tank | Na dotaz | Zadat poptávku | |
| A04 WHR43218 |
C00524792
483286008746 |
Stay ,back right | Na dotaz | Zadat poptávku | |
| A05 WHR43218 |
C00524793
483286008747 |
Stay ,back left | Na dotaz | Zadat poptávku | |
| A06 WHR43218 |
C00501112
483286008748 |
Bearing | Na dotaz | Zadat poptávku | |
| A07 WHR43218 |
C00524815
483286008848 |
Holder | Na dotaz | Zadat poptávku | |
| A08 WHR43218 |
C00524816
483286008849 |
Cover | Na dotaz | Zadat poptávku | |
| A09 WHR43218 |
C00524794
483286008749 |
Bearing | Na dotaz | Zadat poptávku | |
| A10 WHR43218 |
C00524291
483286001173 |
Handle | Na dotaz | Zadat poptávku | |
| A11 WHR43218 |
C00337190
483286008752 |
Wheel | Na dotaz | Zadat poptávku | |
| A12 WHR43218 |
C00341459
483286008753 |
PIVOT FOR RAISING HOOD E1000/N1000/N1300 | Na dotaz | Zadat poptávku | |
| A13 WHR43218 |
C00581959
483286008754 |
Rod ,connecting | Na dotaz | Zadat poptávku | |
| A14 WHR43218 |
C00336106
483286008755 |
Pružina | 4 131 Kč
€ 163.10 |
||
| A15 WHR43218 |
C00524795
483286008756 |
Nut | Na dotaz | Zadat poptávku | |
| A16 WHR43218 |
C00337237
483286008757 |
Washer | Na dotaz | Zadat poptávku | |
| A17 WHR43218 |
C00337241
483286008758 |
Washer | Na dotaz | Zadat poptávku | |
| A18 WHR43218 |
C00524796
483286008759 |
Support ,micro | Na dotaz | Zadat poptávku | |
| A19 WHR43218 |
C00497167
483286001174 |
Sensor | Na dotaz | Zadat poptávku | |
| A20 WHR43218 |
C00384679
483286008762 |
Magnet ,cover | Na dotaz | Zadat poptávku | |
| A21 WHR43218 |
C00524817
483286008851 |
Plate | Na dotaz | Zadat poptávku | |
| A22 WHR43218 |
C00524818
483286008852 |
Plate handle | Na dotaz | Zadat poptávku | |
| A23 WHR43218 |
C00524797
483286008763 |
Spacer | Na dotaz | Zadat poptávku | |
| A24 WHR43218 |
C00524798
483286008764 |
Insulation ,frontal | Na dotaz | Zadat poptávku | |
| A25 WHR43218 |
C00581960
483286008765 |
Card ,control | Na dotaz | Zadat poptávku | |
| A26 WHR43218 |
C00524799
483286008766 |
Insulation ,cover | Na dotaz | Zadat poptávku | |
| A27 WHR43218 |
C00524800
483286008767 |
Insulation ,cover | Na dotaz | Zadat poptávku | |
| A28 WHR43218 |
C00524801
483286008768 |
Insulation ,lateral | Na dotaz | Zadat poptávku | |
| A29 WHR43218 |
C00524802
483286008769 |
Crosspiece ,upper back | Na dotaz | Zadat poptávku | |
| A30 WHR43218 |
C00503471
483286008771 |
Panel ,back | Na dotaz | Zadat poptávku | |
| A31 WHR43218 |
C00524803
483286008772 |
Insulation ,upper back | Na dotaz | Zadat poptávku | |
| A32 WHR43218 |
C00524804
483286008773 |
Support ,spring | Na dotaz | Zadat poptávku | |
| A33 WHR43218 |
C00341454
483286008774 |
Pin ,split | Na dotaz | Zadat poptávku | |
| A34 WHR43218 |
C00336683
483286000086 |
Screw | Na dotaz | Zadat poptávku | |
| A35 WHR43218 |
C00497168
483286001175 |
Gasket | Na dotaz | Zadat poptávku | |
| B01 WHR43218 |
C00501069
483286001176 |
Pump 1,1 Kw 400/3/50 N1300 | Na dotaz | Zadat poptávku | |
| B02 WHR43218 |
C00524292
483286001177 |
Support ,PUMP | Na dotaz | Zadat poptávku | |
| B03 WHR43218 |
C00383438
483286008854 |
Panel rear | Na dotaz | Zadat poptávku | |
| B04 WHR43218 |
C00581752
483286001178 |
Inlet ,ELBOW | Na dotaz | Zadat poptávku | |
| B05 WHR43218 |
C00524293
483286001179 |
Outlet elbow | Na dotaz | Zadat poptávku | |
| B06 WHR43218 |
C00524294
483286001181 |
hadice | 1 427 Kč
€ 56.30 |
||
| B07 WHR43218 |
C00343385
483286008171 |
Clamp 38-50mmm | Na dotaz | Zadat poptávku | |
