Komerční kód: | BF11B |
Kód 12NC: | |
I.C. kód: | AQ355800000 |
Značka: | HOT POINT |
Typ produktu: |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
Číslo | Kód | Název | Cena | ||
---|---|---|---|---|---|
001 01760-08 |
C00077108
482000040800 |
ANELLO CERNIERA | Na dotaz | Zadat poptávku | |
002 01760-08 |
C00209683
482000084586 |
HINGE PIN | Na dotaz | Zadat poptávku | |
003 01760-08 |
C00128462
481990500032 |
pouzdro pruziny | 145 Kč
€ 5.70 |
||
004 01760-08 |
C00210357 | HINGE SPRING | Na dotaz | Zadat poptávku | |
005 01760-08 |
C00209712
482000040355 |
DOOR HINGE | Na dotaz | Zadat poptávku | |
006 01760-08 |
C00210352 | DOOR SEAL LOWER | Na dotaz | Zadat poptávku | |
007 01760-08 |
C00210358 | INNER DOOR | Na dotaz | Zadat poptávku | |
008 01760-08 |
C00128687 | DISTRIBUTOR SEAL | Na dotaz | Zadat poptávku | |
009 01760-08 |
C00031957
482000038895 |
DETERGENT/RINSEAID ELECTRO DISPENSER | Na dotaz | Zadat poptávku | |
010 01760-08 |
C00210178
482000084600 |
DOOR SWITCH | Na dotaz | Zadat poptávku | |
011 01760-08 |
C00210177
482000030319 |
DOOR LATCH | Na dotaz | Zadat poptávku | |
011 01760-08 |
C00210592 | DOOR LATCH | Na dotaz | Zadat poptávku | |
012 01760-08 |
C00209697
482000040354 |
DISP FIXING BKT PAIR | Na dotaz | Zadat poptávku | |
013 01760-08 |
C00613587 | NEON-NOGLOW | Na dotaz | Zadat poptávku | |
014 01760-08 |
C00210364 | PUSH BUTTON SWITCH | Na dotaz | Zadat poptávku | |
015 01760-08 |
C00210376 | TIMER BF11 | Na dotaz | Zadat poptávku | |
016 01760-08 |
C00210359 | TIMER BRACKET | Na dotaz | Zadat poptávku | |
017 01760-08 |
C00210351
482000039364 |
LATCH HANDLE | Na dotaz | Zadat poptávku | |
018 01760-08 |
C00210181
482000084601 |
SPRING-HANDLE | Na dotaz | Zadat poptávku | |
019 01760-08 |
C00210371 | CONSOLE HSG BROWN | Na dotaz | Zadat poptávku | |
020 01760-08 |
C00210367 | FILLER STRIP BROWN | Na dotaz | Zadat poptávku | |
021 01760-08 |
C00210349
481290508256 |
FIXING | Na dotaz | Zadat poptávku | |
022 01760-08 |
C00210373 | CONSOLE FACIA BROWN | Na dotaz | Zadat poptávku | |
023 01760-08 |
C00210375 | TIMER KNOB BROWN | Na dotaz | Zadat poptávku | |
024 01760-08 |
C00210369 | PUSH BUTTON BROWN | Na dotaz | Zadat poptávku | |
025 01760-08 |
C00210363 | CONSOLE EX BROWN | Na dotaz | Zadat poptávku | |
026 01760-08 |
C00210347
481949263462 |
SPRING | Na dotaz | Zadat poptávku | |
027 01760-08 |
C00209687 | SCREW | Na dotaz | Zadat poptávku | |
028 01760-08 |
C00210346 | INSULATING PANEL | Na dotaz | Zadat poptávku | |
029 01760-08 |
C00210356 | OUTER DOOR | Na dotaz | Zadat poptávku | |
030 01760-08 |
