KITCHENAID KRVX 6030
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | KRVX 6030 |
| Kód 12NC: | 851328315000 |
| Značka: | KITCHENAID |
| Typ produktu: | Vestavné lednice |
| Další podobné modely: | Q0912490000, 851328301000 |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 999 WHR00732 |
C00351066 | SERVICE MANUAL WHP | Na dotaz | Zadat poptávku | |
| B047 WHR00732 |
C00327213
481226278053 |
Filter | Na dotaz | Zadat poptávku | |
| G166 WHR00732 |
C00334587
482000012896 |
PTC-Unit starting device 22V | Na dotaz | Zadat poptávku | |
| G173 WHR00732 |
C00328594
481236039081 |
Evaporator | Na dotaz | Zadat poptávku | |
| G782 WHR00732 |
C00334588
482000012897 |
Compressor DLX 4KK.1 | Na dotaz | Zadat poptávku | |
| K100 WHR00732 |
C00333858
482000009084 |
Rivet BK | Na dotaz | Zadat poptávku | |
| K136 WHR00732 |
C00328540
481232178389 |
Cable harness Lamp | Na dotaz | Zadat poptávku | |
| K143 WHR00732 |
C00317727
481225928963 |
Heating element 220V 24W | Na dotaz | Zadat poptávku | |
| K144 WHR00732 |
C00331063
481244229345 |
Panel Evaporator | Na dotaz | Zadat poptávku | |
| K145 WHR00732 |
C00313861
481236138137 |
Internal fan | Na dotaz | Zadat poptávku | |
| K209 WHR00732 |
C00328539
481232178388 |
Cable harness Ventilator | Na dotaz | Zadat poptávku | |
| K215 WHR00732 |
C00327041
481221778273 |
Housing CB | Na dotaz | Zadat poptávku | |
| K220 WHR00732 |
C00329249
481240478927 |
senzor | 1 013 Kč
€ 40.00 |
||
| K221 WHR00732 |
C00328596
481236039083 |
Bracket Evaporator | Na dotaz | Zadat poptávku | |
| K234 WHR00732 |
C00328825
481236138138 |
Ventilator Condenser | Na dotaz | Zadat poptávku | |
| K246 WHR00732 |
C00329773
481241719495 |
závěs | 640 Kč
€ 25.20 |
||
| K248 WHR00732 |
C00329775
481241719497 |
Hinge top right | Na dotaz | Zadat poptávku | |
| K250 WHR00732 |
C00327321
481229088122 |
Terminal Board | Na dotaz | Zadat poptávku | |
| K251 WHR00732 |
C00332268
481251148474 |
Condenser | Na dotaz | Zadat poptávku | |
| K307 WHR00732 |
C00330233
481245948218 |
Cover top | Na dotaz | Zadat poptávku | |
| K308 WHR00732 |
C00329599
481241610602 |
Door | Na dotaz | Zadat poptávku | |
| K310 WHR00732 |
C00331236
481245088493 |
Shelf small | Na dotaz | Zadat poptávku | |
| K317 WHR00732 |
C00331238
481245088495 |
Rošt | 1 932 Kč
€ 76.20 |
||
| K328 WHR00732 |
C00331237
481245088494 |
Shelf large | Na dotaz | Zadat poptávku | |
| K329 WHR00732 |
C00345858
481249868301 |
Door handle | Na dotaz | Zadat poptávku | |
| K332 WHR00732 |
C00331329
481245228996 |
Control panel | Na dotaz | Zadat poptávku | |
| K384 WHR00732 |
C00334595
482000012909 |
Cable mains UK | Na dotaz | Zadat poptávku | |
| K408 WHR00732 |
C00333878
482000009112 |
Bushing | Na dotaz | Zadat poptávku | |
| K428 WHR00732 |
C00334590
482000012899 |
Modul, vinotéka | Na dotaz | Zadat poptávku | |
| K446 WHR00732 |
C00331655
482000001206 |
Stop door RIGHT | Na dotaz | Zadat poptávku | |
| K447 WHR00732 |
C00331656
482000001207 |
Stop door left | Na dotaz | Zadat poptávku | |
| K523 WHR00732 |
C00334591
482000012900 |
Capacitor 2 MF | Na dotaz | Zadat poptávku | |
| K532 WHR00732 |
C00334592
482000012901 |
Flange ri | Na dotaz | Zadat poptávku | |
| K546 WHR00732 |
C00334593
482000012902 |
Flange le | Na dotaz | Zadat poptávku | |
| K547 WHR00732 |
C00334594
482000012903 |
Control panel thermostat | Na dotaz | Zadat poptávku | |
