WHIRLPOOL WVG 29 UPRIGHT FREEZERS WP
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | WVG 29 UPRIGHT FREEZERS WP |
| Kód 12NC: | 850460771000 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Volně stojící mrazáky |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 024 0 WHR93071 |
C00574837
481244010536 |
Table top. | Na dotaz | Zadat poptávku | |
| 040 0 WHR93071 |
C00339800
481241718854 |
Hinge lower | Na dotaz | Zadat poptávku | |
| 040 0 WHR93071 |
C00488951
481241719036 |
Hinge upper | Na dotaz | Zadat poptávku | |
| 040 1 WHR93071 |
C00336360
481241778021 |
Shim hinge | Na dotaz | Zadat poptávku | |
| 040 2 WHR93071 |
C00574795
481241719037 |
Hinge,upper. | Na dotaz | Zadat poptávku | |
| 040 3 WHR93071 |
C00488952
481241719038 |
Hinge upper | Na dotaz | Zadat poptávku | |
| 040 4 WHR93071 |
C00488953
481241719039 |
Hinge lower | Na dotaz | Zadat poptávku | |
| 041 1 WHR93071 |
C00336366
481241778022 |
Shim | Na dotaz | Zadat poptávku | |
| 070 0 WHR93071 |
C00574852
481244088988 |
Pedestal. | Na dotaz | Zadat poptávku | |
| 102 0 WHR93071 |
C00574843
481244069137 |
Evapor.door. | Na dotaz | Zadat poptávku | |
| 104 0 WHR93071 |
C00574749
481241618502 |
Door refriger.. | Na dotaz | Zadat poptávku | |
| 111 7 WHR93071 |
C00574901
481245918211 |
Nameplate. | Na dotaz | Zadat poptávku | |
| 111 8 WHR93071 |
C00493581
481245918212 |
Nameplate | Na dotaz | Zadat poptávku | |
| 156 0 WHR93071 |
C00339160
481241848502 |
Icecube tray | Na dotaz | Zadat poptávku | |
| 191 0 WHR93071 |
C00574960
481246688609 |
Magnetic seal. | Na dotaz | Zadat poptávku | |
| 241 0 WHR93071 |
C00484963
481241828271 |
Shelf | Na dotaz | Zadat poptávku | |
| 244 0 WHR93071 |
C00574828
481241868255 |
DRAWER. | Na dotaz | Zadat poptávku | |
| 244 1 WHR93071 |
C00574829
481241868256 |
Drawer small. | Na dotaz | Zadat poptávku | |
| 244 2 WHR93071 |
C00574830
481241868257 |
Drawer. | Na dotaz | Zadat poptávku | |
| 244 3 WHR93071 |
C00574844
481244069138 |
Flap. | Na dotaz | Zadat poptávku | |
| 247 2 WHR93071 |
C00574922
481246228324 |
Cover ,Thermostat. | Na dotaz | Zadat poptávku | |
| 253 4 WHR93071 |
C00574311
481227138411 |
Switch lamp. | Na dotaz | Zadat poptávku | |
| 301 0 WHR93071 |
C00574867
481245228299 |
Control panel. | Na dotaz | Zadat poptávku | |
| 324 5 WHR93071 |
C00574845
481244069195 |
Air diffuser. | Na dotaz | Zadat poptávku | |
| 331 0 WHR93071 |
C00574680
481227158167 |
Knob thermostat. | Na dotaz | Zadat poptávku | |
| 402 0 WHR93071 |
C00574708
481236038779 |
Compressor EG70 LRW 220V/60Hz. | Na dotaz | Zadat poptávku | |
| 402 2 WHR93071 |
C00574987
481253538085 |
Clip. | Na dotaz | Zadat poptávku | |
| 402 3 WHR93071 |
C00574946
481246428021 |
Traverse. | Na dotaz | Zadat poptávku | |
| 402 4 WHR93071 |
C00318946
481241818319 |
Tray | Na dotaz | Zadat poptávku | |
| 440 0 WHR93071 |
C00488649
481236118341 |
Fan wheel | Na dotaz | Zadat poptávku | |
| 440 1 WHR93071 |
C00574941
481246368014 |
Damper. | Na dotaz | Zadat poptávku | |
| 441 4 WHR93071 |
C00482950
481244078993 |
Cabinet | Na dotaz | Zadat poptávku | |
| 443 0 WHR93071 |
C00574714
481236138051 |
MOTOR VENTILATORA 220V/60HZ | Na dotaz | Zadat poptávku | |
| 443 1 WHR93071 |
C00335783
481246048881 |
Support Ventilator | Na dotaz | Zadat poptávku | |
| 451 0 WHR93071 |
C00488521
481225948149 |
Heating element | Na dotaz | Zadat poptávku | |
| 451 1 WHR93071 |
C00484645
481225278799 |
Fuse | Na dotaz | Zadat poptávku | |
| 480 0 WHR93071 |
C00574701
481232058108 |
Cable harness. | Na dotaz | Zadat poptávku | |
| 503 0 WHR93071 |
C00482949
481244078991 |
Cabinet ,Timer | Na dotaz | Zadat poptávku | |
| 503 1 WHR93071 |
