| Komerční kód: | AMC 988 |
| Kód 12NC: | 852898810000 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Klimatizace |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 001 0 WHR67749 |
C00401994
481240449666 |
Holder right | Na dotaz | Zadat poptávku | |
| 001 1 WHR67749 |
C00401995
481240449667 |
Holder | Na dotaz | Zadat poptávku | |
| 003 2 WHR67749 |
C00403423
481244048464 |
Cover top | Na dotaz | Zadat poptávku | |
| 003 5 WHR67749 |
C00404774
481246228833 |
Cover | Na dotaz | Zadat poptávku | |
| 021 0 WHR67749 |
C00404411
481245848402 |
Grille | Na dotaz | Zadat poptávku | |
| 021 1 WHR67749 |
C00403424
481244048465 |
Front panel left side | Na dotaz | Zadat poptávku | |
| 024 0 WHR67749 |
C00404338
481245388071 |
Cover,top | Na dotaz | Zadat poptávku | |
| 024 1 WHR67749 |
C00404339
481245388072 |
Cover,lower | Na dotaz | Zadat poptávku | |
| 032 2 WHR67749 |
C00403425
481244048466 |
Front panel right | Na dotaz | Zadat poptávku | |
| 033 1 WHR67749 |
C00405341
481249818692 |
Handle | Na dotaz | Zadat poptávku | |
| 033 2 WHR67749 |
C00403422
481244048463 |
Plate bottom | Na dotaz | Zadat poptávku | |
| 033 3 WHR67749 |
C00403426
481244048467 |
Side panel | Na dotaz | Zadat poptávku | |
| 033 4 WHR67749 |
C00403427
481244048468 |
Panel rear | Na dotaz | Zadat poptávku | |
| 033 5 WHR67749 |
C00404775
481246228834 |
Cover valve | Na dotaz | Zadat poptávku | |
| 034 0 WHR67749 |
C00402002
481240449676 |
Support Motor | Na dotaz | Zadat poptávku | |
| 084 4 WHR67749 |
C00404935
481246378018 |
Damper | Na dotaz | Zadat poptávku | |
| 084 5 WHR67749 |
C00404936
481246378019 |
Damper | Na dotaz | Zadat poptávku | |
| 104 3 WHR67749 |
C00403428
481244048469 |
Separator | Na dotaz | Zadat poptávku | |
| 111 7 WHR67749 |
C00404493
481245918281 |
Nameplate | Na dotaz | Zadat poptávku | |
| 301 2 WHR67749 |
C00400729
481222438031 |
Control box | Na dotaz | Zadat poptávku | |
| 303 0 WHR67749 |
C00403392
481244048427 |
Plate, bottom | Na dotaz | Zadat poptávku | |
| 320 1 WHR67749 |
C00403393
481244048428 |
Grille | Na dotaz | Zadat poptávku | |
| 320 2 WHR67749 |
C00403394
481244048429 |
Front cover | Na dotaz | Zadat poptávku | |
| 320 3 WHR67749 |
C00403395
481244048431 |
Casinghalf | Na dotaz | Zadat poptávku | |
| 324 5 WHR67749 |
C00403703
481244528055 |
Conveyor air upper | Na dotaz | Zadat poptávku | |
| 324 6 WHR67749 |
C00403702
481244528054 |
navaděč vzduchu | 307 Kč
€ 12.10 |
||
| 350 1 WHR67749 |
C00405023
481246469249 |
Display | Na dotaz | Zadat poptávku | |
| 402 0 WHR67749 |
C00401400
481236039034 |
Compressor SHW33TC4-V | Na dotaz | Zadat poptávku | |
| 407 0 WHR67749 |
C00401997
481240449669 |
držák motoru | 178 Kč
€ 7.00 |
||
| 420 1 WHR67749 |
C00399735
481212028048 |
Capacitor compressor | Na dotaz | Zadat poptávku | |
| 420 2 WHR67749 |
C00402003
481240449677 |
Bracket capacitor | Na dotaz | Zadat poptávku | |
| 440 0 WHR67749 |
C00401744
481236158455 |
Motor fan | Na dotaz | Zadat poptávku | |
| 440 5 WHR67749 |
C00403694
481244508024 |
mřížka | 373 Kč
€ 14.70 |
||
| 441 0 WHR67749 |
C00399694
481204868005 |
Transformer | Na dotaz | Zadat poptávku | |
| 442 0 WHR67749 |
C00401743
481236158454 |
Motor fan | Na dotaz | Zadat poptávku | |
| 442 5 WHR67749 |
C00401029
481228678008 |
Fan | Na dotaz | Zadat poptávku | |
| 443 1 WHR67749 |
C00401741
481236158451 |
Motor | 307 Kč
€ 12.10 |
||
| 443 4 WHR67749 |
C00401665
481236118548 |
Fan | Na dotaz | Zadat poptávku | |
| 453 1 WHR67749 |
C00404771
481246228829 |
Clip | Na dotaz | Zadat poptávku | |
| 521 0 WHR67749 |
C00399736
481212028049 |
Capacitor motor, fan | Na dotaz | Zadat poptávku | |
| 521 2 WHR67749 |
C00400661
481221838462 |
Control box | Na dotaz | Zadat poptávku | |
| 521 7 WHR67749 |
C00400757
481223708023 |
Sensor temper. | Na dotaz | Zadat poptávku | |
| 521 8 WHR67749 |
C00378552
481223708024 |
Sensor temper. pipe | Na dotaz | Zadat poptávku | |
| 526 0 WHR67749 |
C00401055
481229068326 |
Terminal Board | Na dotaz | Zadat poptávku | |
| 526 3 WHR67749 |
C00401039
481229028024 |
Terminal block | Na dotaz | Zadat poptávku | |
| 526 4 WHR67749 |
C00400696
481221848137 |
Control board | Na dotaz | Zadat poptávku | |
| 701 1 WHR67749 |
C00401057
481229068328 |
Pipe Fastener | Na dotaz | Zadat poptávku | |
| 740 0 WHR67749 |
C00405501
481251148433 |
Condenser | Na dotaz | Zadat poptávku | |
| 745 0 WHR67749 |
C00405460
481251138337 |
Evaporator | Na dotaz | Zadat poptávku | |
| 746 4 WHR67749 |
C00402140
481240478825 |
deska spojovací | 134 Kč
€ 5.30 |
||
| 764 0 WHR67749 |
C00405247
481248058381 |
filtr | Na dotaz | Zadat poptávku | |
| 781 2 WHR67749 |
C00399848
481213598931 |
Valve 1/2 on-off | Na dotaz | Zadat poptávku | |
| 781 3 WHR67749 |
C00377398
481213598935 |
Valve 1/4 on-off | Na dotaz | Zadat poptávku | |
| 781 8 WHR67749 |
C00399864
481213598949 |
Valve 4-way | Na dotaz | Zadat poptávku | |
| 782 0 WHR67749 |
C00399915
481217088012 |
Drainhose | Na dotaz | Zadat poptávku | |
| 910 4 WHR67749 |
C00405156
481246818368 |
Cap for hole | Na dotaz | Zadat poptávku | |
| 921 1 WHR67749 |
C00405545
481252008036 |
Bearing | Na dotaz | Zadat poptávku | |
| 993 0 WHR67749 |
C00377388
481201408001 |
Remote control | Na dotaz | Zadat poptávku | |
| 999 WHR67749 |
C00686650 | Circuit/Wiring Diagram WHP | Na dotaz | Zadat poptávku | |
