KITCHENAID ARC 226 LH Wine Cellar 7M WP
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | ARC 226 LH Wine Cellar 7M WP |
| Kód 12NC: | 850122601010 |
| I.C. kód: | 850122601011 |
| Značka: | KITCHENAID |
| Typ produktu: | Vestavné lednice |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| B047 WHR89672 |
C00327213
481226278053 |
Filter | Na dotaz | Zadat poptávku | |
| G165 WHR89672 |
C00328595
481236039082 |
Compressor PLE 35 K 220V 50Hz | Na dotaz | Zadat poptávku | |
| G170 WHR89672 |
C00328593
481236039079 |
Tray Compressor | Na dotaz | Zadat poptávku | |
| G173 WHR89672 |
C00328594
481236039081 |
Evaporator | Na dotaz | Zadat poptávku | |
| K100 WHR89672 |
C00333858
482000009084 |
Rivet BK | Na dotaz | Zadat poptávku | |
| K136 WHR89672 |
C00328540
481232178389 |
Cable harness Lamp | Na dotaz | Zadat poptávku | |
| K137 WHR89672 |
C00326788
481212158173 |
transformator | 1 140 Kč
€ 45.00 |
||
| K138 WHR89672 |
C00326830
481213428097 |
Glass Lamp | Na dotaz | Zadat poptávku | |
| K140 WHR89672 |
C00326831
481213428098 |
Housing Lamp | Na dotaz | Zadat poptávku | |
| K142 WHR89672 |
C00326824
481213418096 |
Lampholder | Na dotaz | Zadat poptávku | |
| K143 WHR89672 |
C00317727
481225928963 |
Heating element 220V 24W | Na dotaz | Zadat poptávku | |
| K144 WHR89672 |
C00331063
481244229345 |
Panel Evaporator | Na dotaz | Zadat poptávku | |
| K145 WHR89672 |
C00313861
481236138137 |
Internal fan | Na dotaz | Zadat poptávku | |
| K155 WHR89672 |
C00326829
481213428096 |
starter | 189 Kč
€ 7.50 |
||
| K209 WHR89672 |
C00328539
481232178388 |
Cable harness Ventilator | Na dotaz | Zadat poptávku | |
| K215 WHR89672 |
C00327041
481221778273 |
Housing CB | Na dotaz | Zadat poptávku | |
| K220 WHR89672 |
C00329249
481240478927 |
senzor | 1 013 Kč
€ 40.00 |
||
| K221 WHR89672 |
C00328596
481236039083 |
Bracket Evaporator | Na dotaz | Zadat poptávku | |
| K234 WHR89672 |
C00328825
481236138138 |
Ventilator Condenser | Na dotaz | Zadat poptávku | |
| K247 WHR89672 |
C00329774
481241719496 |
Hinge bracket bottom right | Na dotaz | Zadat poptávku | |
| K249 WHR89672 |
C00329776
481241719498 |
Závěs dveří horní | 559 Kč
€ 22.10 |
||
| K250 WHR89672 |
C00327321
481229088122 |
Terminal Board | Na dotaz | Zadat poptávku | |
| K251 WHR89672 |
C00332268
481251148474 |
Condenser | Na dotaz | Zadat poptávku | |
| K301 WHR89672 |
C00333859
482000009085 |
Cable BK | Na dotaz | Zadat poptávku | |
| K302 WHR89672 |
C00328541
481232178391 |
Cable harness Compressor | Na dotaz | Zadat poptávku | |
| K303 WHR89672 |
C00326825
481213418097 |
Zářivka 6W | 513 Kč
€ 20.30 |
||
| K305 WHR89672 |
C00327042
481221778274 |
Housing CB | Na dotaz | Zadat poptávku | |
| K306 WHR89672 |
C00332269
481251148475 |
Bracket condenser | Na dotaz | Zadat poptávku | |
| K310 WHR89672 |
C00331236
481245088493 |
Shelf small | Na dotaz | Zadat poptávku | |
| K312 WHR89672 |
C00333860
482000009086 |
Cabinet | Na dotaz | Zadat poptávku | |
| K328 WHR89672 |
C00331237
481245088494 |
Shelf large | Na dotaz | Zadat poptávku | |
| K330 WHR89672 |
C00404900
481246269007 |
Handle | Na dotaz | Zadat poptávku | |
| K333 WHR89672 |
C00331328
481245228995 |
Control panel | Na dotaz | Zadat poptávku | |
| K335 WHR89672 |
C00316859
481221778275 |
modul vinoteky- predni | 5 336 Kč
€ 210.70 |
||
| K336 WHR89672 |
C00333861
482000009087 |
Connect.cable | Na dotaz | Zadat poptávku | |
| K338 WHR89672 |
C00314995
481221778276 |
jednotka vinoteky | 4 430 Kč
€ 174.90 |
||
| K339 WHR89672 |
C00327781
481241829987 |
Base compressor | Na dotaz | Zadat poptávku | |
| K389 WHR89672 |
C00411653
482000009504 |
Cover top | Na dotaz | Zadat poptávku | |
| K390 WHR89672 |
C00411654
482000009505 |
Frame | Na dotaz | Zadat poptávku | |
| K391 WHR89672 |
C00323121
480131100882 |
Hinge top | Na dotaz | Zadat poptávku | |
| K392 WHR89672 |
C00323120
480131100881 |
Hinge lower | Na dotaz | Zadat poptávku | |
| K393 WHR89672 |
C00323122
480131100884 |
Door | Na dotaz | Zadat poptávku | |
