WHIRLPOOL AWC 5101
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | AWC 5101 |
| Kód 12NC: | 851700298000 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Pračky |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 001 0 WHR20376 |
C00388443
480111103716 |
Cabinet | Na dotaz | Zadat poptávku | |
| 011 0 WHR20376 |
C00388444
480111103717 |
Foot M8-L34 | Na dotaz | Zadat poptávku | |
| 021 0 WHR20376 |
C00388445
480111103718 |
Front | Na dotaz | Zadat poptávku | |
| 024 2 WHR20376 |
C00388446
480111103719 |
Panel rear | Na dotaz | Zadat poptávku | |
| 025 0 WHR20376 |
C00388447
480111103721 |
Support control board | Na dotaz | Zadat poptávku | |
| 030 0 WHR20376 |
C00388448
480111103722 |
Table top | Na dotaz | Zadat poptávku | |
| 040 0 WHR20376 |
C00388449
480111103723 |
Hinge | Na dotaz | Zadat poptávku | |
| 050 0 WHR20376 |
C00388450
480111103724 |
Plinth | Na dotaz | Zadat poptávku | |
| 061 0 WHR20376 |
C00388451
480111103725 |
Counter weight upper | Na dotaz | Zadat poptávku | |
| 061 1 WHR20376 |
C00388452
480111103726 |
Counter weight front, bottom | Na dotaz | Zadat poptávku | |
| 061 2 WHR20376 |
C00388453
480111103727 |
Screw Counter weight | Na dotaz | Zadat poptávku | |
| 081 0 WHR20376 |
C00427620
480111103731 |
Shock absorber | Na dotaz | Zadat poptávku | |
| 084 0 WHR20376 |
C00388454
480111103729 |
Silent bloc | Na dotaz | Zadat poptávku | |
| 110 0 WHR20376 |
C00388455
480111103732 |
Handle door | Na dotaz | Zadat poptávku | |
| 130 0 WHR20376 |
C00388456
480111103733 |
Plate Door lock upper | Na dotaz | Zadat poptávku | |
| 130 1 WHR20376 |
C00388457
480111103734 |
Plate Door lock lower | Na dotaz | Zadat poptávku | |
| 131 0 WHR20376 |
C00388458
480111103735 |
Lock hook door | Na dotaz | Zadat poptávku | |
| 131 1 WHR20376 |
C00388459
480111103736 |
Pin Door Lock | Na dotaz | Zadat poptávku | |
| 131 2 WHR20376 |
C00388460
480111103737 |
Spring Door Lock | Na dotaz | Zadat poptávku | |
| 135 1 WHR20376 |
C00388461
480111103738 |
Knob Door Safety | Na dotaz | Zadat poptávku | |
| 135 2 WHR20376 |
C00388462
480111103739 |
Spring Door Safety | Na dotaz | Zadat poptávku | |
| 135 3 WHR20376 |
C00388463
480111103741 |
Holder adjust. Door Safety | Na dotaz | Zadat poptávku | |
| 140 0 WHR20376 |
C00388464
480111103742 |
Door glass | Na dotaz | Zadat poptávku | |
| 143 0 WHR20376 |
C00388465
480111103743 |
Glassdoor frame | Na dotaz | Zadat poptávku | |
| 144 0 WHR20376 |
C00388466
480111103744 |
Frame door glas | Na dotaz | Zadat poptávku | |
| 144 3 WHR20376 |
C00388467
480111103745 |
Screw PT 4.2 x 12 | Na dotaz | Zadat poptávku | |
| 191 0 WHR20376 |
C00388468
480111103746 |
Door bellow | Na dotaz | Zadat poptávku | |
| 191 1 WHR20376 |
C00388469
480111103747 |
Ring Bellow-Tub | Na dotaz | Zadat poptávku | |
| 191 2 WHR20376 |
C00388470
480111103748 |
Ring Bellow-Front | Na dotaz | Zadat poptávku | |
| 223 0 WHR20376 |
C00388471
480111103749 |
Tub, half rear | Na dotaz | Zadat poptávku | |
| 223 1 WHR20376 |
C00388472
480111103751 |
Tub, half front | Na dotaz | Zadat poptávku | |
| 223 2 WHR20376 |
C00388506
480111103796 |
Drum cpl. 40l, 1200rpm | Na dotaz | Zadat poptávku | |
| 271 0 WHR20376 |
C00388474
480111103753 |
V-ribbed belt | Na dotaz | Zadat poptávku | |
| 272 0 WHR20376 |
C00388475
480111103754 |
Pulley | Na dotaz | Zadat poptávku | |
