WHIRLPOOL VS 400 IX
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | VS 400 IX |
| Kód 12NC: | 850123784020 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Volně stojící lednice s mrazákem |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 011 0 WHR62118 |
C00330451
481246218246 |
Foot | Na dotaz | Zadat poptávku | |
| 012 0 WHR62118 |
C00332374
481252878071 |
Roller | Na dotaz | Zadat poptávku | |
| 012 1 WHR62118 |
C00332719
481253548034 |
Shaft roller | Na dotaz | Zadat poptávku | |
| 012 3 WHR62118 |
C00332375
481252878072 |
Roller | Na dotaz | Zadat poptávku | |
| 024 0 WHR62118 |
C00330760
481246279911 |
Cover right IN | Na dotaz | Zadat poptávku | |
| 024 1 WHR62118 |
C00330761
481246279912 |
Cover left IN | Na dotaz | Zadat poptávku | |
| 040 0 WHR62118 |
C00329726
481241719286 |
Hinge upper | Na dotaz | Zadat poptávku | |
| 040 1 WHR62118 |
C00330766
481246279929 |
kryt | 108 Kč
€ 4.30 |
||
| 040 2 WHR62118 |
C00329724
481241719284 |
pant | 525 Kč
€ 20.70 |
||
| 040 3 WHR62118 |
C00330767
481246279931 |
Cover IN | Na dotaz | Zadat poptávku | |
| 040 4 WHR62118 |
C00492112
481253288015 |
Bushing | Na dotaz | Zadat poptávku | |
| 040 5 WHR62118 |
C00377659
481241719326 |
Hinge middle | Na dotaz | Zadat poptávku | |
| 040 6 WHR62118 |
C00329721
481241719278 |
Pin hinge lower | Na dotaz | Zadat poptávku | |
| 042 0 WHR62118 |
C00377702
481244011748 |
Kit door reversal | Na dotaz | Zadat poptávku | |
| 047 0 WHR62118 |
C00332696
481253288051 |
Bushing IN | Na dotaz | Zadat poptávku | |
| 047 1 WHR62118 |
C00332699
481253288065 |
Cover bushing IN | Na dotaz | Zadat poptávku | |
| 047 2 WHR62118 |
C00317580
481244688153 |
Pouzdro | 407 Kč
€ 16.10 |
||
| 047 3 WHR62118 |
C00329809
481241778146 |
Stop door left | Na dotaz | Zadat poptávku | |
| 086 0 WHR62118 |
C00329054
481240448923 |
Support | Na dotaz | Zadat poptávku | |
| 086 1 WHR62118 |
C00332711
481253538083 |
Pin | Na dotaz | Zadat poptávku | |
| 086 2 WHR62118 |
C00327081
481222608024 |
Pin rail | Na dotaz | Zadat poptávku | |
| 101 0 WHR62118 |
C00402595
481241610644 |
Door freezer IN | Na dotaz | Zadat poptávku | |
| 103 0 WHR62118 |
C00403629
481244229346 |
Drawer fast freezing | Na dotaz | Zadat poptávku | |
| 104 0 WHR62118 |
C00402594
481241610643 |
Door refriger. IN | Na dotaz | Zadat poptávku | |
| 110 0 WHR62118 |
C00405351
481249818778 |
Handle freezer door | Na dotaz | Zadat poptávku | |
| 110 1 WHR62118 |
C00405352
481249818779 |
Handle refrigerator door | Na dotaz | Zadat poptávku | |
| 111 7 WHR62118 |
C00404499
481245918302 |
Nameplate Whirlpool | Na dotaz | Zadat poptávku | |
| 152 0 WHR62118 |
C00403057
481241848962 |
Shelf freezer door | Na dotaz | Zadat poptávku | |
| 152 1 WHR62118 |
C00403058
481241848963 |
