| Komerční kód: | AHO118 |
| Kód 12NC: | 850221801000 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Profesionální trouby , mikrovlnky , varné desky , konvektomaty |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 712-004-00 WHR38883 |
C00417579
482000021429 |
Grid | Na dotaz | Zadat poptávku | |
| 713-005-00 WHR38883 |
C00417541
482000021364 |
Foot | Na dotaz | Zadat poptávku | |
| 717-000-00 WHR38883 |
C00417580
482000021430 |
Burner oven | Na dotaz | Zadat poptávku | |
| 717-008-00 WHR38883 |
C00417581
482000021431 |
Spark plug oven | Na dotaz | Zadat poptávku | |
| 717-009-00 WHR38883 |
C00417582
482000021432 |
Gas cock | Na dotaz | Zadat poptávku | |
| 717-017-00 WHR38883 |
C00417583
482000021433 |
Pipe | Na dotaz | Zadat poptávku | |
| 717-018-00 WHR38883 |
C00417584
482000021434 |
Nut | Na dotaz | Zadat poptávku | |
| 717-044-00 WHR38883 |
C00417640
482000021490 |
Burner | Na dotaz | Zadat poptávku | |
| 717-045-00 WHR38883 |
C00417641
482000021491 |
Burner | Na dotaz | Zadat poptávku | |
| 717-046-00 WHR38883 |
C00417642
482000021492 |
Burner | Na dotaz | Zadat poptávku | |
| 717-054-00 WHR38883 |
C00417585
482000021435 |
Head Burner | Na dotaz | Zadat poptávku | |
| 717-062-00 WHR38883 |
C00417586
482000021436 |
Nut thermocouple | Na dotaz | Zadat poptávku | |
| 717-065-00 WHR38883 |
C00417587
482000021437 |
Injector holder | Na dotaz | Zadat poptávku | |
| 717-066-00 WHR38883 |
C00417588
482000021438 |
Nozzle Venturi | Na dotaz | Zadat poptávku | |
| 717-071-00 WHR38883 |
C00417643
482000021493 |
Spark plug | Na dotaz | Zadat poptávku | |
| 717-072-00 WHR38883 |
C00417589
482000021439 |
Plug | Na dotaz | Zadat poptávku | |
| 717-073-00 WHR38883 |
C00417590
482000021440 |
Air regulator pilot | Na dotaz | Zadat poptávku | |
| 717-075-00 WHR38883 |
C00417591
482000021441 |
Nozzle 092 LPG | Na dotaz | Zadat poptávku | |
| 717-076-00 WHR38883 |
C00417592
482000021442 |
Nozzle 0120 LPG | Na dotaz | Zadat poptávku | |
| 717-077-00 WHR38883 |
C00417593
482000021443 |
Nozzle 0140 LPG/NG | Na dotaz | Zadat poptávku | |
| 717-078-00 WHR38883 |
C00417594
482000021444 |
Nozzle 0185 NG | Na dotaz | Zadat poptávku | |
| 717-079-00 WHR38883 |
C00417595
482000021445 |
Nozzle 0220 NG | Na dotaz | Zadat poptávku | |
| 717-091-00 WHR38883 |
C00417596
482000021446 |
Nozzle 00,55 LPG | Na dotaz | Zadat poptávku | |
| 717-093-00 WHR38883 |
C00417597
482000021447 |
Nozzle 00,65 LPG | Na dotaz | Zadat poptávku | |
| 717-097-00 WHR38883 |
C00417598
482000021448 |
Nozzle 00,40 LPG | Na dotaz | Zadat poptávku | |
| 719-008-00 WHR38883 |
C00417599
482000021449 |
Thermocouple front | Na dotaz | Zadat poptávku | |
| 719-010-00 WHR38883 |
C00417600
482000021450 |
Thermocouple rear | Na dotaz | Zadat poptávku | |
| 721-042-00 WHR38883 |
C00417601
482000021451 |
Burner body | Na dotaz | Zadat poptávku | |
| 721-043-00 WHR38883 |
C00417602
482000021452 |
Burner body | Na dotaz | Zadat poptávku | |
| 721-045-00 WHR38883 |
C00417603
482000021453 |
Burner cap | Na dotaz | Zadat poptávku | |
| 721-046-00 WHR38883 |
C00417604
482000021454 |
Burner cap | Na dotaz | Zadat poptávku | |
| 721-047-00 WHR38883 |
C00417605
482000021455 |
Grid for hob | Na dotaz | Zadat poptávku | |
| 721-059-00 WHR38883 |
C00417606
482000021456 |
Burner cap | Na dotaz | Zadat poptávku | |
| 721-061-00 WHR38883 |
C00417607
482000021457 |
Burner body | Na dotaz | Zadat poptávku | |
| 721-062-00 WHR38883 |
C00417608
482000021458 |
Injector holder | Na dotaz | Zadat poptávku | |
| 727-005-00 WHR38883 |
C00417609
482000021459 |
Clamping spring | Na dotaz | Zadat poptávku | |
| 728-022-00 WHR38883 |
C00417610
482000021460 |
Burner venturi | Na dotaz | Zadat poptávku | |
| 728-023-00 WHR38883 |
C00417611
482000021461 |
Burner venturi | Na dotaz | Zadat poptávku | |
| 728-030-00 WHR38883 |
C00417612
482000021462 |
Burner venturi | Na dotaz | Zadat poptávku | |
| 761-006-00 WHR38883 |
C00417547
482000021370 |
Knob | Na dotaz | Zadat poptávku | |
| 761-011-00 WHR38883 |
C00417613
482000021463 |
Indication disc rear gas tab | Na dotaz | Zadat poptávku | |
| 761-012-00 WHR38883 |
