WHIRLPOOL G2P 70 F/01 SS OVENS WP
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
Komerční kód: | G2P 70 F/01 SS OVENS WP |
Kód 12NC: | 857795415010 |
Značka: | WHIRLPOOL |
Typ produktu: | Vestavné trouby a varné desky |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
Číslo | Kód | Název | Cena | ||
---|---|---|---|---|---|
022 0 WHR75355 |
C00330807
481246418151 |
Panel side right | Na dotaz | Zadat poptávku | |
022 1 WHR75355 |
C00330808
481246418152 |
Panel side left | Na dotaz | Zadat poptávku | |
022 2 WHR75355 |
C00330809
481246418153 |
Frame post left | Na dotaz | Zadat poptávku | |
022 3 WHR75355 |
C00330810
481246418154 |
Frame post right | Na dotaz | Zadat poptávku | |
022 4 WHR75355 |
C00332759
481281518708 |
Trim side | Na dotaz | Zadat poptávku | |
022 5 WHR75355 |
C00332760
481281518709 |
Plate support | Na dotaz | Zadat poptávku | |
040 0 WHR75355 |
C00312539
481241719298 |
Hinge oven door lower 3/4 | Na dotaz | Zadat poptávku | |
040 1 WHR75355 |
C00313466
481241719299 |
Hinge oven door upper 1/2 3 V | Na dotaz | Zadat poptávku | |
043 0 WHR75355 |
C00329728
481241719297 |
Hinge support oven door | Na dotaz | Zadat poptávku | |
100 0 WHR75355 |
C00603911
481244269518 |
Door complete 3/4. | Na dotaz | Zadat poptávku | |
100 1 WHR75355 |
C00603913
481244269519 |
Door complete 1/2. | Na dotaz | Zadat poptávku | |
110 0 WHR75355 |
C00604080
481249858216 |
Handle SS. | Na dotaz | Zadat poptávku | |
110 1 WHR75355 |
C00314970
481249878634 |
Support support | Na dotaz | Zadat poptávku | |
121 0 WHR75355 |
C00314320
481241619708 |
Door frame inner door 3/4 BL | Na dotaz | Zadat poptávku | |
121 1 WHR75355 |
C00320778
481241619709 |
Door frame inner door 1/2 BL | Na dotaz | Zadat poptávku | |
121 2 WHR75355 |
C00315379
481240418463 |
Door frame inner | Na dotaz | Zadat poptávku | |
121 3 WHR75355 |
C00319055
481240418464 |
Door frame inner | Na dotaz | Zadat poptávku | |
121 4 WHR75355 |
C00316632
481240418465 |
Bracket inner door glass | Na dotaz | Zadat poptávku | |
141 0 WHR75355 |
C00317620
481245058984 |
Oven glass medium | Na dotaz | Zadat poptávku | |
141 1 WHR75355 |
C00317301
481245058985 |
Oven glass medium | Na dotaz | Zadat poptávku | |
142 0 WHR75355 |
C00317740
481245068293 |
Oven glass door glass 3/4 | Na dotaz | Zadat poptávku | |
142 1 WHR75355 |
C00331174
481245068294 |
Oven glass door glass 1/2 | Na dotaz | Zadat poptávku | |
191 0 WHR75355 |
C00312196
481246818347 |
Gasket oven 3/4 | Na dotaz | Zadat poptávku | |
191 1 WHR75355 |
C00312120
481246818345 |
Gasket 1/2 oven | Na dotaz | Zadat poptávku | |
192 0 WHR75355 |
C00311684
481246818346 |
Gasket 3/4 oven | Na dotaz | Zadat poptávku | |
192 1 WHR75355 |
C00312340
481246818348 |
Gasket oven 1/2 | Na dotaz | Zadat poptávku | |
201 0 WHR75355 |
C00327928
481242378009 |
Fan oven diffuser | Na dotaz | Zadat poptávku | |
245 0 WHR75355 |
C00330066
481245819268 |
Oven shelf | Na dotaz | Zadat poptávku | |
245 1 WHR75355 |
C00330064
481245819266 |
Grill grid | Na dotaz | Zadat poptávku | |
247 0 WHR75355 |
C00327791
481241838126 |
Baking tray | Na dotaz | Zadat poptávku | |
