WHIRLPOOL WVG 261/1
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
Komerční kód: | WVG 261/1 |
Kód 12NC: | 850461665130 |
Značka: | WHIRLPOOL |
Typ produktu: | Volně stojící mrazáky |
Další podobné modely: | 850461642110, 850461665120 |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
Číslo | Kód | Název | Cena | ||
---|---|---|---|---|---|
011 0 WHR77638 |
C00404736
481246218322 |
Foot WH | Na dotaz | Zadat poptávku | |
011 1 WHR77638 |
C00401971
481240449613 |
Support adjusting screw | Na dotaz | Zadat poptávku | |
012 0 WHR77638 |
C00491928
481246238133 |
Roller | Na dotaz | Zadat poptávku | |
030 0 WHR77638 |
C00576138
481232818184 |
Timer 220V/50Hz | Na dotaz | Zadat poptávku | |
033 3 WHR77638 |
C00404955
481246418194 |
Console WH | Na dotaz | Zadat poptávku | |
034 1 WHR77638 |
C00403219
481244029484 |
Elect.parts box WH | Na dotaz | Zadat poptávku | |
040 0 WHR77638 |
C00482883
481240478518 |
Support | Na dotaz | Zadat poptávku | |
040 1 WHR77638 |
C00404723
481246098126 |
Cover left WH | Na dotaz | Zadat poptávku | |
040 2 WHR77638 |
C00404724
481246098127 |
Cover right | Na dotaz | Zadat poptávku | |
041 0 WHR77638 |
C00488952
481241719038 |
Hinge upper | Na dotaz | Zadat poptávku | |
041 1 WHR77638 |
C00488983
481241719287 |
Závěs dveří šuplíkového mrazáku (horní/dolní) Whirlpool | 110 Kč
€ 4.30 |
||
041 4 WHR77638 |
C00402729
481241719367 |
Hinge lower | Na dotaz | Zadat poptávku | |
041 8 WHR77638 |
C00319327
481246098059 |
Cover | Na dotaz | Zadat poptávku | |
047 0 WHR77638 |
C00576393
481246258092 |
Stop door left.. | Na dotaz | Zadat poptávku | |
047 1 WHR77638 |
C00402730
481241719368 |
Stop door | Na dotaz | Zadat poptávku | |
047 2 WHR77638 |
C00344062
481253288067 |
Bushing WH | Na dotaz | Zadat poptávku | |
047 3 WHR77638 |
C00330537
481246228701 |
Cover WH | Na dotaz | Zadat poptávku | |
101 0 WHR77638 |
C00402695
481241619937 |
Door freezer WH | Na dotaz | Zadat poptávku | |
102 0 WHR77638 |
C00402694
481241619936 |
Door flap | Na dotaz | Zadat poptávku | |
111 0 WHR77638 |
C00487765
481249818224 |
Handle | Na dotaz | Zadat poptávku | |
111 1 WHR77638 |
C00377845
481249878672 |
kryt rukojeťe | 1 105 Kč
€ 43.60 |
||
111 2 WHR77638 |
C00404620
481246068577 |
Insert f.Handle right | Na dotaz | Zadat poptávku | |
111 3 WHR77638 |
C00404621
481246068578 |
Insert f.Handle left | Na dotaz | Zadat poptávku | |
111 5 WHR77638 |
C00404488
481245918271 |
Nameplate gray | Na dotaz | Zadat poptávku | |
111 7 WHR77638 |
C00576370
481245918254 |
Nameplate Whirlpool.. | Na dotaz | Zadat poptávku | |
117 3 WHR77638 |
C00482836
481240418307 |
Slide | Na dotaz | Zadat poptávku | |
156 0 WHR77638 |
C00576212
481241848653 |
Tray icecube.. | Na dotaz | Zadat poptávku | |
191 0 WHR77638 |
C00576409
481246818305 |
Gasket.. | Na dotaz | Zadat poptávku | |
244 0 WHR77638 |
C00402876
481241820092 |
Drawer large | Na dotaz | Zadat poptávku | |
244 1 WHR77638 |
C00487580
481241878081 |
Grid | Na dotaz | Zadat poptávku | |
244 3 WHR77638 |
C00402922
481241828932 |
Drawer Refrig. lower | Na dotaz | Zadat poptávku | |
245 0 WHR77638 |
C00484963
481241828271 |
Shelf | Na dotaz | Zadat poptávku | |
301 0 WHR77638 |
C00404593
481246049874 |
