BAUKNECHT UGI 1040/B
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
Komerční kód: | UGI 1040/B |
Kód 12NC: | 855268801000 |
Značka: | BAUKNECHT |
Typ produktu: | Vestavné mrazáky |
Další podobné modely: | 855268801002, 855268801003, 855268801001, 855268801009, 855268801005, 855268801006, 855268801007, 855268801008 |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
Číslo | Kód | Název | Cena | ||
---|---|---|---|---|---|
003 1 WHR86454 |
C00337466
481946049686 |
Trim, upper | Na dotaz | Zadat poptávku | |
011 0 WHR86454 |
C00311579
481950018141 |
Noha vestavné chladničky Whirlpool AFB 821/1, AFB 8281, ARG 913/A+, ARG 913 1, ARZ 005/A+ | 85 Kč
€ 3.40 |
||
040 1 WHR86454 |
C00310966
481231018672 |
Závěs dveří - sada 481231018672 | Na dotaz | Zadat poptávku | |
045 9 WHR86454 |
C00315522
481241778065 |
Čep | Na dotaz | Zadat poptávku | |
051 0 WHR86454 |
C00333116
481946418163 |
Base | Na dotaz | Zadat poptávku | |
065 0 WHR86454 |
C00333279
481952918041 |
Buffer piece | Na dotaz | Zadat poptávku | |
070 0 WHR86454 |
C00337695
481944269341 |
Plinth | Na dotaz | Zadat poptávku | |
070 2 WHR86454 |
C00337694
481944228604 |
Plinth | Na dotaz | Zadat poptávku | |
070 3 WHR86454 |
C00333019
481944229927 |
Kryt | Na dotaz | Zadat poptávku | |
070 5 WHR86454 |
C00333319
481953268472 |
Spacer | Na dotaz | Zadat poptávku | |
084 3 WHR86454 |
C00333073
481946248211 |
gufero | 121 Kč
€ 4.80 |
||
101 0 WHR86454 |
C00497731
481241618527 |
DVERE MRAZIAKA | Na dotaz | Zadat poptávku | |
105 7 WHR86454 |
C00330486
481246228381 |
Excenter | Na dotaz | Zadat poptávku | |
111 4 WHR86454 |
C00333061
481946049859 |
Nameplate | Na dotaz | Zadat poptávku | |
156 0 WHR86454 |
C00287849
481941878977 |
miska na led | 300 Kč
€ 11.80 |
||
170 7 WHR86454 |
C00337470
481946088703 |
Trim, side | Na dotaz | Zadat poptávku | |
191 1 WHR86454 |
C00312856
481946818162 |
Těsnění magnetické | 2 394 Kč
€ 94.50 |
||
231 3 WHR86454 |
C00333124
481946688704 |
Clamp sensor thermostat | Na dotaz | Zadat poptávku | |
242 7 WHR86454 |
C00341247
481941849693 |
Drawer | Na dotaz | Zadat poptávku | |
242 9 WHR86454 |
C00591096
481241868269 |
DRAWER. | Na dotaz | Zadat poptávku | |
249 1 WHR86454 |
C00498305
481245948134 |
Profile | Na dotaz | Zadat poptávku | |
249 2 WHR86454 |
C00320056
481946088126 |
Trim short | Na dotaz | Zadat poptávku | |
252 1 WHR86454 |
C00333095
481946279338 |
kryt | 121 Kč
€ 4.80 |
||
263 0 WHR86454 |
C00336947
481240448582 |
Rail | Na dotaz | Zadat poptávku | |
263 2 WHR86454 |
C00340907
481946698401 |
Fixation basket ri. | Na dotaz | Zadat poptávku | |
263 3 WHR86454 |
C00340908
481946698399 |
Fixation basket le. | Na dotaz | Zadat poptávku | |
339 0 WHR86454 |
C00333349
481953598346 |
Rod | Na dotaz | Zadat poptávku | |
350 1 WHR86454 |
C00312136
481228018015 |
jednotka signalek | 4 073 Kč
€ 160.80 |
||
402 0 WHR86454 |
C00555088
481236038767 |
Compressor EMT40CLP.. | Na dotaz | Zadat poptávku | |
402 3 WHR86454 |
C00333348
481953598345 |
Fastener | Na dotaz | Zadat poptávku | |
402 4 WHR86454 |
C00333135
481946689405 |
PRICHYTKA | 120 Kč
€ 4.70 |
||
442 0 WHR86454 |
C00314229
481936178144 |
motorek ventilatoru | 2 193 Kč
€ 86.60 |
||
442 1 WHR86454 |
C00332945
481940478859 |
drzak | 169 Kč
€ 6.70 |
||
491 0 WHR86454 |
C00327312
481229088075 |
Cover connection block | Na dotaz | Zadat poptávku | |
554 1 WHR86454 |
C00333185
481949268723 |
pruzina | 472 Kč
€ 18.60 |
||
561 7 WHR86454 |
C00480850
481929068431 |
KRABICKA SVORKOVNICE AFG527 N | Na dotaz | Zadat poptávku | |
566 2 WHR86454 |
C00311565
481927129106 |
Thermostat A04-391 | Na dotaz | Zadat poptávku | |
614 0 WHR86454 |
C00333354
481969028196 |
Monoblock | Na dotaz | Zadat poptávku | |
740 0 WHR86454 |
C00332232
481251148279 |
Condenser | Na dotaz | Zadat poptávku | |
745 0 WHR86454 |
C00332193
481251138146 |
vyparnik | 3 359 Kč
€ 132.60 |
||
745 1 WHR86454 |
C00333321
481953268708 |
Bushing | Na dotaz | Zadat poptávku | |
745 3 WHR86454 |
C00332389
481252928038 |
Hose | Na dotaz | Zadat poptávku | |
764 2 WHR86454 |
C00266743
481948028144 |
Filtr chladničky - patrona | Na dotaz | Zadat poptávku | |
910 0 WHR86454 |
C00336700
481252318037 |
Screw | Na dotaz | Zadat poptávku | |
910 1 WHR86454 |
C00332310
481252388004 |
Screw M5X18,5M5X18,5 | Na dotaz | Zadat poptávku | |
965 3 WHR86454 |
C00336186
481946698398 |
Spacer f. drawer | Na dotaz | Zadat poptávku | |
965 5 WHR86454 |
C00333278
481952918039 |
Spacer | Na dotaz | Zadat poptávku | |
993 4 WHR86454 |
C00333018
481944229733 |
miska na led | 708 Kč
€ 28.00 |
||
993 9 WHR86454 |
C00344666
481231018802 |
Accessory (n.shown) | Na dotaz | Zadat poptávku | |
999 WHR86454 |
C00724066 | Circuit/Wiring Diagram WHP | Na dotaz | Zadat poptávku |
