| Komerční kód: | AMD 027/1 |
| Kód 12NC: | 853002701100 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Klimatizace |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 999 WHR22044 |
C00545424 | NTC/PTC Chart WHP | Na dotaz | Zadat poptávku | |
| 999 WHR22044 |
C00545425 | Testprogram WHP | Na dotaz | Zadat poptávku | |
| 999 WHR22044 |
C00561881 | Circuit/Wiring Diagram WHP | Na dotaz | Zadat poptávku | |
| A01 WHR22044 |
C00386051
482000006139 |
Plate mounting | Na dotaz | Zadat poptávku | |
| A02 WHR22044 |
C00395026
480150100261 |
Chassis | Na dotaz | Zadat poptávku | |
| A03 WHR22044 |
C00377003
480150100271 |
Fan wheel Indoor | Na dotaz | Zadat poptávku | |
| A04 WHR22044 |
C00386059
480150100234 |
Ložisko | Na dotaz | Zadat poptávku | |
| A05 WHR22044 |
C00415524
482000017877 |
Evaporator | Na dotaz | Zadat poptávku | |
| A06 WHR22044 |
C00376989
480150100135 |
Motorek | 495 Kč
€ 19.50 |
||
| A07 WHR22044 |
C00415525
482000017878 |
Water conveyor assy (white) | Na dotaz | Zadat poptávku | |
| A08 WHR22044 |
C00385844
481252048018 |
Axis sheath | Na dotaz | Zadat poptávku | |
| A09 WHR22044 |
C00412037
482000010429 |
Air guide up | Na dotaz | Zadat poptávku | |
| A10 WHR22044 |
C00412038
482000010430 |
Air guide down | Na dotaz | Zadat poptávku | |
| A11 WHR22044 |
C00412039
482000010431 |
Display panel | Na dotaz | Zadat poptávku | |
| A12 WHR22044 |
C00412040
482000010432 |
Front panel | Na dotaz | Zadat poptávku | |
| A13 WHR22044 |
C00411973
482000010335 |
Display board | Na dotaz | Zadat poptávku | |
| A14 WHR22044 |
C00411993
482000010362 |
Cover Display | Na dotaz | Zadat poptávku | |
| A15 WHR22044 |
C00395003
480150100235 |
Cap | Na dotaz | Zadat poptávku | |
| A16 WHR22044 |
C00386265
482000010396 |
Cap for hole | Na dotaz | Zadat poptávku | |
| A17 WHR22044 |
C00409757
482000006142 |
Cover cable | Na dotaz | Zadat poptávku | |
| A18 WHR22044 |
C00415526
482000017879 |
Cover front | Na dotaz | Zadat poptávku | |
| A19 WHR22044 |
C00378274
482000010320 |
Ovladač dálkový | Na dotaz | Zadat poptávku | |
| A19 WHR22044 |
C00378173
482000002784 |
Holder Remote control | Na dotaz | Zadat poptávku | |
| A20 WHR22044 |
C00386174
482000010402 |
Cable mains | Na dotaz | Zadat poptávku | |
| A21 WHR22044 |
C00395212
480150100492 |
Cover Electronic box | Na dotaz | Zadat poptávku | |
| A22 WHR22044 |
C00378138
482000000399 |
Temperature sensor | Na dotaz | Zadat poptávku | |
| A22 WHR22044 |
C00378139
482000000400 |
Sensor temper. coil | Na dotaz | Zadat poptávku | |
| A23 WHR22044 |
C00386171
482000010332 |
Wire terminal board | Na dotaz | Zadat poptávku | |
| A24 WHR22044 |
C00386169
480150100146 |
Terminal Board | Na dotaz | Zadat poptávku | |
| A25 WHR22044 |
C00415527
482000017880 |
Control board IU | Na dotaz | Zadat poptávku | |
| A25 WHR22044 |
C00415528
482000017881 |
Power board IU | Na dotaz | Zadat poptávku | |
| A26 WHR22044 |
C00395210
480150100489 |
Electronic box | Na dotaz | Zadat poptávku | |
| A27 WHR22044 |
C00409760
482000006145 |
Ring Motor | Na dotaz | Zadat poptávku | |
| A28 WHR22044 |
C00415529
482000017882 |
Motor fan | Na dotaz | Zadat poptávku | |
| A29 WHR22044 |
C00412044
482000010436 |
Cover metal | Na dotaz | Zadat poptávku | |
| A30 WHR22044 |
C00412045
482000010437 |
Elect.parts box metal | Na dotaz | Zadat poptávku | |
| A31 WHR22044 |
C00411961
482000010318 |
Control box | Na dotaz | Zadat poptávku | |
| A32 WHR22044 |
C00411994
482000010363 |
Display Window | Na dotaz | Zadat poptávku | |
