IGNIS AWL 388
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | AWL 388 |
| Kód 12NC: | 854038801010 |
| Značka: | IGNIS |
| Typ produktu: | Pračky |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 001 0 WHR96158 |
C00343938
481944019578 |
skrin pracky | 4 521 Kč
€ 178.50 |
||
| 004 1 WHR96158 |
C00499390
481946279386 |
KRYT SPODKU SKRINE N | Na dotaz | Zadat poptávku | |
| 011 0 WHR96158 |
C00340791
481946248157 |
Foot adjustable | Na dotaz | Zadat poptávku | |
| 013 0 WHR96158 |
C00498912
481931038995 |
Nozka pracky - Tatra kov N | Na dotaz | Zadat poptávku | |
| 021 0 WHR96158 |
C00340676
481944019565 |
FRONT | Na dotaz | Zadat poptávku | |
| 024 0 WHR96158 |
C00743086
481944019787 |
Panel rear | Na dotaz | Zadat poptávku | |
| 025 0 WHR96158 |
C00499019
481940478555 |
Holder timer | Na dotaz | Zadat poptávku | |
| 030 0 WHR96158 |
C00335651
481944019567 |
TABLE TOP | Na dotaz | Zadat poptávku | |
| 034 2 WHR96158 |
C00341034
481949268458 |
Držák přední stěny pračky | 39 Kč
€ 1.50 |
||
| 034 3 WHR96158 |
C00499595
481953268243 |
P#zdro prednej steny | Na dotaz | Zadat poptávku | |
| 040 0 WHR96158 |
C00339862
481941719232 |
zaves dveri pracky | 1 026 Kč
€ 40.50 |
||
| 053 0 WHR96158 |
C00337714
481944019566 |
sokl pracky | 504 Kč
€ 19.90 |
||
| 061 0 WHR96158 |
C00343072
481946689118 |
protizavazi horni | 959 Kč
€ 37.90 |
||
| 061 1 WHR96158 |
C00343088
481946689078 |
Counter weight bottom | Na dotaz | Zadat poptávku | |
| 080 0 WHR96158 |
C00336126
481949268215 |
tlumic treci sestava | Na dotaz | Zadat poptávku | |
| 081 0 WHR96158 |
C00333126
481946688956 |
PLATE THERMOSTAT SENSOR | Na dotaz | Zadat poptávku | |
| 083 1 WHR96158 |
C00337752
481946688986 |
TRECÍ PLECH | 363 Kč
€ 14.30 |
||
| 084 0 WHR96158 |
C00336288
481946248049 |
tlumic gumovy tl. | Na dotaz | Zadat poptávku | |
| 086 0 WHR96158 |
C00498986
481940118607 |
PRICHYTKA TLMICA TATRA N | Na dotaz | Zadat poptávku | |
| 130 0 WHR96158 |
C00587472
481953538119 |
hak uzaveru dveri | 258 Kč
€ 10.20 |
||
| 132 0 WHR96158 |
C00342837
481941028587 |
CAP | Na dotaz | Zadat poptávku | |
| 141 0 WHR96158 |
C00339063
481945069519 |
sklo dveri | 1 111 Kč
€ 43.90 |
||
| 143 0 WHR96158 |
C00499318
481945948562 |
ram dveri | 1 244 Kč
€ 49.10 |
||
| 144 0 WHR96158 |
C00340709
481945948607 |
priruba dveri | 1 588 Kč
€ 62.70 |
||
| 144 1 WHR96158 |
C00337775
481946689077 |
Plate door frame | Na dotaz | Zadat poptávku | |
| 190 0 WHR96158 |
C00317356
481946669828 |
TVOAWG 370 | 1 414 Kč
€ 55.80 |
||
| 190 1 WHR96158 |
C00335943
481949238119 |
spona TVO - vnitřní | 416 Kč
€ 16.40 |
||
| 190 2 WHR96158 |
C00335945
481949268515 |
spona TVO predni st. | Na dotaz | Zadat poptávku | |
| 200 0 WHR96158 |
C00337450
481941818294 |
nadrz | 3 945 Kč
€ 155.70 |
||
| 201 0 WHR96158 |
C00344299
481941878808 |
dno nadrze | 3 984 Kč
€ 157.30 |
||
| 201 1 WHR96158 |
C00335938
481953228209 |
STRAP TUB | Na dotaz | Zadat poptávku | |
