WHIRLPOOL AMW 593 IX
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | AMW 593 IX |
| Kód 12NC: | 858759301790 |
| I.C. kód: | 858759301791 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Mikrovlnné trouby |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 0221 WHR35325 |
C00448568
481067007334 |
Trim side left | Na dotaz | Zadat poptávku | |
| 0222 WHR35325 |
C00448569
481067007344 |
Trim side right | Na dotaz | Zadat poptávku | |
| 0410 WHR35325 |
C00329806
481241778141 |
Hinge assembly | Na dotaz | Zadat poptávku | |
| 1000 WHR35325 |
C00448666
481069112961 |
Door cpl. FE JO | Na dotaz | Zadat poptávku | |
| 1301 WHR35325 |
C00327641
481231038915 |
Cam spring | Na dotaz | Zadat poptávku | |
| 1302 WHR35325 |
C00327642
481231038916 |
vacka | 416 Kč
€ 16.40 |
||
| 1303 WHR35325 |
C00319192
481231038917 |
tahlo | 1 156 Kč
€ 45.60 |
||
| 1306 WHR35325 |
C00327644
481231038919 |
Bracket | Na dotaz | Zadat poptávku | |
| 1307 WHR35325 |
C00314852
481231039126 |
vacka | 1 160 Kč
€ 45.80 |
||
| 2450 WHR35325 |
C00330099
481245819376 |
rost trouby | Na dotaz | Zadat poptávku | |
| 2460 WHR35325 |
C00318818
481241838128 |
plech na pečení nahrada481010426480 pro všechny druhy trub Whirlpool, hloubka 18mm | Na dotaz | Zadat poptávku | |
| 2470 WHR35325 |
C00327803
481241838167 |
Tác skleněný na pečení | 2 125 Kč
€ 83.90 |
||
| 3200 WHR35325 |
C00435568
481010362300 |
Control panel WP FE IX | Na dotaz | Zadat poptávku | |
| 3201 WHR35325 |
C00313222
481252888106 |
Kroužek knoflíku | 524 Kč
€ 20.70 |
||
| 3202 WHR35325 |
C00329434
481241259159 |
lista spodni | 923 Kč
€ 36.40 |
||
| 3212 WHR35325 |
C00329435
481241259164 |
Knoflík | 803 Kč
€ 31.70 |
||
| 3310 WHR35325 |
C00318219
481241278882 |
knoflik ovladaci IX | Na dotaz | Zadat poptávku | |
| 3311 WHR35325 |
C00311165
481241129017 |
Kroužek (držák) tlačíka mikrovlnné trouby Whirlpool AMW 510 IX, AMW 528 IX, AMW 568 IX. | 540 Kč
€ 21.30 |
||
| 3319 WHR35325 |
C00311807
481241129011 |
Pružina tlačítka | 381 Kč
€ 15.00 |
||
| 3330 WHR35325 |
C00311058
481241259087 |
Tlačítko | 311 Kč
€ 12.30 |
||
| 3520 WHR35325 |
C00321824
480121100209 |
Display | Na dotaz | Zadat poptávku | |
| 3521 WHR35325 |
C00327242
481227138474 |
Holder PCB | Na dotaz | Zadat poptávku | |
| 3546 WHR35325 |
C00331052
481244229315 |
Cover | Na dotaz | Zadat poptávku | |
| 3546 WHR35325 |
C00325482
481067721631 |
Cover | Na dotaz | Zadat poptávku | |
| 4040 WHR35325 |
C00311859
481913158019 |
Magnetron | Na dotaz | Zadat poptávku | |
| 4060 WHR35325 |
C00317612
481236158491 |
Motorek otočného talíře mikrovlnné trouby | 407 Kč
€ 16.10 |
||
| 4061 WHR35325 |
C00332669
481253248065 |
Bushing | Na dotaz | Zadat poptávku | |
| 4062 WHR35325 |
C00325493
481068957441 |
Antenna | Na dotaz | Zadat poptávku | |
| 4063 WHR35325 |
C00345827
481249298057 |
Spring | Na dotaz | Zadat poptávku | |
| 4120 WHR35325 |
C00312591
481214528028 |
transformator VN | 4 440 Kč
€ 175.30 |
||
| 4200 WHR35325 |
C00313243
481912138013 |
Kondenzátor VN 1,15uF | 1 023 Kč
€ 40.40 |
||
| 4210 WHR35325 |
C00319002
481212208004 |
Filtr odrušovací | 1 355 Kč
€ 53.50 |
||