| B08 WHR43218 |
C00343391
483286008782 |
Clamp | Na dotaz | Zadat poptávku | |
| B09 WHR43218 |
C00343384
483286008783 |
Clamp 44-56mm | Na dotaz | Zadat poptávku | |
| B10 WHR43218 |
C00524807
483286008784 |
Pipe ,WASHING | Na dotaz | Zadat poptávku | |
| B11 WHR43218 |
C00337391
483286008785 |
Tube bend | Na dotaz | Zadat poptávku | |
| B12 WHR43218 |
C00337977
483286008786 |
O-Ring | Na dotaz | Zadat poptávku | |
| B13 WHR43218 |
C00524295
483286001182 |
Hub | Na dotaz | Zadat poptávku | |
| B14 WHR43218 |
C00497101
483286001183 |
Gasket | Na dotaz | Zadat poptávku | |
| B15 WHR43218 |
C00524296
483286001184 |
Nut | Na dotaz | Zadat poptávku | |
| B16 WHR43218 |
C00337392
483286008787 |
Tube bend | Na dotaz | Zadat poptávku | |
| B17 WHR43218 |
C00337973
483286008173 |
O-Ring | Na dotaz | Zadat poptávku | |
| B18 WHR43218 |
C00338016
483286008172 |
Nut 1" | Na dotaz | Zadat poptávku | |
| B19 WHR43218 |
C00339377
483286008788 |
hadice | 2 164 Kč
€ 85.40 |
||
| B20 WHR43218 |
C00497102
483286001185 |
OVER FLOW SPC | Na dotaz | Zadat poptávku | |
| B21 WHR43218 |
C00344127
483286008791 |
Bulb ,seating | Na dotaz | Zadat poptávku | |
| B22 WHR43218 |
C00340543
483286008792 |
Gasket | Na dotaz | Zadat poptávku | |
| B23 WHR43218 |
C00338039
483286008793 |
Nut | Na dotaz | Zadat poptávku | |
| B24 WHR43218 |
C00340494
483286008794 |
Gasket ,Air trap | Na dotaz | Zadat poptávku | |
| B25 WHR43218 |
C00338341
483286008795 |
Link , Air trap | Na dotaz | Zadat poptávku | |
| B26 WHR43218 |
C00344556
483286008796 |
Airtrap | Na dotaz | Zadat poptávku | |
| B27 WHR43218 |
C00339400
483286008798 |
Hose ,pressostat | Na dotaz | Zadat poptávku | |
| B28 WHR43218 |
C00497103
483286001186 |
Switch,pushbut. | Na dotaz | Zadat poptávku | |
| B29 WHR43218 |
C00339938
483286008799 |
topení | 4 186 Kč
€ 165.30 |
||
| B30 WHR43218 |
C00335614
483286008166 |
T-adapter | Na dotaz | Zadat poptávku | |
| B31 WHR43218 |
C00339249
483286008167 |
Hose rubber | Na dotaz | Zadat poptávku | |
| B32 WHR43218 |
C00341422
483286008802 |
Pipe ,fitting | Na dotaz | Zadat poptávku | |
| B33 WHR43218 |
C00335965
483286008156 |
Strap 13 - 20mm | Na dotaz | Zadat poptávku | |
| B34 WHR43218 |
C00340541
483286008158 |
Gasket | Na dotaz | Zadat poptávku | |
| B35 WHR43218 |
C00524808
483286008803 |
Filter ,intake | Na dotaz | Zadat poptávku | |
| B36 WHR43218 |
C00524809
483286008804 |
Filter , tank | Na dotaz | Zadat poptávku | |
| B37 WHR43218 |
C00524810
483286008805 |
Filter ,drawer | Na dotaz | Zadat poptávku | |
| B38 WHR43218 |
C00524819
483286008853 |
Guide | Na dotaz | Zadat poptávku | |
| B39 WHR43218 |
C00524297
483286001187 |
Washer | Na dotaz | Zadat poptávku | |
| B40 WHR43218 |
C00423521
483286011352 |
Resistor NTC | Na dotaz | Zadat poptávku | |
| C01 WHR43218 |
C00344334
483286008812 |
Boiler | Na dotaz | Zadat poptávku | |
| C04 WHR43218 |
C00339911
483286008813 |
Heating element 6kW 230V | Na dotaz | Zadat poptávku | |
| C05 WHR43218 |
C00336567
483286008138 |
Screw M8x12 | Na dotaz | Zadat poptávku | |
| C06 WHR43218 |
C00337970
483286008137 |
O-Ring | Na dotaz | Zadat poptávku | |
| C07 WHR43218 |
C00337304
483286008141 |
1-WAY SOLENOID VALVE D10 | Na dotaz | Zadat poptávku | |
| C08 WHR43218 |
C00344392
483286008814 |
Bearing ,electric valve | Na dotaz | Zadat poptávku | |
| C09 WHR43218 |
C00341420
483286008815 |