| 220 0 WHR96158 |
C00341188
481941818284 |
Drum + cross piece ass | Na dotaz | Zadat poptávku | |
| 271 0 WHR96158 |
C00344363
481935818138 |
Belt | Na dotaz | Zadat poptávku | |
| 272 0 WHR96158 |
C00337066
481952888075 |
remenice bubnu | 697 Kč
€ 27.50 |
||
| 278 0 WHR96158 |
C00344283
481932138009 |
Bowden cable | Na dotaz | Zadat poptávku | |
| 292 0 WHR96158 |
C00320302
481946669797 |
Gasket | Na dotaz | Zadat poptávku | |
| 301 0 WHR96158 |
C00743095
481945319723 |
Control panel | Na dotaz | Zadat poptávku | |
| 303 0 WHR96158 |
C00490827
481949869974 |
AELO N?SYPKY AWL N | Na dotaz | Zadat poptávku | |
| 331 0 WHR96158 |
C00743096
481941379117 |
Disc,indication | Na dotaz | Zadat poptávku | |
| 332 0 WHR96158 |
C00337027
481941028588 |
PUSH BUTTON | Na dotaz | Zadat poptávku | |
| 332 1 WHR96158 |
C00337028
481941028589 |
kryt tlacitka | 122 Kč
€ 4.80 |
||
| 341 0 WHR96158 |
C00339129
481941258289 |
Indication disc timer | Na dotaz | Zadat poptávku | |
| 341 1 WHR96158 |
C00743089
481941258519 |
Knob thermostat | Na dotaz | Zadat poptávku | |
| 401 0 WHR96158 |
C00498966
481936158119 |
motor komutatorovy | 3 854 Kč
€ 152.20 |
||
| 401 1 WHR96158 |
C00312014
481931088529 |
Uhlíky motoru - pár 13,6x5x32 mm | 195 Kč
€ 7.70 |
||
| 421 0 WHR96158 |
C00338676
481912118245 |
Interf.filter | Na dotaz | Zadat poptávku | |
| 430 0 WHR96158 |
C00314221
481936018189 |
Pump, draining | Na dotaz | Zadat poptávku | |
| 432 0 WHR96158 |
C00337055
481936078311 |
Pump body - 6258.50792 | Na dotaz | Zadat poptávku | |
| 451 0 WHR96158 |
C00380589
481925928796 |
Heating element - 1900W 220V - 730100310 | Na dotaz | Zadat poptávku | |
| 490 0 WHR96158 |
C00316393
481932118136 |
Flexo kabel 2 m, konektory | Na dotaz | Zadat poptávku | |
| 491 0 WHR96158 |
C00343512
481929068166 |
Connect.block | Na dotaz | Zadat poptávku | |
| 501 0 WHR96158 |
C00379020
481928218538 |
programator 914/1426 | 2 146 Kč
€ 84.70 |
||
| 501 1 WHR96158 |
C00336041
481915748001 |
Steppin motor | Na dotaz | Zadat poptávku | |
| 521 0 WHR96158 |
C00317244
481921478443 |
regulator motoru | 4 305 Kč
€ 170.00 |
||
| 551 4 WHR96158 |
C00335515
481927128776 |
termostat pevny 40°C | 709 Kč
€ 28.00 |
||
| 554 0 WHR96158 |
C00335497
481927128678 |
termostat kapilarni | Na dotaz | Zadat poptávku | |
| 572 0 WHR96158 |
C00481806
481928128235 |
ventil 2-cest. | 1 289 Kč
€ 50.90 |
||
| 583 0 WHR96158 |
C00743090
481927128951 |
Pressostat | Na dotaz | Zadat poptávku | |
| 620 0 WHR96158 |
C00743097
481927648177 |
Unit,pushbutton | Na dotaz | Zadat poptávku | |
| 630 0 WHR96158 |
C00587476
481969018149 |
ZAVORA DVIEROK PLAST N | Na dotaz | Zadat poptávku | |
| 630 1 WHR96158 |
C00587314
481940478903 |
ZAMOK DVIEROK ZOSTAVA | Na dotaz | Zadat poptávku | |
| 701 0 WHR96158 |
C00339222
481953028283 |
Hose, inlet.2m | Na dotaz | Zadat poptávku | |
| 702 0 WHR96158 |
C00339270
481953028793 |
Hose insideinside | Na dotaz | Zadat poptávku | |
