WHIRLPOOL SPOW 224/3
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | SPOW 224/3 |
| Kód 12NC: | 853005879000 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Klimatizace |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 999 WHR22075 |
C00561926 | NTC/PTC Chart WHP | Na dotaz | Zadat poptávku | |
| 999 WHR22075 |
C00561929 | Circuit/Wiring Diagram WHP | Na dotaz | Zadat poptávku | |
| A01 WHR22075 |
C00386051
482000006139 |
Plate mounting | Na dotaz | Zadat poptávku | |
| A02 WHR22075 |
C00386156
482000021494 |
Rear panel | Na dotaz | Zadat poptávku | |
| A03 WHR22075 |
C00386157
482000021496 |
Air guide | Na dotaz | Zadat poptávku | |
| A04 WHR22075 |
C00386054
482000021410 |
Air guide | Na dotaz | Zadat poptávku | |
| A05 WHR22075 |
C00386357
482000021497 |
Air guide | Na dotaz | Zadat poptávku | |
| A06 WHR22075 |
C00385844
481252048018 |
Axis sheath | Na dotaz | Zadat poptávku | |
| A07 WHR22075 |
C00386159
482000021498 |
Fan | Na dotaz | Zadat poptávku | |
| A08 WHR22075 |
C00386059
480150100234 |
Ložisko | Na dotaz | Zadat poptávku | |
| A09 WHR22075 |
C00385811
482000010297 |
Baffle | Na dotaz | Zadat poptávku | |
| A10 WHR22075 |
C00386450
482000091839 |
REFRIGERATION SYSTEM | Na dotaz | Zadat poptávku | |
| A10 WHR22075 |
C00503735
482000093965 |
Evaporator | Na dotaz | Zadat poptávku | |
| A11 WHR22075 |
C00386358
482000021500 |
Cover front | Na dotaz | Zadat poptávku | |
| A12 WHR22075 |
C00386280
482000021392 |
Cap ornamental | Na dotaz | Zadat poptávku | |
| A13 WHR22075 |
C00419624
482000091711 |
Display board | Na dotaz | Zadat poptávku | |
| A14 WHR22075 |
C00417646
482000021501 |
Front panel | Na dotaz | Zadat poptávku | |
| A15 WHR22075 |
C00419685
482000091840 |
Display | Na dotaz | Zadat poptávku | |
| A16 WHR22075 |
C00386282
482000021415 |
Cap ornamental | Na dotaz | Zadat poptávku | |
| A17 WHR22075 |
C00385852
482000091710 |
Keyboard | Na dotaz | Zadat poptávku | |
| A18 WHR22075 |
C00386426
482000091724 |
TEMPERATURE SENSOR | Na dotaz | Zadat poptávku | |
| A19 WHR22075 |
C00386452
482000091841 |
FAN MOTOR | Na dotaz | Zadat poptávku | |
| A20 WHR22075 |
C00386031
482000021401 |
Cover | Na dotaz | Zadat poptávku | |
| A21 WHR22075 |
C00386164
482000021505 |
Protect motor | Na dotaz | Zadat poptávku | |
| A22 WHR22075 |
C00386050
482000021404 |
Deflector | Na dotaz | Zadat poptávku | |
| A23 WHR22075 |
C00386056
482000021411 |
Deflector | Na dotaz | Zadat poptávku | |
| A24 WHR22075 |
C00385842
482000006237 |
Condensed tube | Na dotaz | Zadat poptávku | |
| A25 WHR22075 |
C00386049
482000021506 |
Steppin motor | Na dotaz | Zadat poptávku | |
| A26 WHR22075 |
C00386002
482000021395 |
Elect.parts box plate | Na dotaz | Zadat poptávku | |
| A27 WHR22075 |
C00386010
482000021396 |
KRABICE ELEKTRIKA | Na dotaz | Zadat poptávku | |
| A28 WHR22075 |
C00419694
482000091856 |
Control board indoor | Na dotaz | Zadat poptávku | |
| A29 WHR22075 |
C00386027
482000021398 |
Elect.parts box cover | Na dotaz | Zadat poptávku | |
| A30 WHR22075 |
C00386028
482000021399 |
Elect.parts box cover | Na dotaz | Zadat poptávku | |
| A31 WHR22075 |
C00386421
480150100141 |
Terminal Board | Na dotaz | Zadat poptávku | |
| A32 WHR22075 |
C00386001
482000021394 |
Clamp | Na dotaz | Zadat poptávku | |
| A33 WHR22075 |
C00385999
482000021393 |
Cover | Na dotaz | Zadat poptávku | |
| A34 WHR22075 |
C00386427
482000091843 |
AC POWER CORD | Na dotaz | Zadat poptávku | |
| A35 WHR22075 |
C00378274
482000010320 |
Ovladač dálkový | Na dotaz | Zadat poptávku | |
| B01 WHR22075 |
C00503736
482000093966 |
Panel PARTS | Na dotaz | Zadat poptávku | |
| B02 WHR22075 |
C00503737
482000093967 |
Fan BLADES | Na dotaz | Zadat poptávku | |
| B03 WHR22075 |
C00503738
482000093968 |
Motor fan | Na dotaz | Zadat poptávku | |
| B04 WHR22075 |
C00503739
482000093969 |
Support motor | Na dotaz | Zadat poptávku | |
| B05 WHR22075 |
C00503740
482000093970 |
Base HOLDER | Na dotaz | Zadat poptávku | |
| B06 WHR22075 |
C00503741
482000093971 |
Plate mounting | Na dotaz | Zadat poptávku | |
| B07 WHR22075 |
C00503742
482000093972 |
Condenser | Na dotaz | Zadat poptávku | |
| B08 WHR22075 |
C00503743
482000093973 |
Board printed UPPER | Na dotaz | Zadat poptávku | |
| B09 WHR22075 |
C00503744
482000093974 |
Cover | Na dotaz | Zadat poptávku | |
| B10 WHR22075 |
C00503745
482000093975 |
Cover Right | Na dotaz | Zadat poptávku | |
| B11 WHR22075 |
C00503746
482000093976 |
kryt | 240 Kč
€ 9.50 |
||
| B12 WHR22075 |
C00503747
482000093977 |
Terminal board | Na dotaz | Zadat poptávku | |
| B13 WHR22075 |
C00503748
482000093978 |
Electronic box | Na dotaz | Zadat poptávku | |
| B14 WHR22075 |
C00386439
480150100206 |
Capacitor | Na dotaz | Zadat poptávku | |
| B15 WHR22075 |
C00386467
482000013806 |
Capacitor Fan | Na dotaz | Zadat poptávku | |
| B16 WHR22075 |
C00503749
482000093979 |
Valve 2-WAY | Na dotaz | Zadat poptávku | |
| B17 WHR22075 |
C00503750
482000093980 |
Valve 3-WAY | Na dotaz | Zadat poptávku | |
| B18 WHR22075 |
C00503751
482000093981 |
Compressor tube | Na dotaz | Zadat poptávku | |
| B19 WHR22075 |
C00503752
482000093982 |
Wire | Na dotaz | Zadat poptávku | |
| B20 WHR22075 |
C00386472
482000091845 |
COMPRESSOR | Na dotaz | Zadat poptávku | |
| B21 WHR22075 |
C00503753
482000093983 |
Cover | Na dotaz | Zadat poptávku | |
