WHIRLPOOL ARC 230/MR
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | ARC 230/MR |
| Kód 12NC: | 850123001000 |
| I.C. kód: | 850123001002 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Vestavné lednice |
| Další podobné modely: | 850123001001 |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| B047 WHR17344 |
C00327213
481226278053 |
Filter | Na dotaz | Zadat poptávku | |
| G166 WHR17344 |
C00334587
482000012896 |
PTC-Unit starting device 22V | Na dotaz | Zadat poptávku | |
| G173 WHR17344 |
C00328594
481236039081 |
Evaporator | Na dotaz | Zadat poptávku | |
| G782 WHR17344 |
C00334588
482000012897 |
Compressor DLX 4KK.1 | Na dotaz | Zadat poptávku | |
| K100 WHR17344 |
C00333858
482000009084 |
Rivet BK | Na dotaz | Zadat poptávku | |
| K135 WHR17344 |
C00334589
482000012898 |
Cable mains | Na dotaz | Zadat poptávku | |
| K136 WHR17344 |
C00328540
481232178389 |
Cable harness Lamp | Na dotaz | Zadat poptávku | |
| K144 WHR17344 |
C00331063
481244229345 |
Panel Evaporator | Na dotaz | Zadat poptávku | |
| K145 WHR17344 |
C00313861
481236138137 |
Internal fan | Na dotaz | Zadat poptávku | |
| K209 WHR17344 |
C00328539
481232178388 |
Cable harness Ventilator | Na dotaz | Zadat poptávku | |
| K215 WHR17344 |
C00327041
481221778273 |
Housing CB | Na dotaz | Zadat poptávku | |
| K220 WHR17344 |
C00329249
481240478927 |
senzor | 1 013 Kč
€ 40.00 |
||
| K221 WHR17344 |
C00328596
481236039083 |
Bracket Evaporator | Na dotaz | Zadat poptávku | |
| K234 WHR17344 |
C00328825
481236138138 |
Ventilator Condenser | Na dotaz | Zadat poptávku | |
| K246 WHR17344 |
C00329773
481241719495 |
závěs | 640 Kč
€ 25.20 |
||
| K248 WHR17344 |
C00329775
481241719497 |
Hinge top right | Na dotaz | Zadat poptávku | |
| K250 WHR17344 |
C00327321
481229088122 |
Terminal Board | Na dotaz | Zadat poptávku | |
| K251 WHR17344 |
C00332268
481251148474 |
Condenser | Na dotaz | Zadat poptávku | |
| K307 WHR17344 |
C00330233
481245948218 |
Cover top | Na dotaz | Zadat poptávku | |
| K310 WHR17344 |
C00331236
481245088493 |
Shelf small | Na dotaz | Zadat poptávku | |
| K328 WHR17344 |
C00331237
481245088494 |
Shelf large | Na dotaz | Zadat poptávku | |
| K408 WHR17344 |
C00333878
482000009112 |
Bushing | Na dotaz | Zadat poptávku | |
| K427 WHR17344 |
C00334596
482000012911 |
Control board thermost. LED | Na dotaz | Zadat poptávku | |
| K428 WHR17344 |
C00334590
482000012899 |
Modul, vinotéka | Na dotaz | Zadat poptávku | |
| K446 WHR17344 |
C00331655
482000001206 |
Stop door RIGHT | Na dotaz | Zadat poptávku | |
| K447 WHR17344 |
C00331656
482000001207 |
Stop door left | Na dotaz | Zadat poptávku | |
| K504 WHR17344 |
C00411379
482000009113 |
Handle | Na dotaz | Zadat poptávku | |
| K505 WHR17344 |
C00411316
482000008928 |
Door ARC 230 MR | Na dotaz | Zadat poptávku | |
| K509 WHR17344 |
C00333863
482000009089 |
Control panel | Na dotaz | Zadat poptávku | |
| K510 WHR17344 |
C00411380
482000009114 |
Control panel | Na dotaz | Zadat poptávku | |
| K511 WHR17344 |
C00411381
482000009115 |
Frame | Na dotaz | Zadat poptávku | |
| K523 WHR17344 |
C00334591
482000012900 |
Capacitor 2 MF | Na dotaz | Zadat poptávku | |