| 272 3 WHR20376 |
C00388476
480111103755 |
Screw Pulley | Na dotaz | Zadat poptávku | |
| 303 0 WHR20376 |
C00388478
480111103757 |
Handle drawer | Na dotaz | Zadat poptávku | |
| 303 1 WHR20376 |
C00388507
480111103797 |
Control panel AWC 5101 | Na dotaz | Zadat poptávku | |
| 331 0 WHR20376 |
C00427621
480111103758 |
Knob timer | Na dotaz | Zadat poptávku | |
| 331 3 WHR20376 |
C00388479
480111103759 |
Button | Na dotaz | Zadat poptávku | |
| 400 0 WHR20376 |
C00388480
480111103761 |
Motor 1000rpm | Na dotaz | Zadat poptávku | |
| 400 1 WHR20376 |
C00336568
481250218401 |
sroub do zavazi | 40 Kč
€ 1.60 |
||
| 421 0 WHR20376 |
C00388481
480111103762 |
Interf.filter 1000rpm | Na dotaz | Zadat poptávku | |
| 430 0 WHR20376 |
C00388482
480111103763 |
Pump | Na dotaz | Zadat poptávku | |
| 451 0 WHR20376 |
C00380528
480111103764 |
Heating element | Na dotaz | Zadat poptávku | |
| 490 0 WHR20376 |
C00376768
480111103765 |
Cable mains | Na dotaz | Zadat poptávku | |
| 491 0 WHR20376 |
C00309418
481232128367 |
Přechodka | 591 Kč
€ 23.30 |
||
| 491 1 WHR20376 |
C00388483
480111103766 |
Screw Strain relief | Na dotaz | Zadat poptávku | |
| 521 0 WHR20376 |
C00388508
480111103798 |
Control unit DOMINO, programmed | Na dotaz | Zadat poptávku | |
| 571 0 WHR20376 |
C00388484
480111103768 |
Valve magnet double | Na dotaz | Zadat poptávku | |
| 581 0 WHR20376 |
C00427622
480111103769 |
Pressostat | Na dotaz | Zadat poptávku | |
| 630 0 WHR20376 |
C00311250
481228058048 |
Door lock Rold DA069516 | Na dotaz | Zadat poptávku | |
| 701 0 WHR20376 |
C00388485
480111103771 |
Přívod hadice | Na dotaz | Zadat poptávku | |
| 702 0 WHR20376 |
C00376769
480111103772 |
hadice od ventilu | Na dotaz | Zadat poptávku | |
| 708 1 WHR20376 |
C00388486
480111103773 |
Bend | Na dotaz | Zadat poptávku | |
| 711 0 WHR20376 |
C00388487
480111103774 |
Dispenser | Na dotaz | Zadat poptávku | |
| 712 0 WHR20376 |
C00388488
480111103775 |
Drawer | Na dotaz | Zadat poptávku | |
| 754 0 WHR20376 |
C00388489
480111103776 |
Drainhose | Na dotaz | Zadat poptávku | |
| 754 1 WHR20376 |
C00388490
480111103777 |
Lock eco | Na dotaz | Zadat poptávku | |
| 781 0 WHR20376 |
C00427623
480111103778 |
Hose draining | Na dotaz | Zadat poptávku | |
| 782 0 WHR20376 |
C00388491
480111103779 |
Hose Pressostat | Na dotaz | Zadat poptávku | |
| 794 2 WHR20376 |
C00388492
480111103781 |
Clamp hose dispenser-tub | Na dotaz | Zadat poptávku | |
| 900 0 WHR20376 |
C00388493
480111103782 |
Clamp | Na dotaz | Zadat poptávku | |
| 900 1 WHR20376 |
C00388494
480111103783 |
Bracket | Na dotaz | Zadat poptávku | |
| 900 2 WHR20376 |
C00388495
480111103784 |
Clamp | Na dotaz | Zadat poptávku | |
| 900 4 WHR20376 |
C00388496
480111103785 |
Clamp hose Tub-Pump (Pump-siede) | Na dotaz | Zadat poptávku | |
| 900 5 WHR20376 |
C00388497
480111103786 |
Clamp hose Tub-Pump (ECO-side) | Na dotaz | Zadat poptávku | |
| 900 8 WHR20376 |
C00388498
480111103787 |
Holder hose rear panel | Na dotaz | Zadat poptávku | |
| 910 1 WHR20376 |
C00388499
480111103788 |
Screw 4.2x14.5 | Na dotaz | Zadat poptávku | |
| 930 0 WHR20376 |
C00388500
480111103789 |
Spring Suspension | Na dotaz | Zadat poptávku | |
| 961 0 WHR20376 |
C00388501
480111103791 |
Spacer | Na dotaz | Zadat poptávku | |
| 999 WHR20377 |
C00364608 | Testprogram WHP | Na dotaz | Zadat poptávku | |
