IGNIS ARL 353/G REFRIGERATORS IG
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | ARL 353/G REFRIGERATORS IG |
| Kód 12NC: | 853935301010 |
| I.C. kód: | 853935301012 |
| Značka: | IGNIS |
| Typ produktu: | Vestavné lednice s mrazákem |
| Další podobné modely: | 853935315012, 853935315015, 853935315010, 853935315011, 853935301010, 853935301011 |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 011 0 WHR90186 |
C00333197
481950018123 |
Foot | Na dotaz | Zadat poptávku | |
| 045 6 WHR90186 |
C00333199
481950018151 |
Pin hinge | Na dotaz | Zadat poptávku | |
| 070 0 WHR90186 |
C00341492
481944088294 |
Pedestal | Na dotaz | Zadat poptávku | |
| 070 1 WHR90186 |
C00499324
481946049066 |
VLOZKA PANELU N | Na dotaz | Zadat poptávku | |
| 070 2 WHR90186 |
C00344330
481953518016 |
Bolt | Na dotaz | Zadat poptávku | |
| 104 0 WHR90186 |
C00341303
481944268955 |
Door,refriger. | Na dotaz | Zadat poptávku | |
| 105 1 WHR90186 |
C00312022
481953268815 |
Pouzdro závěsu | 526 Kč
€ 20.80 |
||
| 105 2 WHR90186 |
C00314819
481946238873 |
Plate | Na dotaz | Zadat poptávku | |
| 105 3 WHR90186 |
C00314817
481946238794 |
Rail | Na dotaz | Zadat poptávku | |
| 153 3 WHR90186 |
C00333010
481941879332 |
Door,dairy | Na dotaz | Zadat poptávku | |
| 154 0 WHR90186 |
C00557454
481941879388 |
Holder,bottles.. | Na dotaz | Zadat poptávku | |
| 155 0 WHR90186 |
C00339534
481946088408 |
drzak vajec | Na dotaz | Zadat poptávku | |
| 191 0 WHR90186 |
C00333151
481946818128 |
tesneni magneticke | 2 309 Kč
€ 91.20 |
||
| 242 0 WHR90186 |
C00557441
481941878802 |
zasuvka na zeleninu | 1 048 Kč
€ 41.40 |
||
| 242 1 WHR90186 |
C00557440
481941878801 |
zasuvka na zeleninu | 1 122 Kč
€ 44.30 |
||
| 245 0 WHR90186 |
C00499278
481945858457 |
rost vysuvny | Na dotaz | Zadat poptávku | |
| 249 0 WHR90186 |
C00335288
481946089469 |
Trim | Na dotaz | Zadat poptávku | |
| 249 3 WHR90186 |
C00316803
481946089247 |
Trim | Na dotaz | Zadat poptávku | |
| 252 0 WHR90186 |
C00342765
481941878931 |
Casing | Na dotaz | Zadat poptávku | |
| 255 0 WHR90186 |
C00333122
481946678214 |
GLAS COVER | Na dotaz | Zadat poptávku | |
| 335 0 WHR90186 |
C00499048
481941128803 |
knoflik termostatu | 218 Kč
€ 8.60 |
||
| 402 0 WHR90186 |
C00343579
481236038585 |
COMPRESSOR BPM 1058Z | Na dotaz | Zadat poptávku | |
| 402 1 WHR90186 |
C00333005
481941878641 |
miska na kondenzat | 171 Kč
€ 6.80 |
||
| 402 4 WHR90186 |
C00333135
481946689405 |
PRICHYTKA | 120 Kč
€ 4.70 |
||
| 491 0 WHR90186 |
C00486743
481946258296 |
VEKO KRABICKY N | Na dotaz | Zadat poptávku | |
| 491 2 WHR90186 |
C00499404
481946279738 |
VEKO PRIVODOVEJ SVORKOVNICE N | Na dotaz | Zadat poptávku | |
| 554 0 WHR90186 |
C00335508
481927129031 |
Thermostat A A13-0435-26 | Na dotaz | Zadat poptávku | |
| 561 0 WHR90186 |
C00574280
481928228582 |
Protect,motor | Na dotaz | Zadat poptávku | |
| 561 3 WHR90186 |
C00336701
481950218311 |
Screw | Na dotaz | Zadat poptávku | |
| 561 4 WHR90186 |
C00636125
481928228505 |
SKRUTKA N | Na dotaz | Zadat poptávku | |
| 561 5 WHR90186 |
C00499442
481946688907 |
PRICHYTKA | 78 Kč
€ 3.10 |
||
| 561 6 WHR90186 |
C00337747
481929068279 |
Plate,connector | Na dotaz | Zadat poptávku | |
| 614 1 WHR90186 |
C00621544
481928238031 |
RELE PTC-1260001 | 208 Kč
€ 8.20 |
||
| 651 0 WHR90186 |
C00311277
481913488135 |
BULB LED E14 T25 - 15W - 220V | Na dotaz | Zadat poptávku | |
| 652 0 WHR90186 |
C00498813
481925518206 |
Holder,lamp | Na dotaz | Zadat poptávku | |
| 740 0 WHR90186 |
C00333247
481951148512 |
Condenser | Na dotaz | Zadat poptávku | |
| 740 3 WHR90186 |
C00328255
481244048012 |
Holder condenser | Na dotaz | Zadat poptávku | |
| 764 0 WHR90186 |
C00266743
481948028144 |
Filtr chladničky - patrona | Na dotaz | Zadat poptávku | |
| 781 6 WHR90186 |
C00484484
481952928181 |
Water conveyor | Na dotaz | Zadat poptávku | |
| 783 6 WHR90186 |
C00333293
481953029022 |
COPPER / ALUMINUM JOINT PIPE | Na dotaz | Zadat poptávku | |
| 993 2 WHR90186 |
C00316841
481969028169 |
Čistič odtokového kanálku chladničky Whirlpool ARG 790/A+, ARG 734/A+, ARG 184701. | 155 Kč
€ 6.10 |
||
| 993 9 WHR90186 |
C00341389
481931039406 |
Door revers.Kit (n.shown) | Na dotaz | Zadat poptávku | |
| 999 WHR90186 |
C00732707 | Circuit/Wiring Diagram WHP | Na dotaz | Zadat poptávku | |
