| Komerční kód: | AKM 485 IX |
| Kód 12NC: | 857148538000 |
| I.C. kód: | 857148538003 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Vestavné trouby a varné desky |
| Další podobné modely: | 857148538000, 857148538002 |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 031 0 WHR70055 |
C00404148
481245350353 |
Hob ,cook top | Na dotaz | Zadat poptávku | |
| 033 0 WHR70055 |
C00404389
481245828038 |
Support ,wok | Na dotaz | Zadat poptávku | |
| 034 0 WHR70055 |
C00402065
481240449833 |
Bracket ,frame | Na dotaz | Zadat poptávku | |
| 191 0 WHR70055 |
C00545048
481246688806 |
Gasket kit | Na dotaz | Zadat poptávku | |
| 241 0 WHR70055 |
C00404408
481245848397 |
Grid hob left | Na dotaz | Zadat poptávku | |
| 241 1 WHR70055 |
C00404407
481245848396 |
Grid hob right | Na dotaz | Zadat poptávku | |
| 331 0 WHR70055 |
C00402308
481241129061 |
Knob gas | Na dotaz | Zadat poptávku | |
| 470 0 WHR70055 |
C00301402
481236068701 |
SMALL BURNER | Na dotaz | Zadat poptávku | |
| 470 1 WHR70055 |
C00301403
481236068702 |
SEMI-RAPID BURNER | Na dotaz | Zadat poptávku | |
| 470 3 WHR70055 |
C00401609
481236068942 |
Burner ,cup D.1,35 | Na dotaz | Zadat poptávku | |
| 471 0 WHR70055 |
C00301506
481236068703 |
Burner | Na dotaz | Zadat poptávku | |
| 471 1 WHR70055 |
C00301507
481236068704 |
Burner | Na dotaz | Zadat poptávku | |
| 471 3 WHR70055 |
C00401610
481236068943 |
Burner ,spreader TRC | Na dotaz | Zadat poptávku | |
| 473 0 WHR70055 |
C00301514
481236068708 |
Burner cap | Na dotaz | Zadat poptávku | |
| 473 1 WHR70055 |
C00301513
481236068707 |
Burner cap | Na dotaz | Zadat poptávku | |
| 473 3 WHR70055 |
C00482782
481236068706 |
viko horaku | 1 210 Kč
€ 47.70 |
||
| 473 6 WHR70055 |
C00401611
481236068944 |
Burner cap ,inn triplecrown | Na dotaz | Zadat poptávku | |
| 474 0 WHR70055 |
C00401612
481236068945 |
Set of nozzles G30-G31 | Na dotaz | Zadat poptávku | |
| 474 0 WHR70055 |
C00401613
481236068946 |
Set of nozzles G20 | Na dotaz | Zadat poptávku | |
| 571 1 WHR70055 |
C00401486
481236058592 |
Gas cock ,D.0,30 | Na dotaz | Zadat poptávku | |
| 571 2 WHR70055 |
C00401487
481236058593 |
Gas cock ,D.0,32 | Na dotaz | Zadat poptávku | |
| 571 3 WHR70055 |
C00401488
481236058594 |
Gas cock ,D.0,63 | Na dotaz | Zadat poptávku | |
| 591 0 WHR70055 |
C00301589
481225268075 |
Svíčka zapalovací | 514 Kč
€ 20.30 |
||
| 591 1 WHR70055 |
C00302542
481225268076 |
Svíčka zapalovací | 487 Kč
€ 19.20 |
||
| 591 3 WHR70055 |
C00401489
481236058595 |
Spark plug ,TRC mm 600 | Na dotaz | Zadat poptávku | |
| 591 9 WHR70055 |
C00301396
481249258055 |
Spring thermocouple | Na dotaz | Zadat poptávku | |
| 592 0 WHR70055 |
C00621796
481213838038 |
termopojistka | 871 Kč
€ 34.40 |
||
| 592 1 WHR70055 |
C00621795
481213838037 |
Thermo couple 450mm | Na dotaz | Zadat poptávku | |
| 592 3 WHR70055 |
C00399878
481213838051 |
Thermo couple ,ultrarapid | Na dotaz | Zadat poptávku | |
| 594 0 WHR70055 |
C00400912
481227328285 |
mikrospinac | 1 431 Kč
€ 56.40 |
||
| 595 0 WHR70055 |
C00484610
481214528031 |
Generator | Na dotaz | Zadat poptávku | |
| 703 0 WHR70055 |
C00401603
481236068934 |
Pipe ,SR right | Na dotaz | Zadat poptávku | |
| 703 1 WHR70055 |
C00401604
481236068935 |
Pipe ,AUX right | Na dotaz | Zadat poptávku | |
| 703 2 WHR70055 |
C00401605
481236068936 |
Pipe ,SR left | Na dotaz | Zadat poptávku | |
| 703 3 WHR70055 |
C00401606
481236068937 |
Pipe ,AUX left | Na dotaz | Zadat poptávku | |
| 703 5 WHR70055 |
C00401608
481236068939 |
Pipe ,gas distributor | Na dotaz | Zadat poptávku | |
| 703 6 WHR70055 |
C00401607
481236068938 |
Pipe ,TRC centre | Na dotaz | Zadat poptávku | |
| 794 0 WHR70055 |
C00301563
481253258032 |
Gasket ,gas | Na dotaz | Zadat poptávku | |
| 794 1 WHR70055 |
C00545046
481246688803 |
Gasket | Na dotaz | Zadat poptávku | |
| 794 2 WHR70055 |
C00545047
481246688804 |
Gasket | Na dotaz | Zadat poptávku | |
| 794 3 WHR70055 |
C00405142
481246688998 |
Gasket ,ultrarapid cup | Na dotaz | Zadat poptávku | |
| 900 0 WHR70055 |
C00399924
481219808018 |
Connector | Na dotaz | Zadat poptávku | |
| 900 1 WHR70055 |
C00404580
481246049837 |
Plate ,taps | Na dotaz | Zadat poptávku | |
| 904 0 WHR70055 |
C00301537
481246378014 |
Support | Na dotaz | Zadat poptávku | |
| 910 0 WHR70055 |
C00545059
481250518411 |
Screw | Na dotaz | Zadat poptávku | |
| 914 0 WHR70055 |
C00301559
481250518442 |
Nut | Na dotaz | Zadat poptávku | |
| 914 1 WHR70055 |
C00301406
481250518417 |
Nut for thermocouple | Na dotaz | Zadat poptávku | |
| 952 0 WHR70055 |
C00406010
481263058106 |
O-Ring ,hob top | Na dotaz | Zadat poptávku | |
