BAUKNECHT GKMT STUTTGART TT
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | GKMT STUTTGART TT |
| Kód 12NC: | 855264001050 |
| Značka: | BAUKNECHT |
| Typ produktu: | Volně stojící mrazáky |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 011 1 WHR98541 |
C00340802
481950018104 |
noha nastavitelna | 189 Kč
€ 7.50 |
||
| 030 0 WHR98541 |
C00591113
481244019722 |
TABLE TOP. | Na dotaz | Zadat poptávku | |
| 032 0 WHR98541 |
C00753354
481244019981 |
Table top | Na dotaz | Zadat poptávku | |
| 033 0 WHR98541 |
C00591162
481244228096 |
Panel insulatin. | Na dotaz | Zadat poptávku | |
| 040 2 WHR98541 |
C00339746
481941719617 |
Hinge,lower | Na dotaz | Zadat poptávku | |
| 045 8 WHR98541 |
C00341440
481953588066 |
Pin hinge | Na dotaz | Zadat poptávku | |
| 047 0 WHR98541 |
C00333266
481952368855 |
drzak dveri levy | 145 Kč
€ 5.70 |
||
| 047 1 WHR98541 |
C00333328
481953268854 |
drzak dveri pravy | 248 Kč
€ 9.80 |
||
| 070 4 WHR98541 |
C00557531
481945858414 |
GRID,AIR.. | Na dotaz | Zadat poptávku | |
| 101 0 WHR98541 |
C00591022
481241618152 |
Door,freezer. | Na dotaz | Zadat poptávku | |
| 102 0 WHR98541 |
C00753343
481244028969 |
Evapor.door | Na dotaz | Zadat poptávku | |
| 102 2 WHR98541 |
C00492281
481940118289 |
SPONA N | Na dotaz | Zadat poptávku | |
| 102 3 WHR98541 |
C00576531
481953598318 |
SPRING.. | Na dotaz | Zadat poptávku | |
| 102 6 WHR98541 |
C00339850
481941719563 |
Hinge | Na dotaz | Zadat poptávku | |
| 102 7 WHR98541 |
C00339851
481941719564 |
Hinge | Na dotaz | Zadat poptávku | |
| 111 0 WHR98541 |
C00496489
481949878088 |
Handle | Na dotaz | Zadat poptávku | |
| 111 4 WHR98541 |
C00490790
481946078242 |
Handle insert | Na dotaz | Zadat poptávku | |
| 156 0 WHR98541 |
C00287849
481941878977 |
miska na led | 300 Kč
€ 11.80 |
||
| 191 0 WHR98541 |
C00492509
481946818065 |
Magnetic seal | Na dotaz | Zadat poptávku | |
| 231 1 WHR98541 |
C00333126
481946688956 |
PLATE THERMOSTAT SENSOR | Na dotaz | Zadat poptávku | |
| 231 2 WHR98541 |
C00343341
481946689101 |
Clamp sensor | Na dotaz | Zadat poptávku | |
| 233 0 WHR98541 |
C00339653
481940479375 |
Holder ,EvaporatorEvaporator | Na dotaz | Zadat poptávku | |
| 233 1 WHR98541 |
C00339620
481940479374 |
drzak vyparniku | 268 Kč
€ 10.60 |
||
| 233 9 WHR98541 |
C00339621
481940479376 |
Holder evaporator | Na dotaz | Zadat poptávku | |
| 242 7 WHR98541 |
C00591360
481941849888 |
DRAWER. | Na dotaz | Zadat poptávku | |
| 242 9 WHR98541 |
C00486649
481945819833 |
Drawer | Na dotaz | Zadat poptávku | |
| 243 6 WHR98541 |
C00591381
481945298809 |
Calendar | Na dotaz | Zadat poptávku | |
| 243 7 WHR98541 |
C00590834
481945298862 |
CALENDAR. | Na dotaz | Zadat poptávku | |
| 252 0 WHR98541 |