Control panel WH | Na dotaz | Zadat poptávku | |
301 1 WHR77638 |
C00404079
481245310889 |
Display | Na dotaz | Zadat poptávku | |
324 5 WHR77638 |
C00484029
481246228346 |
Air diffuser | Na dotaz | Zadat poptávku | |
331 0 WHR77638 |
C00400917
481227618489 |
Knob switch fast freezing | Na dotaz | Zadat poptávku | |
331 1 WHR77638 |
C00488711
481240418306 |
Lock | Na dotaz | Zadat poptávku | |
332 0 WHR77638 |
C00493520
481241368017 |
Switch fast freezing | Na dotaz | Zadat poptávku | |
334 0 WHR77638 |
C00401020
481228268046 |
Knob thermostat gray | Na dotaz | Zadat poptávku | |
402 0 WHR77638 |
C00482713
481236038961 |
Compressor EG 100 HLR | Na dotaz | Zadat poptávku | |
402 2 WHR77638 |
C00576151
481240418308 |
Base compressor.. | Na dotaz | Zadat poptávku | |
402 3 WHR77638 |
C00377666
481241818687 |
Tray Compressor | Na dotaz | Zadat poptávku | |
420 0 WHR77638 |
C00405520
481251148485 |
Fuse bi-metal | Na dotaz | Zadat poptávku | |
440 0 WHR77638 |
C00488649
481236118341 |
Fan wheel | Na dotaz | Zadat poptávku | |
440 9 WHR77638 |
C00493822
481253538102 |
Valve | Na dotaz | Zadat poptávku | |
443 0 WHR77638 |
C00326717
481202858374 |
Motor fan 220-240V/50-60Hz | Na dotaz | Zadat poptávku | |
443 1 WHR77638 |
C00574941
481246368014 |
Damper. | Na dotaz | Zadat poptávku | |
443 2 WHR77638 |
C00335783
481246048881 |
Support Ventilator | Na dotaz | Zadat poptávku | |
451 0 WHR77638 |
C00400718
481221848187 |
Heating element 500W 200V | Na dotaz | Zadat poptávku | |
506 2 WHR77638 |
C00484625
481221838145 |
Plug female | Na dotaz | Zadat poptávku | |
556 0 WHR77638 |
C00312619
481213428075 |
senzor teploty | 1 456 Kč
€ 57.50 |
||
564 0 WHR77638 |
C00404978
481246418256 |
Fuse | Na dotaz | Zadat poptávku | |
566 2 WHR77638 |
C00491042
481227148002 |
Thermostat | Na dotaz | Zadat poptávku | |
566 4 WHR77638 |
C00401352
481232178245 |
Cable harness upper | Na dotaz | Zadat poptávku | |
614 0 WHR77638 |
C00490944
481221838269 |
Relay overload protection | Na dotaz | Zadat poptávku | |
702 0 WHR77638 |
C00405578
481252648274 |
Tube | Na dotaz | Zadat poptávku | |
740 0 WHR77638 |
C00574589
481251148337 |
Condenser. | Na dotaz | Zadat poptávku | |
740 1 WHR77638 |
C00330489
481246228394 |
Holder Condenser | Na dotaz | Zadat poptávku | |
740 2 WHR77638 |
C00482840
481240418443 |
Support condenser upper | Na dotaz | Zadat poptávku | |
743 0 WHR77638 |
C00482950
481244078993 |
Cabinet | Na dotaz | Zadat poptávku | |
745 0 WHR77638 |
C00486260
481251138179 |
Evaporator | Na dotaz | Zadat poptávku | |
745 1 WHR77638 |
C00485136
481244078992 |
Cover evaporator | Na dotaz | Zadat poptávku | |
745 2 WHR77638 |
C00482931
481244029361 |
Cabinet | Na dotaz | Zadat poptávku | |
751 0 WHR77638 |
C00405597
481253029378 |
Drainpipe lower | Na dotaz | Zadat poptávku | |
764 0 WHR77638 |
C00345711
481248028051 |
Dryer | Na dotaz | Zadat poptávku | |
901 0 WHR77638 |
C00491491
481240418313 |
Shaft | Na dotaz | Zadat poptávku | |
904 2 WHR77638 |
C00490978
481226278022 |
Cap | Na dotaz | Zadat poptávku | |
962 0 WHR77638 |
C00485113
481244029451 |
Protector module | Na dotaz | Zadat poptávku | |
999 WHR77638 |
C00705087 | Circuit/Wiring Diagram WHP | Na dotaz | Zadat poptávku |