Shelf refrigerator door | Na dotaz | Zadat poptávku | |
| 152 2 WHR62118 |
C00491685
481241828807 |
Holder can | Na dotaz | Zadat poptávku | |
| 152 3 WHR62118 |
C00403061
481241848966 |
Shelf refrigerator door | Na dotaz | Zadat poptávku | |
| 152 4 WHR62118 |
C00377694
481241848967 |
Shelf for bottles | Na dotaz | Zadat poptávku | |
| 152 5 WHR62118 |
C00403060
481241848965 |
Separator | Na dotaz | Zadat poptávku | |
| 152 6 WHR62118 |
C00402917
481241828903 |
Separator Bottle shelf | Na dotaz | Zadat poptávku | |
| 156 0 WHR62118 |
C00403059
481241848964 |
Rack egg | Na dotaz | Zadat poptávku | |
| 191 0 WHR62118 |
C00340400
481246818325 |
Těsnění dveří mrazničky | 2 216 Kč
€ 87.50 |
||
| 191 1 WHR62118 |
C00340434
481246818326 |
Těsnění dveří chladničky | 2 220 Kč
€ 87.60 |
||
| 239 0 WHR62118 |
C00377668
481241820022 |
Ice maker | Na dotaz | Zadat poptávku | |
| 239 2 WHR62118 |
C00401943
481240438814 |
Support ice maker | Na dotaz | Zadat poptávku | |
| 239 3 WHR62118 |
C00377667
481241820021 |
Tray ice cubes | Na dotaz | Zadat poptávku | |
| 241 0 WHR62118 |
C00402827
481241820019 |
Drawer refrigerator | Na dotaz | Zadat poptávku | |
| 241 1 WHR62118 |
C00402825
481241820017 |
Shelf fast freezing | Na dotaz | Zadat poptávku | |
| 242 0 WHR62118 |
C00403056
481241848961 |
Drawer vegetables | Na dotaz | Zadat poptávku | |
| 242 1 WHR62118 |
C00377724
481244229347 |
Front panel Crisper | Na dotaz | Zadat poptávku | |
| 242 2 WHR62118 |
C00402826
481241820018 |
Spacer vegetable drawer | Na dotaz | Zadat poptávku | |
| 255 0 WHR62118 |
C00377760
481245088505 |
Glass shelf | Na dotaz | Zadat poptávku | |
| 255 1 WHR62118 |
C00403865
481245088504 |
Cover vegetable drawer | Na dotaz | Zadat poptávku | |
| 256 1 WHR62118 |
C00319191
481246048883 |
Support Air clean filt. | Na dotaz | Zadat poptávku | |
| 256 2 WHR62118 |
C00330243
481246048886 |
Cover | Na dotaz | Zadat poptávku | |
| 256 3 WHR62118 |
C00403556
481244079322 |
Slide Regulator | Na dotaz | Zadat poptávku | |
| 301 0 WHR62118 |
C00403912
481245228816 |
Reflector | Na dotaz | Zadat poptávku | |
| 301 1 WHR62118 |
C00500899
481246469119 |
Console silver | Na dotaz | Zadat poptávku | |
| 331 0 WHR62118 |
C00329463
481241279206 |
BOUTON | Na dotaz | Zadat poptávku | |
| 402 0 WHR62118 |
C00311545
481236039073 |
kompresor R600 univ EMX70CLC-náhrada 484000008469 | 4 200 Kč
€ 165.80 |
||
| 402 1 WHR62118 |
C00329857
481241818667 |
Tray compressor | Na dotaz | Zadat poptávku | |
| 402 2 WHR62118 |
C00331559
481246699005 |
Base compressor | Na dotaz | Zadat poptávku | |
| 441 0 WHR62118 |
C00311429
481236118635 |
motor ventilatoru | 3 403 Kč
€ 134.30 |
||
| 441 1 WHR62118 |
C00314645
481240418458 |
Support motor freezer | Na dotaz | Zadat poptávku | |
| 441 2 WHR62118 |
C00315086
481246638021 |