C00210353 | DOOR FIXING UPPER | Na dotaz | Zadat poptávku | |
031 01760-08 |
C00210360 | BRACKET R/HAND | Na dotaz | Zadat poptávku | |
032 01760-08 |
C00210345 | RUBBER SPACER | Na dotaz | Zadat poptávku | |
033 01760-08 |
C00210354 | DOOR FIXING LOWER | Na dotaz | Zadat poptávku | |
034 01760-08 |
C00210350 | KICKSTRIP | Na dotaz | Zadat poptávku | |
035 01760-08 |
C00210348 | PANEL | Na dotaz | Zadat poptávku | |
036 01760-08 |
C00210361 | BRACKET L/HAND | Na dotaz | Zadat poptávku | |
037 01760-08 |
C00210355 | INSULATION SHEET | Na dotaz | Zadat poptávku | |
038 01760-08 |
C00210365
481990500536 |
STEAM PROTECTION | Na dotaz | Zadat poptávku | |
101 01760-10 |
C00210381
481990500541 |
FRONT PROTECTION | Na dotaz | Zadat poptávku | |
103 01760-10 |
C00210382 | TUB RETAINER LEFT | Na dotaz | Zadat poptávku | |
104 01760-10 |
C00209694
482000084589 |
SPRAY ARM TUBE | Na dotaz | Zadat poptávku | |
105 01760-10 |
C00210383 | FILTER CLIP | Na dotaz | Zadat poptávku | |
106 01760-10 |
C00119861 | SPODNÍ ROTOR PLAST | Na dotaz | Zadat poptávku | |
107 01760-10 |
C00210384
482000084602 |
FILTER ASSEMBLY | Na dotaz | Zadat poptávku | |
108 01760-10 |
C00210385 | SIDE PANEL L/HAND | Na dotaz | Zadat poptávku | |
109 01760-10 |
C00210386
482000030320 |
Těsnění dveří | 1 618 Kč
€ 63.90 |
||
110 01760-10 |
C00210387 | SPRAY NOZZLE | Na dotaz | Zadat poptávku | |
111 01760-10 |
C00210388 | SEAL | Na dotaz | Zadat poptávku | |
112 01760-10 |
C00210389
481990500229 |
UPP SPRAY FEED PIPE | Na dotaz | Zadat poptávku | |
115 01760-10 |
C00210390 | DOORCATCH | Na dotaz | Zadat poptávku | |
116 01760-10 |
C00210391 | BRACKET | Na dotaz | Zadat poptávku | |
117 01760-10 |
C00210392 | INSULATING PANEL TOP | Na dotaz | Zadat poptávku | |
120 01760-10 |
C00210393 | SIDE PANEL R/HAND | Na dotaz | Zadat poptávku | |
121 01760-10 |
C00209691 | VENT GASKET | Na dotaz | Zadat poptávku | |
122 01760-10 |
C00209688 | FILLER PLUG | Na dotaz | Zadat poptávku | |
123 01760-10 |
C00210394
481990500518 |
METERING TANK | Na dotaz | Zadat poptávku | |
124 01760-10 |
C00210395 | TUB RETAINER RIGHT | Na dotaz | Zadat poptávku | |
125 01760-10 |
C00210396 | LOWER BACK PANEL | Na dotaz | Zadat poptávku | |
127 01760-10 |
C00209689
482000084587 |
BASKET RUNNER | Na dotaz | Zadat poptávku | |
128 01760-10 |
C00209698 | VENT RING NUT | Na dotaz | Zadat poptávku | |
129 01760-10 |
C00210397
481990500031 |
CAP | Na dotaz | Zadat poptávku | |
130 01760-10 |
C00210194
481990500187 |
BASKET RUNN. PIN | Na dotaz | Zadat poptávku | |
131 01760-10 |
C00209705
482000030310 |
ROLLER ASSY | Na dotaz | Zadat poptávku | |