| A33 WHR22044 |
C00412013
482000010395 |
Cover lamp | Na dotaz | Zadat poptávku | |
| A34 WHR22044 |
C00412046
482000010438 |
Cover right | Na dotaz | Zadat poptávku | |
| A35 WHR22044 |
C00412047
482000010439 |
Cover left | Na dotaz | Zadat poptávku | |
| A36 WHR22044 |
C00381043
482000010309 |
Axle | Na dotaz | Zadat poptávku | |
| A37 WHR22044 |
C00412048
482000010440 |
Plate mounting | Na dotaz | Zadat poptávku | |
| A38 WHR22044 |
C00409598
482000005815 |
Filter | Na dotaz | Zadat poptávku | |
| B01 WHR22044 |
C00386185
481249818794 |
Cover Handle | Na dotaz | Zadat poptávku | |
| B02 WHR22044 |
C00386188
482000017883 |
Front panel | Na dotaz | Zadat poptávku | |
| B03 WHR22044 |
C00386189
482000017884 |
BASE | Na dotaz | Zadat poptávku | |
| B04 WHR22044 |
C00386136
482000010419 |
PFC reactor | Na dotaz | Zadat poptávku | |
| B05 WHR22044 |
C00386135
482000010420 |
Cover | Na dotaz | Zadat poptávku | |
| B06 WHR22044 |
C00386196
482000017885 |
Fan outdoor | Na dotaz | Zadat poptávku | |
| B07 WHR22044 |
C00386197
482000017886 |
Condenser assy | Na dotaz | Zadat poptávku | |
| B08 WHR22044 |
C00386198
482000017887 |
Motor fan | Na dotaz | Zadat poptávku | |
| B09 WHR22044 |
C00386199
482000017888 |
Bracket | Na dotaz | Zadat poptávku | |
| B10 WHR22044 |
C00415530
482000017889 |
Plate mounting | Na dotaz | Zadat poptávku | |
| B11 WHR22044 |
C00386201
482000017890 |
Compressor | Na dotaz | Zadat poptávku | |
| B12 WHR22044 |
C00412029
482000010417 |
Compressor ASG151UKNB7AT | Na dotaz | Zadat poptávku | |
| B13 WHR22044 |
C00386205
482000017891 |
Valve | Na dotaz | Zadat poptávku | |
| B14 WHR22044 |
C00386202
482000006161 |
Valve 3 Way | Na dotaz | Zadat poptávku | |
| B15 WHR22044 |
C00386206
482000017892 |
Capillary tube assy | Na dotaz | Zadat poptávku | |
| B16 WHR22044 |
C00416613
482000019340 |
Main Control board OU | Na dotaz | Zadat poptávku | |
| B17 WHR22044 |
C00386209
482000017894 |
Plate assy | Na dotaz | Zadat poptávku | |
| B18 WHR22044 |
C00386212
482000010453 |
Air grid back | Na dotaz | Zadat poptávku | |
| B19 WHR22044 |
C00415531
482000017895 |
Plate mounting | Na dotaz | Zadat poptávku | |
| B20 WHR22044 |
C00386216
482000017896 |
Panel side | Na dotaz | Zadat poptávku | |
| B22 WHR22044 |
C00386218
482000017897 |
Valve 4-way assy | Na dotaz | Zadat poptávku | |
| B23 WHR22044 |
C00386231
482000006165 |
Valve 4 Way | Na dotaz | Zadat poptávku | |
| B24 WHR22044 |
C00386124
480150100843 |
Valve 4-WAY | Na dotaz | Zadat poptávku | |
| B26 WHR22044 |
C00415532
482000017898 |
Fuse | Na dotaz | Zadat poptávku | |
| B27 WHR22044 |
C00386232
482000017899 |
Filter board | Na dotaz | Zadat poptávku | |
| B28 WHR22044 |
C00386233
482000010457 |
KRABICE ELEKTRIKA | Na dotaz | Zadat poptávku | |
| B29 WHR22044 |
C00386235
481246228229 |
Cover rear | Na dotaz | Zadat poptávku | |
| B30 WHR22044 |
C00386245
482000010458 |
Sensor temper. | Na dotaz | Zadat poptávku | |
| B31 WHR22044 |
C00378140
482000000401 |
Sensor temper. | Na dotaz | Zadat poptávku | |
| B33 WHR22044 |
C00386246
482000010459 |
Wire connection | Na dotaz | Zadat poptávku | |
| B34 WHR22044 |
C00386249
482000017900 |
Cover top | Na dotaz | Zadat poptávku | |
| B35 WHR22044 |
C00401597
481236068897 |
Rubber blanket water outlet | Na dotaz | Zadat poptávku | |
| B36 WHR22044 |
C00409042
482000004978 |
Outlet stud drain condensat n.s. | Na dotaz | Zadat poptávku | |
| B37 WHR22044 |
C00417528
482000021345 |
Gasket Outlet stud n.shown | Na dotaz | Zadat poptávku | |
