| Komerční kód: | SPOW 222 AIR CONDITIONERS |
| Kód 12NC: | 853031701100 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Klimatizace |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 999 WHR22149 |
C00561796 | NTC/PTC Chart WHP | Na dotaz | Zadat poptávku | |
| 999 WHR22149 |
C00561798 | Circuit/Wiring Diagram WHP | Na dotaz | Zadat poptávku | |
| A001 WHR22149 |
C00386051
482000006139 |
Plate mounting | Na dotaz | Zadat poptávku | |
| A002 WHR22149 |
C00386156
482000021494 |
Rear panel | Na dotaz | Zadat poptávku | |
| A003 WHR22149 |
C00386157
482000021496 |
Air guide | Na dotaz | Zadat poptávku | |
| A004 WHR22149 |
C00386054
482000021410 |
Air guide | Na dotaz | Zadat poptávku | |
| A005 WHR22149 |
C00386357
482000021497 |
Air guide | Na dotaz | Zadat poptávku | |
| A006 WHR22149 |
C00385844
481252048018 |
Axis sheath | Na dotaz | Zadat poptávku | |
| A007 WHR22149 |
C00386159
482000021498 |
Fan | Na dotaz | Zadat poptávku | |
| A008 WHR22149 |
C00386059
480150100234 |
Ložisko | Na dotaz | Zadat poptávku | |
| A009 WHR22149 |
C00385811
482000010297 |
Baffle | Na dotaz | Zadat poptávku | |
| A010 WHR22149 |
C00386450
482000091839 |
REFRIGERATION SYSTEM | Na dotaz | Zadat poptávku | |
| A011 WHR22149 |
C00386358
482000021500 |
Cover front | Na dotaz | Zadat poptávku | |
| A012 WHR22149 |
C00386280
482000021392 |
Cap ornamental | Na dotaz | Zadat poptávku | |
| A013 WHR22149 |
C00419624
482000091711 |
Display board | Na dotaz | Zadat poptávku | |
| A014 WHR22149 |
C00417646
482000021501 |
Front panel | Na dotaz | Zadat poptávku | |
| A015 WHR22149 |
C00419685
482000091840 |
Display | Na dotaz | Zadat poptávku | |
| A016 WHR22149 |
C00386282
482000021415 |
Cap ornamental | Na dotaz | Zadat poptávku | |
| A017 WHR22149 |
C00385852
482000091710 |
Keyboard | Na dotaz | Zadat poptávku | |
| A018 WHR22149 |
C00386426
482000091724 |
TEMPERATURE SENSOR | Na dotaz | Zadat poptávku | |
| A019 WHR22149 |
C00386452
482000091841 |
FAN MOTOR | Na dotaz | Zadat poptávku | |
| A020 WHR22149 |
C00386031
482000021401 |
Cover | Na dotaz | Zadat poptávku | |
| A021 WHR22149 |
C00386164
482000021505 |
Protect motor | Na dotaz | Zadat poptávku | |
| A022 WHR22149 |
C00386050
482000021404 |
Deflector | Na dotaz | Zadat poptávku | |
| A023 WHR22149 |
C00386056
482000021411 |
Deflector | Na dotaz | Zadat poptávku | |
| A024 WHR22149 |
C00385842
482000006237 |
Condensed tube | Na dotaz | Zadat poptávku | |
| A025 WHR22149 |
C00386049
482000021506 |
Steppin motor | Na dotaz | Zadat poptávku | |
| A026 WHR22149 |
C00386002
482000021395 |
Elect.parts box plate | Na dotaz | Zadat poptávku | |
| A027 WHR22149 |
C00386010
482000021396 |
KRABICE ELEKTRIKA | Na dotaz | Zadat poptávku | |
| A028 WHR22149 |
C00419686
482000091842 |
Control board indoor | Na dotaz | Zadat poptávku | |
| A029 WHR22149 |
C00386027
482000021398 |
Elect.parts box cover | Na dotaz | Zadat poptávku | |
| A030 WHR22149 |
C00386028
482000021399 |
Elect.parts box cover | Na dotaz | Zadat poptávku | |
| A031,B023 WHR22149 |
C00394929
480150100136 |
Terminal Board | Na dotaz | Zadat poptávku | |
| A032 WHR22149 |
C00386001
482000021394 |
Clamp | Na dotaz | Zadat poptávku | |
| A033 WHR22149 |
C00385999
482000021393 |
Cover | Na dotaz | Zadat poptávku | |
| A034 WHR22149 |
C00386427
482000091843 |
AC POWER CORD | Na dotaz | Zadat poptávku | |
| A035 WHR22149 |
C00378274
482000010320 |
Ovladač dálkový | Na dotaz | Zadat poptávku | |
| A036 WHR22149 |
C00386177
482000021508 |
Filter | Na dotaz | Zadat poptávku | |
| B001 WHR22149 |
C00386086
482000006149 |
Front panel | Na dotaz | Zadat poptávku | |
| B002 WHR22149 |
C00409813
482000006241 |
Base | Na dotaz | Zadat poptávku | |
| B003 WHR22149 |
C00386432
482000021282 |
Axial flow fan | Na dotaz | Zadat poptávku | |
| B004 WHR22149 |
C00409766
482000006152 |
Motor fan | Na dotaz | Zadat poptávku | |
| B005 WHR22149 |
C00386434
482000021283 |
Bracket motor | Na dotaz | Zadat poptávku | |
| B006 WHR22149 |
C00419687
482000091844 |
Condenser assy | Na dotaz | Zadat poptávku | |
| B007 WHR22149 |
C00406880
482000000341 |
Grid air REAR | Na dotaz | Zadat poptávku | |
| B008 WHR22149 |
C00386113
482000006156 |
Cover top | Na dotaz | Zadat poptávku | |
| B009 WHR22149 |
C00386098
482000006157 |
Plate mounting | Na dotaz | Zadat poptávku | |
| B010 WHR22149 |
C00409815
482000006243 |
Separator | Na dotaz | Zadat poptávku | |
| B011 WHR22149 |
C00386472
482000091845 |
COMPRESSOR | Na dotaz | Zadat poptávku | |
| B012 WHR22149 |
C00409770
482000006160 |
Cable | Na dotaz | Zadat poptávku | |
| B013 WHR22149 |
C00409817
482000006245 |
Valve 3 Way | Na dotaz | Zadat poptávku | |
| B014 WHR22149 |
C00419688
482000091846 |
Pipe assy | Na dotaz | Zadat poptávku | |
| B015 WHR22149 |
C00409819
482000006247 |
Panel side | Na dotaz | Zadat poptávku | |
| B016 WHR22149 |
C00385959
480150100575 |
Cover | Na dotaz | Zadat poptávku | |
| B017 WHR22149 |
C00419689
482000091847 |
Valve 2-way stop | Na dotaz | Zadat poptávku | |
| B018 WHR22149 |
C00406887
482000000349 |
Valve body 4-WAY | Na dotaz | Zadat poptávku | |
| B019 WHR22149 |
C00394954
480150100172 |
Coil Valve | Na dotaz | Zadat poptávku | |
| B020 WHR22149 |
C00419690
482000091848 |
Valve 4-way assy | Na dotaz | Zadat poptávku | |
| B021 WHR22149 |
C00419684
482000091838 |
Capacitor | Na dotaz | Zadat poptávku | |
| B022 WHR22149 |
C00386438
482000006167 |
Elect.parts box | Na dotaz | Zadat poptávku | |
| B024 WHR22149 |
C00386440
482000006168 |
Capacitor Fan | Na dotaz | Zadat poptávku | |