132 01760-10 |
C00210398
481990500511 |
HEATER | Na dotaz | Zadat poptávku | |
133 01760-10 |
C00210399 | RUNNER END STOP | Na dotaz | Zadat poptávku | |
134 01760-10 |
C00209699 | HEATER SUPPORT | Na dotaz | Zadat poptávku | |
135 01760-10 |
C00209696
481990500025 |
OCHRANA | 145 Kč
€ 5.70 |
||
201 01760-12 |
C00210400 | SUMP HOSE | Na dotaz | Zadat poptávku | |
202 01760-12 |
C00209701
482000038755 |
SALT FUNNEL | Na dotaz | Zadat poptávku | |
203 01760-12 |
C00210401 | SUMP GASKET | Na dotaz | Zadat poptávku | |
204 01760-12 |
C00209702 | BRACKET | Na dotaz | Zadat poptávku | |
205 01760-12 |
C00210402 | SUMP | Na dotaz | Zadat poptávku | |
206 01760-12 |
C00210403
481990500538 |
DRAIN PUMP | Na dotaz | Zadat poptávku | |
207 01760-12 |
C00210404
481990500191 |
HOSE CLAMP | Na dotaz | Zadat poptávku | |
208 01760-12 |
C00210405
481990500189 |
HOSE | Na dotaz | Zadat poptávku | |
209 01760-12 |
C00210406 | AIR TRAP | Na dotaz | Zadat poptávku | |
210 01760-12 |
C00210407 | SPRAY FORCE ADJUSTER | Na dotaz | Zadat poptávku | |
211 01760-12 |
C00210408 | BRACKET | Na dotaz | Zadat poptávku | |
212 01760-12 |
C00210409
481990500212 |
SPECIAL SCREW | Na dotaz | Zadat poptávku | |
213 01760-12 |
C00209684
481990500006 |
podlozka | 111 Kč
€ 4.40 |
||
214 01760-12 |
C00210410
481990500242 |
TURBINA | 393 Kč
€ 15.50 |
||
215 01760-12 |
C00209680
482000030309 |
IMPELLOR SEAL | Na dotaz | Zadat poptávku | |
216 01760-12 |
C00210411
481990500202 |
GASKET | Na dotaz | Zadat poptávku | |
217 01760-12 |
C00210412 | PUMP HOUSING REAR | Na dotaz | Zadat poptávku | |
218 01760-12 |
C00210413
482000039262 |
CIRC MOTOR & PUMP## | Na dotaz | Zadat poptávku | |
219 01760-12 |
C00210414 | BASE PANEL | Na dotaz | Zadat poptávku | |
221 01760-12 |
C00209692
482000084588 |
THERMOSTAT GROMMET | Na dotaz | Zadat poptávku | |
222 01760-12 |
C00209704
482000084592 |
THERMOSTAT-TUB | Na dotaz | Zadat poptávku | |
223 01760-12 |
C00210416 | SOFTENER UNIT | Na dotaz | Zadat poptávku | |
223 01760-12 |
C00211073 | SOFTENER UNIT | Na dotaz | Zadat poptávku | |
224 01760-12 |
C00209679 | SALT CONTNR GASKET | Na dotaz | Zadat poptávku | |
224 01760-12 |
C00210984 | GASKET SOFTENER UNIT | Na dotaz | Zadat poptávku | |
225 01760-12 |
C00128471 | BIN/SEL. BUSH | Na dotaz | Zadat poptávku | |
225 01760-12 |
C00210982 | NUT SOFTENER UNIT | Na dotaz | Zadat poptávku | |
226 01760-12 |
C00210417 | SOFTENER CAP | Na dotaz | Zadat poptávku | |
227 01760-12 |
C00210418 | HOSE | Na dotaz | Zadat poptávku | |
228 01760-12 |
C00210419 | HOSE | Na dotaz | Zadat poptávku | |
229 01760-12 |