247 2 WHR75355 |
C00327929
481242378011 |
Handle baking tray | Na dotaz | Zadat poptávku | |
261 0 WHR75355 |
C00330067
481245819269 |
Inset grid upper cavity | Na dotaz | Zadat poptávku | |
261 2 WHR75355 |
C00328960
481240418118 |
Bracket | Na dotaz | Zadat poptávku | |
261 8 WHR75355 |
C00330065
481245819267 |
Inset grid lower cavity | Na dotaz | Zadat poptávku | |
301 0 WHR75355 |
C00331468
481245350018 |
Control panel support | Na dotaz | Zadat poptávku | |
320 0 WHR75355 |
C00603960
481245350148 |
Control panel SS. | Na dotaz | Zadat poptávku | |
332 0 WHR75355 |
C00314692
481241128945 |
Push button IX | Na dotaz | Zadat poptávku | |
334 0 WHR75355 |
C00487205
481241259138 |
Knob SS | Na dotaz | Zadat poptávku | |
351 0 WHR75355 |
C00311750
481213428063 |
Pilot lamp yellow | Na dotaz | Zadat poptávku | |
354 1 WHR75355 |
C00311674
481221778107 |
Lens lens (yellow) | Na dotaz | Zadat poptávku | |
400 0 WHR75355 |
C00315048
481202858348 |
96ntilator tangential motor | Na dotaz | Zadat poptávku | |
400 1 WHR75355 |
C00326715
481202858349 |
Cover protect. cooling fan | Na dotaz | Zadat poptávku | |
440 0 WHR75355 |
C00311342
481236118457 |
Motor fan complete | Na dotaz | Zadat poptávku | |
451 0 WHR75355 |
C00312315
481225998465 |
Heating element circ. 2000W 230V | Na dotaz | Zadat poptávku | |
452 0 WHR75355 |
C00312039
481225948111 |
Topné těleso trouby – horní + grill | 2 399 Kč
€ 94.70 |
||
456 0 WHR75355 |
C00311969
481225948189 |
Heating element lower | Na dotaz | Zadat poptávku | |
491 0 WHR75355 |
C00314644
481232128427 |
Terminal block + cable | Na dotaz | Zadat poptávku | |
491 1 WHR75355 |
C00327596
481229068306 |
Bracket terminal block | Na dotaz | Zadat poptávku | |
491 2 WHR75355 |
C00327597
481229068307 |
Bracket | Na dotaz | Zadat poptávku | |
500 0 WHR75355 |
C00311891
481221478361 |
Control unit | Na dotaz | Zadat poptávku | |
500 1 WHR75355 |
C00327006
481221478652 |
Support programmer EL. | Na dotaz | Zadat poptávku | |
521 0 WHR75355 |
C00314735
481228208648 |
Switch,oven + thermostat upper | Na dotaz | Zadat poptávku | |
521 1 WHR75355 |
C00497370
481228248285 |
Switch,oven + thermostat lower | Na dotaz | Zadat poptávku | |
522 0 WHR75355 |
C00315975
481227328159 |
REGULATOR | Na dotaz | Zadat poptávku | |
554 1 WHR75355 |
C00315994
481228268022 |
Holder Thermostat | Na dotaz | Zadat poptávku | |
561 0 WHR75355 |
C00317987
481228208633 |
Thermostat safety NA T70 | Na dotaz | Zadat poptávku | |
562 0 WHR75355 |
C00320312
481228248284 |
Thermostat safety 45°C | Na dotaz | Zadat poptávku | |
563 0 WHR75355 |
C00314981
481221538001 |
Thermostat safety T115 | Na dotaz | Zadat poptávku | |
564 0 WHR75355 |
C00327568
481228248287 |
Bezpečnostní termostat 60°C | 898 Kč
€ 35.50 |
||
651 0 WHR75355 |
C00312081
481213428087 |
Lamp,oven | Na dotaz | Zadat poptávku | |
743 0 WHR75355 |
C00316208
481244039495 |
Conveyor air upper | Na dotaz | Zadat poptávku | |
743 1 WHR75355 |
C00328203
481244039496 |
Conveyor air lower | Na dotaz | Zadat poptávku | |
904 0 WHR75355 |
C00330680
481246248433 |
Chimney part condenser | Na dotaz | Zadat poptávku |