| 4260 WHR35325 |
C00311329
481221838323 |
DIODE HIGH VOLTAGE | Na dotaz | Zadat poptávku | |
| 4400 WHR35325 |
C00313819
480120100529 |
motor ventilátoru horkovzduchu mikrovlnné trouby | 1 517 Kč
€ 59.90 |
||
| 4410 WHR35325 |
C00313825
481236118461 |
Fan cooling assembly | Na dotaz | Zadat poptávku | |
| 4430 WHR35325 |
C00318172
481951528223 |
Vrtule ventilátoru horkovzduchu kombinované mikrovlnné trouby Whirlpool | 1 587 Kč
€ 62.70 |
||
| 4510 WHR35325 |
C00312125
481225998477 |
Topné těleso trouby – kruhové, horkovzduch 1200W | 1 638 Kč
€ 64.70 |
||
| 4520 WHR35325 |
C00315071
481225998469 |
Topné těleso trouby – horní grill 1600W | 2 821 Kč
€ 111.40 |
||
| 4527 WHR35325 |
C00332138
481250218782 |
Screw | 386 Kč
€ 15.20 |
||
| 4528 WHR35325 |
C00332656
481253088032 |
Washer | Na dotaz | Zadat poptávku | |
| 4529 WHR35325 |
C00329122
481240449806 |
Support grill | Na dotaz | Zadat poptávku | |
| 4560 WHR35325 |
C00327162
481225928945 |
Heating element bottom 1000W 230V | Na dotaz | Zadat poptávku | |
| 4569 WHR35325 |
C00329123
481240449807 |
Support | Na dotaz | Zadat poptávku | |
| 4900 WHR35325 |
C00328494
481232118245 |
Cable mains | Na dotaz | Zadat poptávku | |
| 5000 WHR35325 |
C00318572
481220988129 |
elektronika | Na dotaz | Zadat poptávku | |
| 5009 WHR35325 |
C00315816
481220988103 |
tlacitka | Na dotaz | Zadat poptávku | |
| 5060 WHR35325 |
C00325488
481068804623 |
Control board Power GR FC BH | Na dotaz | Zadat poptávku | |
| 5610 WHR35325 |
C00327567
481228248283 |
Thermostat | Na dotaz | Zadat poptávku | |
| 5660 WHR35325 |
C00315980
481228248293 |
termostat | Na dotaz | Zadat poptávku | |
| 6200 WHR35325 |
C00318162
480120100754 |
FUNC ENCODER SRGAVQ(0700) ALPS | Na dotaz | Zadat poptávku | |
| 6330 WHR35325 |
C00313526
480120101578 |
Mikrospínač dveří | 742 Kč
€ 29.30 |
||
| 6331 WHR35325 |
C00315857
481227138473 |
Držák spínače | 341 Kč
€ 13.50 |
||
| 6510 WHR35325 |
C00314001
481213488067 |
Žárovka do mikrovlnných trub (12V, 10W) | 121 Kč
€ 4.80 |
||
| 6511 WHR35325 |
C00325467
481010582905 |
Lamp holder S-KIT SpOven | Na dotaz | Zadat poptávku | |
| 6512 WHR35325 |
C00345826
481249298056 |
Spring | Na dotaz | Zadat poptávku | |
| 6513 WHR35325 |
C00331517
481246688855 |
Spring lampchoke | Na dotaz | Zadat poptávku | |
| 6520 WHR35325 |
C00332901
481938118151 |
Kryt žárovky | 741 Kč
€ 29.30 |
||
| 6560 WHR35325 |
C00332897
481938028007 |
Reflector | Na dotaz | Zadat poptávku | |
| 6910 WHR35325 |
C00327579
481228268062 |
Sensor temp | Na dotaz | Zadat poptávku | |
| 7433 WHR35325 |
C00330077
481245819302 |
Grid vent | Na dotaz | Zadat poptávku | |
| 7435 WHR35325 |
C00328914
481240118679 |
Strip bottom | Na dotaz | Zadat poptávku | |
| 9710 WHR35325 |
C00311937
481925228125 |
Pojistka 10A L | 266 Kč
€ 10.50 |
||
| 9711 WHR35325 |
C00332822
481925638016 |
Držák pojistky | 377 Kč
€ 14.90 |
||
| 999 WHR35325 |
C00351860
488000351860 |
Safety Instructions WHP | Na dotaz | Zadat poptávku | |
| 9994 WHR35325 |
C00329211
481240478734 |
Bar bottom | Na dotaz | Zadat poptávku | |
| 9996 WHR35325 |
C00459042
481244011336 |
Plate top | Na dotaz | Zadat poptávku | |