C00210420 | ADJUSTABLE FOOT | Na dotaz | Zadat poptávku | |
230 01760-12 |
C00210421 | PRESSURE SW LEVEL | Na dotaz | Zadat poptávku | |
231 01760-12 |
C00210422 | PRESSURE SW SAFETY | Na dotaz | Zadat poptávku | |
232 01760-12 |
C00210423 | HOSE VALVE/MET.TANK | Na dotaz | Zadat poptávku | |
233 01760-12 |
C00210424 | CROSS MEMBER FRONT | Na dotaz | Zadat poptávku | |
234 01760-12 |
C00212973
482000051692 |
MAINS CABLE & PLUG | Na dotaz | Zadat poptávku | |
235 01760-12 |
C00209686
481253008013 |
hadice vytok. mycky | 920 Kč
€ 36.30 |
||
236 01760-12 |
C00077109
482000041302 |
FILTRO TUBI ALIMENTAZIONE | Na dotaz | Zadat poptávku | |
237 01760-12 |
C00210425 | FILL HOSE | Na dotaz | Zadat poptávku | |
238 01760-12 |
C00210426
482000037421 |
HOSE CLAMP | Na dotaz | Zadat poptávku | |
239 01760-12 |
C00210427 | TERMINAL BLOCK | Na dotaz | Zadat poptávku | |
240 01760-12 |
C00210428 | FILL VALVE | Na dotaz | Zadat poptávku | |
241 01760-12 |
C00210429 | BRACKET | Na dotaz | Zadat poptávku | |
242 01760-12 |
C00210430
482000036478 |
CAPACITOR | Na dotaz | Zadat poptávku | |
243 01760-12 |
C00210431 | BRACKET | Na dotaz | Zadat poptávku | |
244 01760-12 |
C00128154 | ANTIPARASITE FILTER | Na dotaz | Zadat poptávku | |
245 01760-12 |
C00210432
481990500529 |
HOSE SAFETY PR.SW. | Na dotaz | Zadat poptávku | |
246 01760-12 |
C00210433
481990500531 |
HOSE LEVEL PR. SW. | Na dotaz | Zadat poptávku | |
999 01760-12 |
C00146259
482000082440 |
WASHER | Na dotaz | Zadat poptávku | |
999 01760-12 |
C00181491 | INSTALL/USER INSTRUC | Na dotaz | Zadat poptávku | |
999 01760-12 |
C00210434
481990500532 |
pruchodka gumova | 100 Kč
€ 3.90 |
||
999 01760-12 |
C00210908 | DOOR TEMPLATE | Na dotaz | Zadat poptávku | |
301 01760-14 |
C00210435 | LOWER BASKET ASSY | Na dotaz | Zadat poptávku | |
302 01760-14 |
C00209752
482000033838 |
WHEEL LOWER BASKET | Na dotaz | Zadat poptávku | |
303 01760-14 |
C00210436 | UPPER BASKET ASSY | Na dotaz | Zadat poptávku | |
304 01760-14 |
C00210437 | CUP RACK | Na dotaz | Zadat poptávku | |
305 01760-14 |
C00210438
482000036739 |
SPRAY ARM NUT | Na dotaz | Zadat poptávku | |
306 01760-14 |
C00210195
482000040899 |
SPRAY ARM BEARING | Na dotaz | Zadat poptávku | |
307 01760-14 |
C00210439
482000033850 |
UPPER SPRAY ARM | Na dotaz | Zadat poptávku | |
308 01760-14 |
C00210440
482000030321 |
SPRAY ARM SUPPORT | Na dotaz | Zadat poptávku | |
309 01760-14 |
C00210441
481990500196 |
FUNNEL | Na dotaz | Zadat poptávku | |
310 01760-14 |
C00209763 | UPPER BASKET WHEEL | Na dotaz | Zadat poptávku | |
311 01760-14 |
C00128646 | CUTLERY BASKET | Na dotaz | Zadat poptávku |
