BAUKNECHT KDA 3720/IN-LH CUSTOMIZED REFRIGERAT BK
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | KDA 3720/IN-LH CUSTOMIZED REFRIGERAT BK |
| Kód 12NC: | 855082301030 |
| Značka: | BAUKNECHT |
| Typ produktu: | Volně stojící lednice s mrazákem |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 001 0 WHR80624 |
C00591124
481244068914 |
OUTER COVER ,INOX/LH | Na dotaz | Zadat poptávku | |
| 011 1 WHR80624 |
C00336245
481946699164 |
Small plate | Na dotaz | Zadat poptávku | |
| 011 6 WHR80624 |
C00333081
481946248513 |
noha | 144 Kč
€ 5.70 |
||
| 040 0 WHR80624 |
C00488924
481241718844 |
HINGE,UPPER ,INOX/LH | Na dotaz | Zadat poptávku | |
| 040 2 WHR80624 |
C00339805
481941719647 |
Hinge lower | Na dotaz | Zadat poptávku | |
| 040 3 WHR80624 |
C00339792
481241718915 |
Hinge middle | Na dotaz | Zadat poptávku | |
| 045 5 WHR80624 |
C00344545
481953598677 |
Axle | Na dotaz | Zadat poptávku | |
| 045 8 WHR80624 |
C00330687
481246258004 |
Pin hinge | Na dotaz | Zadat poptávku | |
| 047 0 WHR80624 |
C00328968
481240418414 |
pouzdro dveri | 167 Kč
€ 6.60 |
||
| 047 1 WHR80624 |
C00328967
481240418413 |
drazak dveri pravy | 222 Kč
€ 8.80 |
||
| 070 0 WHR80624 |
C00500845
481244068913 |
SOKEL IX ART676 N | Na dotaz | Zadat poptávku | |
| 084 6 WHR80624 |
C00333281
481952918124 |
krouzek tlumici | 495 Kč
€ 19.50 |
||
| 101 0 WHR80624 |
C00484865
481241619428 |
Door freezer | Na dotaz | Zadat poptávku | |
| 104 0 WHR80624 |
C00496188
481241618879 |
DVERE CHLADNICKY ART676 N | Na dotaz | Zadat poptávku | |
| 105 5 WHR80624 |
C00337806
481946689479 |
Pivot left | Na dotaz | Zadat poptávku | |
| 111 0 WHR80624 |
C00620436
481246268942 |
Door handle freezing | Na dotaz | Zadat poptávku | |
| 111 1 WHR80624 |
C00620437
481246268943 |
Door handle cooling | Na dotaz | Zadat poptávku | |
| 111 2 WHR80624 |
C00490097
481246228411 |
Disc Handle | Na dotaz | Zadat poptávku | |
| 133 7 WHR80624 |
C00337805
481946689478 |
Pivot right | Na dotaz | Zadat poptávku | |
| 153 3 WHR80624 |
C00489015
481241828234 |
Door dairy | Na dotaz | Zadat poptávku | |
| 153 4 WHR80624 |
C00318440
481241828136 |
Door,dairy | 1 349 Kč
€ 53.30 |
||
| 153 5 WHR80624 |
C00329914
481241828301 |
Door dairy smaller,trans.steel blue | Na dotaz | Zadat poptávku | |
| 153 7 WHR80624 |
C00590524
481241828256 |
DOOR,DAIRY. | Na dotaz | Zadat poptávku | |
| 153 9 WHR80624 |
C00620408
481241828302 |
Door dairy bigger,trans.steel blue | Na dotaz | Zadat poptávku | |
| 154 0 WHR80624 |
C00590525
481241828257 |
BOTTLE SHELF. | Na dotaz | Zadat poptávku | |
| 154 1 WHR80624 |
C00491679
481241828516 |
Bottle holder | Na dotaz | Zadat poptávku | |
| 155 0 WHR80624 |
C00329909
481241828013 |
Holder, eggs (6 pcs.) | Na dotaz | Zadat poptávku | |
| 156 0 WHR80624 |
C00287849
481941878977 |
miska na led | 300 Kč
€ 11.80 |
||
| 170 0 WHR80624 |
C00503106
481244068912 |
LISTA KRYCIA IX ART676 N | Na dotaz | Zadat poptávku | |
| 176 0 WHR80624 |
C00503117
481246049615 |
Decor frame left cooling | Na dotaz | Zadat poptávku | |
| 176 2 WHR80624 |
C00464060
481246068584 |
Decor frame ,left | Na dotaz | Zadat poptávku | |
| 191 0 WHR80624 |
C00374352
481246688741 |
Magnetic seal, white 1156,9 x 690,4 mm | Na dotaz | Zadat poptávku | |
| 191 1 WHR80624 |
C00374353
481246688735 |
Magnetic seal, white 410,9 x 690,4 mm | Na dotaz | Zadat poptávku | |
| 242 0 WHR80624 |
C00590523
481241828255 |
