IGNIS TGA 3500NF/EG
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | TGA 3500NF/EG |
| Kód 12NC: | 853923901200 |
| Značka: | IGNIS |
| Typ produktu: | Volně stojící lednice s mrazákem |
| Další podobné modely: | 853923901201 |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 0040 WHR14953 |
C00330828
481246428054 |
drzak kompr.a kolec | 925 Kč
€ 36.50 |
||
| 0110 WHR14953 |
C00330455
481246218263 |
noha lednice | 138 Kč
€ 5.40 |
||
| 0121 WHR14953 |
C00332373
481252878062 |
kolecko lednice | 530 Kč
€ 20.90 |
||
| 0122 WHR14953 |
C00332726
481253578074 |
osa kolecka lednice | 430 Kč
€ 17.00 |
||
| 0400 WHR14953 |
C00329779
481241719517 |
Závěs horní | 934 Kč
€ 36.90 |
||
| 0402 WHR14953 |
C00329780
481241719518 |
Závěs spodní | 976 Kč
€ 38.50 |
||
| 0403 WHR14953 |
C00319920
481241719519 |
Závěs dveří střední | 976 Kč
€ 38.50 |
||
| 0452 WHR14953 |
C00316600
481222608025 |
cep | 413 Kč
€ 16.30 |
||
| 1020 WHR14953 |
C00433005
480132103257 |
DVEŘE MRAZNIČKY GW | Na dotaz | Zadat poptávku | |
| 1040 WHR14953 |
C00435630
481010369828 |
DVEŘE CHLADNIČKY, BÍLÁ GW | Na dotaz | Zadat poptávku | |
| 1050 WHR14953 |
C00314960
481253288064 |
BUSHING WHITE GW | Na dotaz | Zadat poptávku | |
| 1051 WHR14953 |
C00332709
481253288102 |
SLEEVE DOOR AUTO-LOCKING RIGHT WHITE GW | Na dotaz | Zadat poptávku | |
| 1052 WHR14953 |
C00332710
481253288103 |
SLEEVE DOOR AUTO-LOCKING LEFT WHITE GW | Na dotaz | Zadat poptávku | |
| 1100 WHR14953 |
C00435625
481010369812 |
Handle upper GW+green ring | Na dotaz | Zadat poptávku | |
| 1101 WHR14953 |
C00435632
481010369837 |
Handle lower GW+green ring | Na dotaz | Zadat poptávku | |
| 1117 WHR14953 |
C00435622
481010369805 |
LOGO IGNIS | Na dotaz | Zadat poptávku | |
| 1118 WHR14953 |
C00433030
480132103307 |
Handle cover GW | Na dotaz | Zadat poptávku | |
| 1521 WHR14953 |
C00374581
481052388111 |
Bottle shelf 00136 TRANSPAR.GREY | Na dotaz | Zadat poptávku | |
| 1522 WHR14953 |
C00329893
481241820162 |
Door dairy | Na dotaz | Zadat poptávku | |
| 1525 WHR14953 |
C00323999
481010369814 |
Separator 50372 GREY ASPES | Na dotaz | Zadat poptávku | |
| 1551 WHR14953 |
C00323386
480132101126 |
police | 918 Kč
€ 36.20 |
||
| 1560 WHR14953 |
C00322568
480132103428 |
Miska na led | Na dotaz | Zadat poptávku | |
| 1910 WHR14953 |
C00323450
480132101354 |
Těsnění magnetické | 2 311 Kč
€ 91.20 |
||
| 1911 WHR14953 |
C00311941
481246668939 |
Magnetické těsnění dveří mrazáku | 1 697 Kč
€ 67.00 |
||
| 2010 WHR14953 |
C00323522
480132101591 |
kryt | 341 Kč
€ 13.50 |
||
| 2410 WHR14953 |
C00435728
481010377017 |
Drawer CENTRAL,WITH STICKER | Na dotaz | Zadat poptávku | |
| 2411 WHR14953 |
C00432344
480132101644 |
Drawer upper,transparent grey | Na dotaz | Zadat poptávku | |
| 2412 WHR14953 |
C00323396
480132101145 |
Koš mrazničky - spodní | 2 755 Kč
€ 108.80 |
||
| 2420 WHR14953 |
C00323383
480132101122 |
Crisper | Na dotaz | Zadat poptávku | |
| 2440 WHR14953 |
C00324012
481010373117 |
Crisper cover +GREEN ASP, PROFILE | Na dotaz | Zadat poptávku | |
| 2442 WHR14953 |
C00324011
481010373104 |
Glass shelf + GW&GREEN ASP,PROFI | Na dotaz | Zadat poptávku | |
| 2448 WHR14953 |
C00435685
481010372010 |
Shelf NET | Na dotaz | Zadat poptávku | |
| 2456 WHR14953 |
C00323526
480132101613 |
police | 380 Kč
€ 15.00 |
||
| 2493 WHR14953 |
C00432174
480132101165 |
Trim Shelf front dark silver | Na dotaz | Zadat poptávku | |
| 2494 WHR14953 |
C00324000
481010369846 |
Trim Shelf front, 50372 GREEN ASPES | Na dotaz | Zadat poptávku | |
| 2498 WHR14953 |
C00320108
480132101162 |
Trim Shelf rear GW | Na dotaz | Zadat poptávku | |
| 2520 WHR14953 |
C00314820
481244098377 |
Konzole světla | 1 368 Kč
€ 54.00 |
||