C00482931
481244029361 |
Cabinet | Na dotaz | Zadat poptávku | |
| 503 2 WHR93071 |
C00491433
481232818185 |
Timer 220V/60Hz | Na dotaz | Zadat poptávku | |
| 554 0 WHR93071 |
C00574685
481228238092 |
Thermostat. | Na dotaz | Zadat poptávku | |
| 566 0 WHR93071 |
C00491346
481228238093 |
Thermostat | Na dotaz | Zadat poptávku | |
| 614 0 WHR93071 |
C00574992
481269028027 |
Relay. | Na dotaz | Zadat poptávku | |
| 620 3 WHR93071 |
C00574746
481241359098 |
Knob. | Na dotaz | Zadat poptávku | |
| 651 0 WHR93071 |
C00574299
481213488025 |
Lamp. | Na dotaz | Zadat poptávku | |
| 652 0 WHR93071 |
C00574676
481225528009 |
Holder,lamp. | Na dotaz | Zadat poptávku | |
| 652 1 WHR93071 |
C00574731
481240478475 |
Support | Na dotaz | Zadat poptávku | |
| 655 1 WHR93071 |
C00574923
481246228325 |
Lamp shield. | Na dotaz | Zadat poptávku | |
| 740 0 WHR93071 |
C00574976
481251148271 |
Condenser. | Na dotaz | Zadat poptávku | |
| 740 1 WHR93071 |
C00621451
481246698943 |
BRACKET. | Na dotaz | Zadat poptávku | |
| 743 0 WHR93071 |
C00574842
481244069035 |
COVER. | Na dotaz | Zadat poptávku | |
| 743 1 WHR93071 |
C00574985
481253048366 |
Insulation. | Na dotaz | Zadat poptávku | |
| 745 0 WHR93071 |
C00486260
481251138179 |
Evaporator | Na dotaz | Zadat poptávku | |
| 745 0 WHR93071 |
C00574968
481250218506 |
Screw. | Na dotaz | Zadat poptávku | |
| 745 1 WHR93071 |
C00485136
481244078992 |
Cover evaporator | Na dotaz | Zadat poptávku | |
| 746 0 WHR93071 |
C00740064
481248028038 |
Dryer | Na dotaz | Zadat poptávku | |
| 751 0 WHR93071 |
C00575086
481253048365 |
Defrostingpipe. | Na dotaz | Zadat poptávku | |
| 900 0 WHR93071 |
C00342336
481244229065 |
Cover white | Na dotaz | Zadat poptávku | |
| 902 3 WHR93071 |
C00343300
481253578042 |
Clip | Na dotaz | Zadat poptávku | |
| 902 4 WHR93071 |
C00574700
481232058073 |
Staple. | Na dotaz | Zadat poptávku | |
| 902 5 WHR93071 |
C00491965
481246698997 |
Spacer | Na dotaz | Zadat poptávku | |
| 902 6 WHR93071 |
C00574719
481240118568 |
Clamp. | Na dotaz | Zadat poptávku | |
| 902 7 WHR93071 |
C00491981
481249148013 |
Clip fix | Na dotaz | Zadat poptávku | |
| 902 8 WHR93071 |
C00315086
481246638021 |
Damper fan | Na dotaz | Zadat poptávku | |
| 902 9 WHR93071 |
C00482960
481244098104 |
Cabinet | Na dotaz | Zadat poptávku | |
| 904 7 WHR93071 |
C00498375
481246228179 |
Bushing right,white. | Na dotaz | Zadat poptávku | |
| 904 8 WHR93071 |
C00574859
481244688129 |
drzak dveri levy | 78 Kč
€ 3.10 |
||
| 904 9 WHR93071 |
C00344080
481253288011 |
Bushing | Na dotaz | Zadat poptávku | |
| 905 0 WHR93071 |
C00336004
481253288012 |
zaslepka | 122 Kč
€ 4.80 |
||
| 905 1 WHR93071 |
C00336668
481256018023 |
Screw | Na dotaz | Zadat poptávku | |
| 905 2 WHR93071 |
C00336667
481256018022 |
Screw | Na dotaz | Zadat poptávku | |
| 910 0 WHR93071 |
C00492130
481253598092 |
Adjusting screw foot | Na dotaz | Zadat poptávku | |
| 910 1 WHR93071 |
C00336665
481256018026 |
Screw | Na dotaz | Zadat poptávku | |
| 910 1 WHR93071 |
C00574989
481256018058 |
SCREW. | Na dotaz | Zadat poptávku | |
| 910 3 WHR93071 |
C00574990
481256018059 |
Screw. | Na dotaz | Zadat poptávku | |
| 910 4 WHR93071 |
C00574991
481256018061 |
Screw. | Na dotaz | Zadat poptávku | |
| 910 5 WHR93071 |
C00336570
481256018025 |
Screw M5x10mm | Na dotaz | Zadat poptávku | |
| 910 6 WHR93071 |
C00574732
481240478476 |
Spacer. | Na dotaz | Zadat poptávku | |
| 912 0 WHR93071 |
C00576118
481222008013 |
Screw.. | Na dotaz | Zadat poptávku | |
| 912 1 WHR93071 |
C00492140
481256018024 |
Screw | Na dotaz | Zadat poptávku | |
| 999 WHR93071 |
C00740535 | Circuit/Wiring Diagram WHP | Na dotaz | Zadat poptávku | |