DRAWER. | Na dotaz | Zadat poptávku | |
| 245 5 WHR80624 |
C00340292
481945868305 |
Grid | Na dotaz | Zadat poptávku | |
| 245 8 WHR80624 |
C00487574
481241828258 |
Grid | Na dotaz | Zadat poptávku | |
| 249 1 WHR80624 |
C00485878
481246049439 |
Trim grid | Na dotaz | Zadat poptávku | |
| 251 0 WHR80624 |
C00319193
481246048927 |
reflektor | 200 Kč
€ 7.90 |
||
| 252 0 WHR80624 |
C00384845
481246228202 |
THERMOSTATHOUS.WITH 2 OPEN HOLES | Na dotaz | Zadat poptávku | |
| 253 0 WHR80624 |
C00311648
481246228545 |
kryt-plast | 734 Kč
€ 29.00 |
||
| 253 2 WHR80624 |
C00342827
481946288081 |
Cap device | Na dotaz | Zadat poptávku | |
| 255 0 WHR80624 |
C00590631
481245088055 |
GLASS SHELF. | Na dotaz | Zadat poptávku | |
| 255 1 WHR80624 |
C00590630
481245088054 |
SHELF. | Na dotaz | Zadat poptávku | |
| 335 0 WHR80624 |
C00311920
481241078172 |
knoflik termostatu | 605 Kč
€ 23.90 |
||
| 335 6 WHR80624 |
C00312939
481249148014 |
pruzina | 382 Kč
€ 15.10 |
||
| 402 0 WHR80624 |
C00313753
481236058114 |
COMPRESSOR | Na dotaz | Zadat poptávku | |
| 402 1 WHR80624 |
C00319510
481241878958 |
miska na kondenzat | Na dotaz | Zadat poptávku | |
| 420 0 WHR80624 |
C00326781
481212158142 |
Capacitor | Na dotaz | Zadat poptávku | |
| 442 0 WHR80624 |
C00341651
481236118268 |
Motor,fan | Na dotaz | Zadat poptávku | |
| 442 1 WHR80624 |
C00332961
481940479433 |
Holder | Na dotaz | Zadat poptávku | |
| 443 3 WHR80624 |
C00343010
481946288074 |
Cover | Na dotaz | Zadat poptávku | |
| 443 4 WHR80624 |
C00333108
481946288073 |
kryt | 4 697 Kč
€ 185.40 |
||
| 443 5 WHR80624 |
C00333263
481951528289 |
Fan wheel | Na dotaz | Zadat poptávku | |
| 491 0 WHR80624 |
C00267000
481229088084 |
KRYT PLAST | Na dotaz | Zadat poptávku | |
| 554 0 WHR80624 |
C00544921
481228238152 |
Thermostat. | Na dotaz | Zadat poptávku | |
| 561 7 WHR80624 |
C00480850
481929068431 |
KRABICKA SVORKOVNICE AFG527 N | Na dotaz | Zadat poptávku | |
| 614 0 WHR80624 |
C00527059
481228068331 |
Monoblock | Na dotaz | Zadat poptávku | |
| 620 0 WHR80624 |
C00491068
481227328273 |
Switch lamp | Na dotaz | Zadat poptávku | |
| 620 2 WHR80624 |
C00319478
481927618256 |
spinac rychlorozmraz | 204 Kč
€ 8.10 |
||
| 651 0 WHR80624 |
C00311277
481913488135 |
BULB LED E14 T25 - 15W - 220V | Na dotaz | Zadat poptávku | |
| 652 0 WHR80624 |
C00311531
481246698982 |
Držák termostatu | 726 Kč
€ 28.70 |
||
| 655 0 WHR80624 |
C00311795
481227618362 |
Páčka osvětlení | 995 Kč
€ 39.30 |
||
| 740 0 WHR80624 |
C00343544
481251148222 |
CONDENSER | Na dotaz | Zadat poptávku | |
| 740 3 WHR80624 |
C00333148
481946699109 |
Spacer | Na dotaz | Zadat poptávku | |
| 764 2 WHR80624 |
C00266743
481948028144 |
Filtr chladničky - patrona | Na dotaz | Zadat poptávku | |
| 903 0 WHR80624 |
C00333338
481953518117 |
krytka | 20 Kč
€ 0.80 |
||
| 903 4 WHR80624 |
C00333168
481949248154 |
zaslepka | 100 Kč
€ 3.90 |
||
| 912 0 WHR80624 |
C00332066
481250218439 |
Screw M4 X17 | Na dotaz | Zadat poptávku | |
| 965 0 WHR80624 |
C00330502
481246228513 |
Stopper | Na dotaz | Zadat poptávku | |
| 993 2 WHR80624 |
C00316841
481969028169 |
Čistič odtokového kanálku chladničky Whirlpool ARG 790/A+, ARG 734/A+, ARG 184701. | 155 Kč
€ 6.10 |
||
| 993 9 WHR80624 |
C00344675
481931039861 |
Accessories not shown | Na dotaz | Zadat poptávku | |
| 999 WHR80624 |
C00711055 | Circuit/Wiring Diagram WHP | Na dotaz | Zadat poptávku | |