C00417614
482000021464 |
Indication disc front gas tab | Na dotaz | Zadat poptávku | |
| 761-021-00 WHR38883 |
C00417615
482000021465 |
Indication disc oven | Na dotaz | Zadat poptávku | |
| 764-006-00 WHR38883 |
C00417616
482000021466 |
Ring | Na dotaz | Zadat poptávku | |
| 764-007-00 WHR38883 |
C00417549
482000021372 |
Gasket control panel | Na dotaz | Zadat poptávku | |
| 765-023-00 WHR38883 |
C00417550
482000021373 |
Cover protect. piezoelectric | Na dotaz | Zadat poptávku | |
| 765-024-00 WHR38883 |
C00417617
482000021467 |
Gasket silicon | Na dotaz | Zadat poptávku | |
| 774-024-00 WHR38883 |
C00417552
482000021375 |
Terminal strip | Na dotaz | Zadat poptávku | |
| 812-048-00 WHR38883 |
C00417618
482000021468 |
Air regulator oven burner | Na dotaz | Zadat poptávku | |
| 812-388-00 WHR38883 |
C00417619
482000021469 |
Grid air | Na dotaz | Zadat poptávku | |
| 816-098-00 WHR38883 |
C00417620
482000021470 |
Support burner | Na dotaz | Zadat poptávku | |
| 816-099-00 WHR38883 |
C00417621
482000021471 |
Support burner | Na dotaz | Zadat poptávku | |
| 840-048-00 WHR38883 |
C00417622
482000021472 |
Control panel | Na dotaz | Zadat poptávku | |
| 872-011-00 WHR38883 |
C00417558
482000021381 |
Extension piece Knob | Na dotaz | Zadat poptávku | |
| 872-044-00 WHR38883 |
C00417559
482000021382 |
Ring protecting piezoelectric | Na dotaz | Zadat poptávku | |
| 982-008-00 WHR38883 |
C00417623
482000021473 |
Door handle assembly | Na dotaz | Zadat poptávku | |
| AGV006ZR10 WHR38883 |
C00417624
482000021474 |
Thermocouple from SN. 74810385 | Na dotaz | Zadat poptávku | |
| B40500 WHR38883 |
C00495093
483286000161 |
Gasket | Na dotaz | Zadat poptávku | |
| M02100 WHR38883 |
C00497226
483286009198 |
Spinac | 1 073 Kč
€ 42.30 |
||
| M16700 WHR38883 |
C00417625
482000021475 |
Plug | Na dotaz | Zadat poptávku | |
| X11900 WHR38883 |
C00417626
482000021476 |
Nut | Na dotaz | Zadat poptávku | |
| X12000 WHR38883 |
C00417627
482000021477 |
Pipe | Na dotaz | Zadat poptávku | |
| X12400 WHR38883 |
C00417628
482000021478 |
Nut pilot | Na dotaz | Zadat poptávku | |
| X12500 WHR38883 |
C00417629
482000021479 |
Pipe pilot | Na dotaz | Zadat poptávku | |
| X12600 WHR38883 |
C00417630
482000021480 |
Connection | Na dotaz | Zadat poptávku | |
| X12700 WHR38883 |
C00417562
482000021385 |
Pipe bicone | Na dotaz | Zadat poptávku | |
| X13002 WHR38883 |
C00417631
482000021481 |
Fixation sparkgplug | Na dotaz | Zadat poptávku | |
| X13200 WHR38883 |
C00495148
483286009266 |
Nut for nozzle | Na dotaz | Zadat poptávku | |
| X13400 WHR38883 |
C00581027
483286000536 |
Valve | Na dotaz | Zadat poptávku | |
| X16100 WHR38883 |
C00417632
482000021482 |
Injector holder | Na dotaz | Zadat poptávku | |
| X16300 WHR38883 |
C00417633
482000021483 |
Nut | Na dotaz | Zadat poptávku | |
| X16400 WHR38883 |
C00417634
482000021484 |
Gasket Aluminium | Na dotaz | Zadat poptávku | |
| X16900 WHR38883 |
C00575074
483286000863 |
Generator ignition | Na dotaz | Zadat poptávku | |
| X17001 WHR38883 |
C00417635
482000021485 |
Nozzle pilot | Na dotaz | Zadat poptávku | |
| X17100 WHR38883 |
C00417563
482000021386 |
Nut + bicone pipe | Na dotaz | Zadat poptávku | |
| X19906 WHR38883 |
C00501145
483286009257 |
Nozzle oven pilot LPG | Na dotaz | Zadat poptávku | |
| X19912 WHR38883 |
C00417636
482000021486 |
Nozzle pilot 041 NG | Na dotaz | Zadat poptávku | |
| X19919 WHR38883 |
C00417637
482000021487 |
Nozzle Pilot 025 LPG | Na dotaz | Zadat poptávku | |
| X29600 WHR38883 |
C00495166
483286009379 |
Nozzle LPG | Na dotaz | Zadat poptávku | |
| X40300 WHR38883 |
C00495143
483286009245 |
Cable H.T. | Na dotaz | Zadat poptávku | |
| X66000 WHR38883 |
C00495142
483286009243 |
Hinge right side | Na dotaz | Zadat poptávku | |
| X66100 WHR38883 |
C00495145
483286009255 |
Hinge left side | Na dotaz | Zadat poptávku | |
| X92200 WHR38883 |
C00417638
482000021488 |
Protector | Na dotaz | Zadat poptávku | |
| Y33800 WHR38883 |
C00417639
482000021489 |
Nozzle 0230R NG | Na dotaz | Zadat poptávku | |
| 999 WHR38884 |
C00610789 | Gastable WHP | Na dotaz | Zadat poptávku | |