Damper fan | Na dotaz | Zadat poptávku | |
| 441 3 WHR62118 |
C00315305
481236118282 |
Fan | Na dotaz | Zadat poptávku | |
| 441 5 WHR62118 |
C00319061
481240418482 |
Support motor fan | Na dotaz | Zadat poptávku | |
| 480 0 WHR62118 |
C00317517
481201978857 |
Cable harness | Na dotaz | Zadat poptávku | |
| 526 0 WHR62118 |
C00312116
481223678536 |
modul chl. | 4 317 Kč
€ 170.40 |
||
| 554 0 WHR62118 |
C00311482
481228268064 |
termostat | Na dotaz | Zadat poptávku | |
| 554 1 WHR62118 |
C00317744
481222438027 |
Cabinet thermostat | Na dotaz | Zadat poptávku | |
| 564 0 WHR62118 |
C00497303
481225228045 |
Thermal fuse | Na dotaz | Zadat poptávku | |
| 614 0 WHR62118 |
C00327052
481221838622 |
Relay | Na dotaz | Zadat poptávku | |
| 651 0 WHR62118 |
C00326855
481213488061 |
Lamp 220V-15W | Na dotaz | Zadat poptávku | |
| 652 0 WHR62118 |
C00327124
481225518277 |
Holder lamp | Na dotaz | Zadat poptávku | |
| 652 1 WHR62118 |
C00330519
481246228624 |
Protector lamp | Na dotaz | Zadat poptávku | |
| 652 2 WHR62118 |
C00329166
481240468044 |
Support lamp | Na dotaz | Zadat poptávku | |
| 655 0 WHR62118 |
C00403913
481245228817 |
Control board + cover | Na dotaz | Zadat poptávku | |
| 691 0 WHR62118 |
C00312619
481213428075 |
senzor teploty | 1 456 Kč
€ 57.50 |
||
| 702 0 WHR62118 |
C00332353
481252648253 |
Tube | Na dotaz | Zadat poptávku | |
| 743 0 WHR62118 |
C00405193
481248028125 |
Air diffuser assembly | Na dotaz | Zadat poptávku | |
| 743 1 WHR62118 |
C00403227
481244029501 |
Cover air diffuser | Na dotaz | Zadat poptávku | |
| 743 2 WHR62118 |
C00330523
481246228641 |
Cover air diffuser | Na dotaz | Zadat poptávku | |
| 743 4 WHR62118 |
C00331048
481244229294 |
Air guide | Na dotaz | Zadat poptávku | |
| 743 5 WHR62118 |
C00517558
481244229295 |
Cover air diffuser.. | Na dotaz | Zadat poptávku | |
| 745 0 WHR62118 |
C00319494
481251138326 |
Evaporator | Na dotaz | Zadat poptávku | |
| 745 2 WHR62118 |
C00328132
481244029472 |
Spacebar right | Na dotaz | Zadat poptávku | |
| 745 3 WHR62118 |
C00328133
481244029473 |
Spacebar left | Na dotaz | Zadat poptávku | |
| 745 4 WHR62118 |
C00329015
481240438735 |
držák senzoru | 321 Kč
€ 12.70 |
||
| 746 1 WHR62118 |
C00342326
481244079174 |
Cover,front | Na dotaz | Zadat poptávku | |
| 746 2 WHR62118 |
C00403238
481244029558 |
Cover evaporator rear | Na dotaz | Zadat poptávku | |
| 746 3 WHR62118 |
C00328974
481240418457 |
Support sensor | Na dotaz | Zadat poptávku | |
| 764 0 WHR62118 |
C00345711
481248028051 |
Dryer | Na dotaz | Zadat poptávku | |
| 904 0 WHR62118 |
C00319419
481240449842 |
Spona | 158 Kč
€ 6.20 |
||
| 904 1 WHR62118 |
C00329132
481240449843 |
Kolejnice levá | 592 Kč
€ 23.40 |
||
| 999 WHR62118 |
C00677817 | Circuit/Wiring Diagram WHP | Na dotaz | Zadat poptávku | |