C00575016
481941878813 |
KRYT TERMOSTATU N | Na dotaz | Zadat poptávku | |
| 263 0 WHR98541 |
C00340172
481946238886 |
kolejnice kose | Na dotaz | Zadat poptávku | |
| 339 0 WHR98541 |
C00591420
481953598649 |
ROD. | Na dotaz | Zadat poptávku | |
| 350 1 WHR98541 |
C00636123
481927718207 |
SLIDE SWITCH. | Na dotaz | Zadat poptávku | |
| 402 0 WHR98541 |
C00343567
481236058113 |
COMPRESSOR EMU32CLP | Na dotaz | Zadat poptávku | |
| 402 4 WHR98541 |
C00333135
481946689405 |
PRICHYTKA | 120 Kč
€ 4.70 |
||
| 420 0 WHR98541 |
C00574995
481912118248 |
CAPACITOR. | Na dotaz | Zadat poptávku | |
| 491 0 WHR98541 |
C00327312
481229088075 |
Cover connection block | Na dotaz | Zadat poptávku | |
| 554 1 WHR98541 |
C00333185
481949268723 |
pruzina | 472 Kč
€ 18.60 |
||
| 554 2 WHR98541 |
C00492311
481940478507 |
HOLDER | Na dotaz | Zadat poptávku | |
| 561 2 WHR98541 |
C00316074
481929068433 |
Connectionblock | Na dotaz | Zadat poptávku | |
| 566 2 WHR98541 |
C00374330
481927129074 |
termostat A04 | Na dotaz | Zadat poptávku | |
| 614 0 WHR98541 |
C00333356
481969028199 |
Monoblock | Na dotaz | Zadat poptávku | |
| 643 0 WHR98541 |
C00620676
481934938132 |
THERMOMETER. | Na dotaz | Zadat poptávku | |
| 691 3 WHR98541 |
C00591347
481940449162 |
Cover probe. | Na dotaz | Zadat poptávku | |
| 740 0 WHR98541 |
C00498584
481251148212 |
CONDENSER | Na dotaz | Zadat poptávku | |
| 740 3 WHR98541 |
C00333137
481946698259 |
Spacer | Na dotaz | Zadat poptávku | |
| 740 4 WHR98541 |
C00328255
481244048012 |
Holder condenser | Na dotaz | Zadat poptávku | |
| 745 0 WHR98541 |
C00556288
481951138715 |
EVAPORATOR.. | Na dotaz | Zadat poptávku | |
| 764 0 WHR98541 |
C00266743
481948028144 |
Filtr chladničky - patrona | Na dotaz | Zadat poptávku | |
| 781 0 WHR98541 |
C00342193
481953228145 |
Defroster plug | Na dotaz | Zadat poptávku | |
| 781 1 WHR98541 |
C00499108
481941849577 |
ODTOKOVY ZLIABOK N | Na dotaz | Zadat poptávku | |
| 902 5 WHR98541 |
C00591394
481946089118 |
Holder | Na dotaz | Zadat poptávku | |
| 902 6 WHR98541 |
C00591362
481941878929 |
Holder f.calendar. | Na dotaz | Zadat poptávku | |
| 903 0 WHR98541 |
C00333338
481953518117 |
krytka | 20 Kč
€ 0.80 |
||
| 904 0 WHR98541 |
C00344131
481946248377 |
Buffer piece | Na dotaz | Zadat poptávku | |
| 912 2 WHR98541 |
C00333223
481950218494 |
Screw | Na dotaz | Zadat poptávku | |
| 965 3 WHR98541 |
C00336190
481946698669 |
SPACER | Na dotaz | Zadat poptávku | |
| 993 4 WHR98541 |
C00339163
481944229728 |
ICE PACK | Na dotaz | Zadat poptávku | |
| 993 9 WHR98541 |
C00591392
481946078782 |
Calendar (n.shown). | Na dotaz | Zadat poptávku | |
| 999 WHR98541 |
C00769746 | Circuit/Wiring Diagram WHP | Na dotaz | Zadat poptávku | |