| 708 1 WHR96158 |
C00341276
481953028868 |
Hadice násypka - nádrž pračky Whirlpool, Bauknecht, Ignis | 853 Kč
€ 33.70 |
||
| 711 0 WHR96158 |
C00484399
481941879105 |
nasypka | 1 704 Kč
€ 67.30 |
||
| 712 0 WHR96158 |
C00341253
481941878686 |
zasuvka nasypky | 445 Kč
€ 17.60 |
||
| 713 0 WHR96158 |
C00499112
481941878221 |
VLOYKA PRE TEKUT? DETERGENTY N | Na dotaz | Zadat poptávku | |
| 718 0 WHR96158 |
C00492628
481953028594 |
viko prepadu | 78 Kč
€ 3.10 |
||
| 718 1 WHR96158 |
C00499464
481946698727 |
VEKO N | Na dotaz | Zadat poptávku | |
| 754 0 WHR96158 |
C00499557
481952648255 |
hadica nadrz cerpadlo-TATRA GUM./TEX | Na dotaz | Zadat poptávku | |
| 754 1 WHR96158 |
C00587299
481936058533 |
Flap. | Na dotaz | Zadat poptávku | |
| 760 0 WHR96158 |
C00314883
481948058106 |
Filtr čerpadla | 198 Kč
€ 7.80 |
||
| 781 0 WHR96158 |
C00318230
481953028847 |
Hose,draining | Na dotaz | Zadat poptávku | |
| 783 0 WHR96158 |
C00499572
481953028808 |
VZDUSNIK S HADICKOU PLAST N | Na dotaz | Zadat poptávku | |
| 786 0 WHR96158 |
C00339380
481953028599 |
Hose draining | Na dotaz | Zadat poptávku | |
| 786 1 WHR96158 |
C00336018
481946248156 |
Stopper | Na dotaz | Zadat poptávku | |
| 787 0 WHR96158 |
C00339383
481953028904 |
hadice vrapova | 378 Kč
€ 14.90 |
||
| 791 0 WHR96158 |
C00340420
481946669598 |
tesneni nasypky spod | 126 Kč
€ 5.00 |
||
| 791 1 WHR96158 |
C00340473
481946669597 |
tesneni nasypky horn | 167 Kč
€ 6.60 |
||
| 794 7 WHR96158 |
C00316490
481946669704 |
tesneni + sitko | 328 Kč
€ 12.90 |
||
| 901 0 WHR96158 |
C00309461
481940118529 |
Spona nádrž-čerpadlo | 199 Kč
€ 7.90 |
||
| 901 1 WHR96158 |
C00343349
481949268061 |
Clamp hose | Na dotaz | Zadat poptávku | |
| 902 1 WHR96158 |
C00498980
481940118384 |
drzak hadic | 89 Kč
€ 3.50 |
||
| 902 2 WHR96158 |
C00499004
481940449832 |
DRYIAK REGUL?TORA MOTORA N | Na dotaz | Zadat poptávku | |
| 902 4 WHR96158 |
C00339542
481946698752 |
Holder unit, pushbutton | Na dotaz | Zadat poptávku | |
| 910 6 WHR96158 |
C00336706
481950238005 |
sroub tlumice | 122 Kč
€ 4.80 |
||
| 912 2 WHR96158 |
C00336468
481931038685 |
SPOJOVACI MATERIÁL T | 343 Kč
€ 13.50 |
||
| 914 0 WHR96158 |
C00338023
481950518298 |
Nut | Na dotaz | Zadat poptávku | |
| 931 0 WHR96158 |
C00336064
481949238138 |
pruzina zavesna | 327 Kč
€ 12.90 |
||
| 931 1 WHR96158 |
C00336127
481949258119 |
Spring | Na dotaz | Zadat poptávku | |
| 932 0 WHR96158 |
C00317751
481949268666 |
Pružina uzávěru dveří | 420 Kč
€ 16.60 |
||
| 941 0 WHR96158 |
C00498909
481931038743 |
LOYISK? DNA N?DRYE N | Na dotaz | Zadat poptávku | |
| 951 0 WHR96158 |
C00498902
481931038157 |
Bearing, kit | Na dotaz | Zadat poptávku | |
| 952 0 WHR96158 |
C00340421
481946669882 |
tesneni termostatu | 405 Kč
€ 16.00 |
||
| 990 0 WHR96158 |
C00498906
481931038683 |
SPOJOVACI MATERIAL H | 800 Kč
€ 31.60 |
||
| 990 1 WHR96158 |
C00341620
481931038684 |
sada na zajištění | 887 Kč
€ 35.00 |
||