| 2521 WHR14953 |
C00315422
481246098137 |
Cover f. lamp white translucent | Na dotaz | Zadat poptávku | |
| 2551 WHR14953 |
C00432171
480132101132 |
Glass shelf +GW & dark silv.profiles | Na dotaz | Zadat poptávku | |
| 2613 WHR14953 |
C00316805
480132101137 |
pojezd | 750 Kč
€ 29.60 |
||
| 3010 WHR14953 |
C00435636
481010369857 |
Control panel GW cpl. VB A+ | Na dotaz | Zadat poptávku | |
| 3011 WHR14953 |
C00435623
481010369807 |
Insert printed NIGHT TARIFF | Na dotaz | Zadat poptávku | |
| 3014 WHR14953 |
C00328160
481244029575 |
kryt | 189 Kč
€ 7.50 |
||
| 3015 WHR14953 |
C00328161
481244029576 |
kryt | 347 Kč
€ 13.70 |
||
| 3231 WHR14953 |
C00323408
480132101174 |
Sticker | Na dotaz | Zadat poptávku | |
| 4020 WHR14953 |
C00313753
481236058114 |
COMPRESSOR | Na dotaz | Zadat poptávku | |
| 4021 WHR14953 |
C00319502
481241870024 |
miska na kondenzat | 388 Kč
€ 15.30 |
||
| 4022 WHR14953 |
C00318606
480132101608 |
ventil | Na dotaz | Zadat poptávku | |
| 4200 WHR14953 |
C00278650
481212018029 |
Kondenzátor 4uF | Na dotaz | Zadat poptávku | |
| 4400 WHR14953 |
C00316811
480132101184 |
Fan box GW cpl. VELA with switch | Na dotaz | Zadat poptávku | |
| 4425 WHR14953 |
C00326500
481052822191 |
ventilator mrazaku | 2 586 Kč
€ 102.10 |
||
| 4430 WHR14953 |
C00317570
481052820911 |
FAN BLADE D100 | Na dotaz | Zadat poptávku | |
| 4912 WHR14953 |
C00323411
480132101182 |
Cover GW | Na dotaz | Zadat poptávku | |
| 4913 WHR14953 |
C00267000
481229088084 |
KRYT PLAST | Na dotaz | Zadat poptávku | |
| 5210 WHR14953 |
C00448370
481052820281 |
Modul Hercules | 1 145 Kč
€ 45.20 |
||
| 5612 WHR14953 |
C00267004
481229088112 |
konektor | 175 Kč
€ 6.90 |
||
| 5620 WHR14953 |
C00314313
481010371493 |
Thermofuse+bimetal LCNF with plug 9 pins | Na dotaz | Zadat poptávku | |
| 6140 WHR14953 |
C00327478
481228038119 |
Monoblock | Na dotaz | Zadat poptávku | |
| 6510 WHR14953 |
C00311277
481913488135 |
BULB LED E14 T25 - 15W - 220V | Na dotaz | Zadat poptávku | |
| 6520 WHR14953 |
C00313006
481225518292 |
objimka zarovky | 238 Kč
€ 9.40 |
||
| 6550 WHR14953 |
C00319786
480132100727 |
spinac svetla | 251 Kč
€ 9.90 |
||
| 6914 WHR14953 |
C00323439
480132101294 |
kryt | 569 Kč
€ 22.50 |
||
| 6917 WHR14953 |
C00314452
481231019153 |
senzor | 1 225 Kč
€ 48.40 |
||
| 7400 WHR14953 |
C00332248
481251148411 |
Condenser | Na dotaz | Zadat poptávku | |
| 7401 WHR14953 |
C00330558
481246228822 |
doraz | 150 Kč
€ 5.90 |
||
| 7430 WHR14953 |
C00322559
480132103293 |
Cover multiflow | Na dotaz | Zadat poptávku | |
| 7431 WHR14953 |
C00317574
481052822111 |
Kryt do mrazničky | Na dotaz | Zadat poptávku | |
| 7460 WHR14953 |
C00319350
481010369508 |
Evaporator kit LCNF+bimetal+fuse+heater | Na dotaz | Zadat poptávku | |
| 7464 WHR14953 |
C00319325
481246098055 |
Podpora koše mrazničky | 191 Kč
€ 7.50 |
||
| 7640 WHR14953 |
C00318890
481010369557 |
FILTRDEHYDRÁTOR | Na dotaz | Zadat poptávku | |
| 7810 WHR14953 |
C00323524
480132101595 |
CONDENSATE DRAIN TUBE | Na dotaz | Zadat poptávku | |
| 7830 WHR14953 |
C00313237
481281719208 |
VALVE, 1/4 BODY+TUBE 100MM | Na dotaz | Zadat poptávku | |
| 9040 WHR14953 |
C00433031
480132103308 |
cover hinge GW left | Na dotaz | Zadat poptávku | |
| 9041 WHR14953 |
C00433032
480132103309 |
Cover hinge GW right | Na dotaz | Zadat poptávku | |
| 9650 WHR14953 |
C00327078
481222608017 |
zaslepka | 146 Kč
€ 5.80 |
||
| 9651 WHR14953 |
C00323643
480132102378 |
zaslepka | 879 Kč
€ 34.70 |
||
| 9652 WHR14953 |
C00316614
481222608029 |
zaslepka | 298 Kč
€ 11.80 |
||
| 999 WHR14953 |
C00346098 | NTC/PTC Chart WHP | Na dotaz | Zadat poptávku | |
| 999 WHR14953 |
C00347090 | Circuit/Wiring Diagram WHP | Na dotaz | Zadat poptávku | |