Pipe ,inlet | Na dotaz | Zadat poptávku | |
| C10 WHR43218 |
C00318788
483286008816 |
Dávkovač oplachu | 2 405 Kč
€ 94.90 |
||
| C11 WHR43218 |
C00335615
483286008817 |
T-adapter | Na dotaz | Zadat poptávku | |
| C12 WHR43218 |
C00337307
483286008154 |
Valve | Na dotaz | Zadat poptávku | |
| C14 WHR43218 |
C00341418
483286008818 |
Pipe 4x7 | Na dotaz | Zadat poptávku | |
| C15 WHR43218 |
C00340961
483286000105 |
Filter | Na dotaz | Zadat poptávku | |
| D02 WHR43218 |
C00501070
483286001188 |
rameno | 3 299 Kč
€ 130.20 |
||
| D03 WHR43218 |
C00340493
483286008821 |
tesneni | 782 Kč
€ 30.90 |
||
| D04 WHR43218 |
C00524812
483286008822 |
Pipe ,fitting | Na dotaz | Zadat poptávku | |
| D05 WHR43218 |
C00502655
483286008182 |
Corner piece | Na dotaz | Zadat poptávku | |
| D07 WHR43218 |
C00382487
483286001191 |
Nut | Na dotaz | Zadat poptávku | |
| D08 WHR43218 |
C00524298
483286001189 |
Rinse arm | Na dotaz | Zadat poptávku | |
| D09 WHR43218 |
C00497104
483286001192 |
Hub | Na dotaz | Zadat poptávku | |
| D10 WHR43218 |
C00581753
483286001193 |
Stopper | Na dotaz | Zadat poptávku | |
| D11 WHR43218 |
C00340917
483286008179 |
naboj | 2 180 Kč
€ 86.10 |
||
| D12 WHR43218 |
C00337987
483286008323 |
Šroub ramene | 1 176 Kč
€ 46.40 |
||
| D13 WHR43218 |
C00339185
483286008192 |
Hub | Na dotaz | Zadat poptávku | |
| D14 WHR43218 |
C00336575
483286008317 |
Screw M4 X 8 | Na dotaz | Zadat poptávku | |
| D15 WHR43218 |
C00336820
483286008829 |
Rinse arm ,right | Na dotaz | Zadat poptávku | |
| D16 WHR43218 |
C00336821
483286008831 |
Rinse arm ,left | Na dotaz | Zadat poptávku | |
| D17 WHR43218 |
C00337974
483286008318 |
O-RING3 | 1 192 Kč
€ 47.10 |
||
| D18 WHR43218 |
C00335606
483286008322 |
Tailpiece rinse arm | Na dotaz | Zadat poptávku | |
| D19 WHR43218 |
C00337975
483286008324 |
Těsnění | 852 Kč
€ 33.60 |
||
| D20 WHR43218 |
C00336816
483286008418 |
Tryska mycího ramene poloprofesionální myčky | 825 Kč
€ 32.60 |
||
| D21 WHR43218 |
C00336822
483286008833 |
Rinse arm ,cpl. | Na dotaz | Zadat poptávku | |
| D22 WHR43218 |
C00501071
483286001194 |
Rinse arm ,CPL | Na dotaz | Zadat poptávku | |
| D23 WHR43218 |
C00524299
483286001195 |
Pin | Na dotaz | Zadat poptávku | |
| D24 WHR43218 |
C00501113
483286008824 |
Pipe | Na dotaz | Zadat poptávku | |
| D25 WHR43218 |
C00581754
483286001196 |
Stay ,WASHING PIPE | Na dotaz | Zadat poptávku | |
| E01 WHR43218 |
C00340952
483286008841 |
Filter ,noise. | Na dotaz | Zadat poptávku | |
| E02 WHR43218 |
C00335570
483286008837 |
Terminal strip | Na dotaz | Zadat poptávku | |
| E03 WHR43218 |
C00335571
483286008838 |
Terminal strip | Na dotaz | Zadat poptávku | |
| E04 WHR43218 |
C00335572
483286008839 |
Terminal strip | Na dotaz | Zadat poptávku | |
| E05 WHR43218 |
C00335535
483286008149 |
Thermostat | Na dotaz | Zadat poptávku | |
| E06 WHR43218 |
C00335583
483286008843 |
Terminal block | Na dotaz | Zadat poptávku | |
| E07 WHR43218 |
C00517743
483286008909 |
Sensor | Na dotaz | Zadat poptávku | |
| E08 WHR43218 |
C00517714
483286000504 |
Terminal Board | Na dotaz | Zadat poptávku | |
| E09 WHR43218 |
C00480967
483286008844 |
jednotka ovládací | 22 891 Kč
€ 903.70 |
||
| E10 WHR43218 |
C00524813
483286008845 |
Cabinet | Na dotaz | Zadat poptávku | |
| E11 WHR43218 |
C00524300
483286001197 |
Switchboard | Na dotaz | Zadat poptávku | |
| E12 WHR43218 |
C00524814
483286008846 |
Plate | Na dotaz | Zadat poptávku | |
